Chapter 2
Cortex Architecture: Principles and Components

Delve into the engineering heart of Cortex and discover the sophisticated architectural principles that make Internet-scale, multi-tenant metrics possible. This chapter breaks down the modular microservices core, unpacks data ingestion and retrieval mechanics, explores storage abstractions, and reveals the design decisions behind Cortex's fault tolerance and extensibility. Whether you're architecting a greenfield deployment or optimizing for extreme workloads, this journey exposes the inner workings and building blocks that separate Cortex from conventional observability systems.

2.1 Microservices Foundation of Cortex

Cortex is architected as a collection of loosely coupled microservices, each assuming a distinct role in managing the lifecycle of time series data. This design enables a resilient, scalable, and flexible monitoring solution suited for demanding cloud-native environments. The core components-the distributor, ingester, querier, ruler, alertmanager, and compactor-coordinate to provide a comprehensive data ingestion, storage, querying, and alerting system. Their interplay exemplifies the advantages of microservice decomposition in a large-scale, metrics-focused platform.

The distributor acts as the ingress point for all incoming metrics. It receives time series data via remote write requests, performing initial validation and consistency checks such as tenant identification and write authorization. To maintain a high availability facade, distributors implement sharding logic, wherein the incoming dataset is replicated to multiple ingesters based on a consistent hashing scheme derived from tenant ID and metric labels. This replication ensures durability and fault tolerance without sacrificing write throughput. Furthermore, distributors use ring-based state management to discover active ingesters dynamically, avoiding centralized bottlenecks. Requests are thus spread evenly, preventing hotspots and enabling elastic scaling of subsequent ingestion layers.

Once received and acknowledged by the distributor, the ingesters are responsible for temporarily storing metrics in memory and performing initial preprocessing. This includes deduplication, compression, and enforcing write-ahead logging to persistent storage (such as object stores) for durability guarantees. Ingester instances maintain distinct in-memory chunks organized by series identity and time window, allowing fast appends and localized data management. To balance consistency with high availability, ingesters employ a distributed consensus protocol to coordinate handoffs during scaling events or failures, ensuring no data loss or duplication. Ingester architecture permits horizontal scaling independently from other services, facilitating elastic resource allocation tailored to ingestion volume and workload.

The querier component operates as the front line for data retrieval, responding to PromQL queries by fetching and merging metrics from long-term storage and recent in-memory ingester chunks. Queriers interface directly with storage backends supporting object storage APIs, applying parallelized data fetching and chunk filtering strategies to minimize latency. They dereference metadata stored in ring and index services to locate data shards efficiently. Query execution involves consolidating results retrieved from independently evolving ingesters and storage layers-a task complicated by eventual consistency inherent in microservice messaging. Advanced caching and query federation optimize repeated query performance while managing resource utilization. Crucially, the querier's decoupling from ingestion allows independent scaling and upgrading, meeting read-intensive workloads without disruption.

Complementing data retrieval, the ruler microservice focuses on continuous evaluation of predefined alerting and recording rules. It periodically executes PromQL expressions, relying on the querier to fetch relevant time series data. The ruler manages isolated rule evaluation for each tenant, leveraging concurrency to scale horizontally. Processed results trigger alerts or generate new derived metrics, which are then reinjected into the system through the distributor. This feedback loop preserves dimensional consistency and auditability. By segregating rule evaluation, Cortex enables independent tuning and extension of alerting logic without impacting core ingestion or query pipelines, granting operators granular control over alert lifecycle management.

The alertmanager serves as the primary alert delivery and silencing engine within Cortex. It consumes alert notifications forwarded from the ruler, applying deduplication, inhibition, grouping, and routing logic based on user-configured policies. Alertmanager supports various notification channels-email, PagerDuty, Slack, and others-ensuring timely incident response integration. Its stateless design permits horizontal scaling while stateful coordination is achieved via shared key-value stores or consensus protocols. Moreover, multi-tenant isolation safeguards alert data confidentiality, with custom routing policies respecting organizational boundaries. By outsourcing alert dispatch to a separate microservice, Cortex improves fault tolerance and allows fine-grained management of alerting workflows independent from metric processing.

Finally, the compactor microservice orchestrates long-term data maintenance within Cortex's object storage backends. Metric data ingested and stored initially in small chunks is gradually compacted into larger, optimized blocks. This process reduces storage overhead, minimizes index size, and improves query performance by aligning storage layout with common access patterns. The compactor runs periodically, merging overlapping blocks, pruning expired data per retention policies, and reindexing content. It cooperates with ring metadata and storage topology services to coordinate safely, avoiding conflicts in concurrent compaction tasks. By isolating compaction, Cortex allows independent evolution and scaling of storage optimization routines, unburdening ingestion and query services from background maintenance duties.

Together, these components form a horizontally scalable and modular framework. The microservice decomposition fundamentally enhances Cortex's operational flexibility: deployments can tailor resource allocation at the component level, updating or scaling each microservice independently without systemic downtime. Tenant isolation is ensured through fine-grained sharding and per-service multitenancy support, preventing cross-customer interference. Distributed state management through rings and consensus algorithms enables dynamic discovery, fault tolerance, and consistent data routing. Consequently, Cortex achieves a robust and elastic platform for time series monitoring that grows seamlessly with user demands while maintaining rigorous control over the entire metrics lifecycle from ingestion to alert generation and data compaction.

2.2 Write Path: From Ingestion to Storage

Metrics ingestion within a distributed time-series database such as Cortex involves a carefully orchestrated sequence of operations designed to guarantee durability, consistency, and high throughput. The write path from data ingestion to final storage is underpinned by a set of components and processes including the Write-Ahead Log (WAL), chunk manipulation, batching strategies, protocol translation, and sharding architectures. Cortex's design leverages these elements to minimize data loss, enhance reliability, and maintain scalability in environments with massive volumes of time-series data.

Upon receiving incoming metrics, Cortex first persists this data into the Write-Ahead Log (WAL). The WAL acts as a durable, sequential record of all incoming samples before any further processing, ensuring that data can be recovered in case of failures or crashes. Unlike buffering data solely in memory-which risks loss on process interruption-the WAL leverages local disk storage to provide a reliable checkpoint. This mechanism establishes a clear commit point for every incoming sample, guaranteeing at-least-once delivery semantics. The WAL is typically implemented as an append-only structure that allows fast sequential writes and efficient reads during recovery.

Raw data in the WAL is subsequently transformed into chunks: contiguous blocks of time-series samples organized for efficient compression and retrieval. Chunking reduces the overhead of storing individual samples by grouping them into manageable segments, optimizing both storage and query performance. Cortex's ingestion pipeline strategically accumulates a series of incoming samples for the same time series until a predetermined chunk size or age threshold is met. This strategy balances ingestion latency and storage efficiency, with early flushing mechanisms triggered by high memory pressure or uneven traffic.

Batching forms another critical layer in the ingestion write path. Instead of processing each sample individually, Cortex aggregates a number of chunks or samples into batches...
