The Art of Bookbinding: A practical treatise, with plates and diagrams

THE ART OF BOOKBINDING. CHAPTER I. FOLDING.

We commence with folding. It is generally the first thing the binder has to do with a book. The sheets are either supplied by the publisher or printer (mostly the printer); should the amateur wish to have his books in sheets, he may generally get them by asking his bookseller for them. It is necessary that they be carefully folded, for unless they are perfectly even, it is impossible that the margins (the blank space round the print) can be uniform when the book is cut. Where the margin is small, as in very small prayer books, a very great risk of cutting into the print is incurred; besides, it is rather annoying to see a book which has the folio or paging on one leaf nearly at the top, and on the next, the print touching the bottom; to remedy such an evil, the printer having done his duty by placing his margins quite true, it remains with the binder to perfect and bring the sheet into proper form by folding. The best bound book may be spoilt by having the sheets badly folded, and the binder is perfectly justified in rejecting any sheets that may be badly printed, that is, not in register. |4|

The sheets are laid upon a table with the signatures (the letters or numbers that are at the foot of the first page of each sheet when folded) facing downwards on the left hand side. A folding-stick is held in the right hand, and the sheet is brought over from right to left, the folios being carefully placed together; if the paper is held up to the light, and is not too thick, it can be easily seen through. Holding the two together and laying them on the table the folder is drawn across the sheet, creasing the centre; then, holding the sheet down with the folder on the line to be creased, the top part is brought over and downwards till the folios or the bottom of the letterpress or print is again even. The folder is then drawn across, and so by bringing each folio together the sheet is completed. The process is extremely simple. The octavo sheet is generally folded into 4 folds, thus giving 8 leaves or 16 pages; a quarto, into 2, giving 4 leaves or 8 pages, and the sheets properly folded, will have their signatures outside at the foot of the first page. If the signature is not on the outside, one may be certain that the sheet has been wrongly folded.

I say generally; at one time the water or wire mark on the paper and the number of folds gave the size of the book.

There are numerous other sizes, but it is not necessary to give them all; the process of folding is in nearly all cases the same; here are however, a few of the sizes given in inches.

As a final caution, the first and last sheets must be carefully examined; very often the sheet has to be cut up or divided, and the leaf or leaves placed in various positions in the book.

It is also advisable to cut the head of the sheets, using the folding-stick, cutting just beyond the back or middle fold; this prevents the sheet running into a side crease when pressing or rolling. Should such a crease occur the leaf or sheet must be damped by placing it between wet paper and subjecting it to pressure; no other method is likely to erase the break.

Refolding.-With regard to books that have been issued in numbers, they must be pulled to pieces or divided. The parts being arranged in consecutive order, so that not so much difficulty will be felt in collating the sheets, the outside wrapper is torn away, and each sheet pulled singly from its neighbour, care being taken to see if any thread used in sewing is in the centre of the sheet at the back; if so, it must be cut with a knife or it will tear the paper. As the sheets are pulled they must be laid on the left hand side, each sheet being placed face downwards; should they be placed face upwards the first sheet will be the last and the whole will require rearranging. All advertisements may be placed away from the sheets into a pile; these will be found very handy for lining boards, pasting on, or as waste. The title and contents will generally be found in the last part; place them in their proper places. The sheets must now be refolded, if improperly folded in the first instance. |6| Turn the whole pile (or book now) over, and again go through each sheet; alter by refolding any sheet that may require it. Very often the sheets are already cut, and in this case the section must be dissected and each leaf refolded and reinserted in proper sequence, and placed carefully head-line to head-line. Great care must be exercised, as the previous creasings render the paper liable to be torn in the process.

Books that have been bound and cut would be rendered often worse by refolding, and as a general rule they are left alone. Bound books are pulled to pieces in the same manner, always taking care that the thread is cut or loose before tearing the sheet away; should trouble arise through the glue, etc., not coming away easily, the back may be damped with a sponge lightly charged with water, or perhaps a better method is to place the book or books in a press, screw up tightly, and soak the backs with thin paste, leaving them soaking for an hour or two; they will want repasting two or three times during the period; the whole of the paper, glue, and leather can then be easily scraped away with a blunt knife; a handful of shavings rubbed over the back will make it quite clean, and no difficulty will be met with if the sections are taken apart while damp. The sections must, as pulled, be placed evenly one on |7| the other, as the paper at back retains sufficient glue to cause them to stick together if laid across one another; the whole must then be left to dry. When dry the groove should be knocked down on a flat surface, and for this the knocking-down iron screwed up in the lying press is perhaps the best thing to use. The groove is the projecting part of the book close to the back, caused by the backing, and is the groove for the back edge of the mill-board to work in by a hinge; this hinge is technically called the "joint."

Machines.-There are many folding machines made by the various machinists; the working of them, however, is in nearly all cases identical. The machine is generally |8| fed by a girl, who places the sheet to points, the arm lifting up at given periods to allow placing the sheet. Another arm carrying a long thin blade descends, taking the sheet through a slot in the table, where it is passed between rollers; another set of rollers at right angles creases it again. The rollers are arranged for two, three, or more creasings or folds. The sheets are delivered at the side into a box, from which they are taken from time to time. The cut is one of Martini's, and is probably the most advanced.

Gathering.-A gathering machine has been patented which is of a simple but ingenious contrivance for the quick gathering of sheets. The usual way to gather, is by laying piles of sheets upon a long table, and for the gatherer to take from each pile a sheet in succession. By the new method a round table is made to revolve by machinery, and upon it are placed the piles of sheets. As the table revolves the gatherer takes a sheet from each pile as it passes him. It will at once be seen that not only is space saved, but that a number of gatherers may be placed at the table; and that there is no possibility of the...
