CHAPTER 1
INTRODUCTION AND FORMS OF CORROSION

Corrosion is basically a combination of technical and economic problems. To understand the economics of corrosion, it is necessary that one is proficient in both the science of corrosion and the fundamental principles of economics. There are many forms of corrosion, which can be deleterious in a variety of ways. It is logical to discuss the various forms of corrosion of metallic structures occurring in different corrosive environments.

1.1 GENERAL OR UNIFORM OR QUASI-UNIFORM CORROSION

General corrosion is the most common form of corrosion. This can be uniform (even), quasi-uniform, or uneven. General corrosion accounts for the greatest loss of metal or material. Electrochemical general corrosion in aqueous media can include galvanic or bimetallic corrosion, atmospheric corrosion, stray current dissolution, and biological corrosion (Table 1.1).

Table 1.1 Forms of Corrosion1

1. General corrosion Uniform, quasi-uniform, nonuniform corrosion, galvanic corrosion 2. Localized corrosion Pitting corrosion, crevice corrosion, filiform corrosion 3. Metallurgically influenced corrosion Intergranular corrosion, sensitization, exfoliation, dealloying 4. Microbiologically influenced corrosion 5. Mechanically assisted corrosion Wear corrosion, erosion-corrosion, corrosion fatigue 6. Environmentally induced cracking Stress-corrosion cracking; hydrogen damage, embrittlement; hydrogen-induced blistering; high-temperature hydrogen attack; hot cracking, hydride formation; liquid metal embrittlement; solid metal-induced embrittlement

1 ASM Metals Handbook, Corrosion, Vol. 13, 9th ed., Craig and Pohlman, pp. 77-189.

Dissolution of steel or zinc in sulfuric or hydrochloric acid is a typical example of uniform electrochemical attack. Uniform corrosion often results from exposure to polluted industrial environments, exposure to fresh, brackish, and salt waters, or exposure to soils and chemicals. Some examples of uniform or general corrosion are the rusting of steel, the green patina on copper, tarnishing silver, and white rust on zinc on atmospheric exposure. Tarnishing of silver in air, oxidation of aluminum in air, attack of lead in sulfate-containing environments results in the formation of thin protective films and the metal surface remains smooth. Oxidation, sulfidation, carburization, hydrogen effects, and hot corrosion can be considered as types of general corrosion(16).

Liquid metals and molten salts at high temperatures lead to general corrosion(1). Microelectrochemical cells result in uniform general corrosion. Uniform general corrosion can be observed during chemical and electrochemical polishing and passivity where anodic and cathodic sites are physically inseparable. A polished surface of a pure active metal immersed in a natural medium (atmosphere) can suffer from galvanic cells. Most of the time, the asperities act as anodes and the cavities as cathodes. If these anodic and cathodic sites are mobile and change in a continuous dynamic manner, uniform or quasi-uniform corrosion is observed. If some anodic sites persist and are not covered by protective corrosion products, or do not passivate, localized corrosion is observed (1).

Some macroelectrochemical cells can cause a uniform or near-uniform general attack of certain regions. General uneven or quasi-uniform corrosion is observed in natural environments. In some cases, uniform corrosion produces a somewhat rough surface by the removal of a substantial amount of metal that either dissolves in the environment or reacts with it to produce a loosely adherent, porous coating of corrosion products. After careful removal of rust formed because of general atmospheric corrosion of steel, the surface reveals an undulated surface, indicating nonuniform attack of different areas (1) as shown in Figure 1.1.

Figure 1.1 Even and uneven general corrosion and high-temperature attack. (Reproduced by permission, Elsevier Ltd. (2).)

In natural atmospheres, the general corrosion of metals can be localized. The corrosion morphology is dependent on the conductivity, ionic species, temperature of the electrolyte, alloy composition, phases, and homogeneity in the microstructure of the alloy, and differential oxygenation cell. The figure also shows high-temperature attack that is generally uniform. It is also possible to observe subsurface corrosion films within the matrix of the alloy because of the film formation at the interface of certain microstructures in several alloys at high temperatures (3).

The main factors governing general corrosion are: (i) agitation, (ii) pH of the medium, (iii) temperature, and (iv) protective passive films.

1. The agitation of the medium has a profound influence on the corrosion performance of the metals as agitation accelerates corrosion performance of the metals, accelerates the diffusion of corrosive species, or destroys the passive film mechanically.
2. Low pH (acidic) values accelerate the rate of corrosion as for an active metal such as iron or zinc, the cathodic reaction controls the rate of reaction in accordance with the equation

   The plot of electrode potential against the logarithm of current density gives rise to a Tafel plot shown in Figure 1.2. From this plot, a logarithm of corrosion current density can be obtained. The Evans diagrams obtained by the extrapolation of Tafel slopes for the cathodic and anodic polarization curves shown in Figure 1.2 can also been seen in Figures 1.3 and 1.4. In general, the cathodic Tafel slopes are reproducible and reliable for evaluation of corrosion rates as they represent noncorroded original surface of the metal. It is obvious that the corrosion current is greater in acidic solution. The influence of pH also depends on the composition of the alloy as seen in Figure 1.4. When the zinc is present with mercury amalgam, the corrosion current is lower than when the metal is zinc alone. When zinc is present along with platinum, high corrosion rates are observed as platinum provides effective cathodic sites for hydrogen evolution. In addition to this, the stability of the passive film in acid, neutral, or alkaline pH is a contributing factor. Some examples are the stability of magnesium fluoride in alkaline medium and the amphoteric nature of aluminum oxide in pH of 4-8 solutions.

   Figure 1.2 Theoretical Tafel plots. (Reproduced by permission, ASM International (4).)

   Figure 1.3 Evans diagram for corrosion of zinc as a function of pH. (Reproduced by permission, Elsevier Ltd., (2).)

   Figure 1.4 Evans diagram for corrosion of zinc alloys. (Reproduced by permission, Elsevier Ltd., (2).)

3. The difference in temperature can create a corrosion cell in the case of copper tubes. In general, increase in temperature results in increased corrosion rate. The corrosion rate of steel in acid solutions doubles for an increase of 10 °C between 15 and 70 °C. At temperatures above 70 °C, the solubility of oxygen in aqueous solutions is low, and the rate of reaction cannot be doubled.
4. Protective passive films similar to that of stainless steels result in uniform corrosion because of the mobility of the active sites that passivate readily. Corrosion products and/or passive films are characteristic of numerous electrochemical reactions of the alloys. The film is protective depending on coverage capacity, conductivity, partial pressure, porosity, toughness, hardness, and resistance to chemicals and gases. Rust, oxides of iron, and zinc oxide (white rust) are not protective, while patina (CuO), Al2O3, MgO, and Cr2O3 are protective in certain environments. Corrosion is generally controlled by diffusion of active species through the film.

1.2 GALVANIC CORROSION

When a metal or alloy is electrically coupled to another metal or conducting nonmetal in the same electrolyte, a galvanic cell is formed. The electromotive force and the current of the galvanic cell depend on the properties of the electrolyte and the polarization characteristics of the anodic and the cathodic reactions. Galvanic corrosion is caused by the contact of two metals or conductors with different potentials. The galvanic corrosion is also called as dissimilar metallic corrosion or bimetallic corrosion where the metal is the conductor material.

Galvanic corrosion can lead to general corrosion, localized corrosion, and sometimes both. Although the dissolution of active metals in acids is because of the numerous galvanic cells on the same metallic surface, it is generally referred to as general corrosion. In less aggressive media such as natural media consisting of dissimilar electrode cells, galvanic corrosion can start as general corrosion that can lead to localized corrosion because of different microstructures or impurities in several cases. Localized galvanic attack depends on the distribution and morphology of metallic phases, solution properties, agitation, and temperature. Localized galvanic corrosion can result in the perforation or failure of the structure.

Galvanic corrosion occurs when two metals with different electrochemical potentials are in contact in the same solution (Figs. 1.5...
