Chapter 1: Soft robotics

Robotics has a subsection called soft robotics, which focuses on the design, control, and construction of robots made of pliable materials, as opposed to rigid connections. This area of robotics is a subfield of robotics. While compared to rigid-bodied robots made from materials such as metals, ceramics, and hard plastics, the compliance of soft robots may enhance their safety when operating in close proximity to people. This is in contrast to rigid-bodied robots.

The objective of the field of soft robotics is to develop and build robots that have physically flexible bodies as well as electrical components. There are occasions when the suppleness is restricted to a certain section of the machine. For instance, robotic arms with stiff bodies may be equipped with soft end effectors so that they can gently grip and move things that have an irregular form or are fragile. The vast majority of mobile robots with rigid bodies also make strategic use of soft components, such as shock-absorbing foot pads or springy joints that can store and release elastic energy. On the other hand, the discipline of soft robotics tends to focus on developing machines that are either mostly or fully made of soft materials. There is a huge amount of untapped potential in robots that are made completely of soft materials. One of the benefits of their flexibility is that it enables them to enter spaces that are inaccessible to bodies with a fixed shape, which may be helpful in situations involving disaster assistance. Additionally, soft robots pose less of a risk when interacting with humans and when deployed inside within the human body.

When it comes to the design of soft robots, nature is frequently looked to as a source of inspiration. This is due to the fact that animals themselves are primarily made up of soft components, and they appear to take advantage of their softness in order to efficiently move through complex environments almost everywhere on Earth.

Because there is a difference in the concentration of solutes in the cytoplasm and the rest of the cell's environment, plant cells have the innate ability to generate hydrostatic pressure (osmotic potential). Ions are able to flow back and forth across the cell membrane, which allows plants to regulate the concentration of the compound. As a result, the plant will adapt to this different level of hydrostatic pressure by altering both its form and its volume. This pressure-derived form development is ideal for soft robotics and may be imitated to generate pressure-adaptive materials via the use of fluid flow. Soft robotics is an emerging field that combines elements of robotics, biology, and computer science. predicts the pace at which the cell volume changes:

is the rate of volume change.

is area of the cell membrane.

is the hydraulic conductivity of the material.

is the change in hydrostatic pressure.

is the change in osmotic potential.

Utilizing this approach, pressure control systems for soft robots have been developed and implemented. These systems are made of soft resins and feature a number of fluid sacs that are separated by membranes that are only partially permeable. Because of the semi-permeability, fluid transmission is possible, which ultimately results in the formation of pressure. This interaction between the movement of fluid and the creation of pressure ultimately results in a change in form and volume.

A strong and precise control over a joint may largely be achieved by the use of compressed hemolymph, which is a technique that is also borrowed from spider movement and can be used to develop similar approaches to hydraulic soft joints.

When it comes to the construction of soft robots, traditional manufacturing processes, such as subtractive procedures like drilling and milling, are of little use since these robots have complicated geometries with malleable bodies. As a result, more sophisticated approaches to the manufacturing process have been devised. The Shape Deposition Manufacturing (SDM) technique, the Smart Composite Microstructure (SCM) method, and 3D multimaterial printing are examples of these technologies. By using this technique, it has been possible to print a broad variety of completely functioning softrobots, some of which are capable of bending, twisting, gripping, and contracting motions. This method gets around some of the problems that are inherent in the more traditional approaches of manufacture, such as the delamination that may occur between bonded sections. Another additive manufacturing technology that generates shape-shifting materials with a shape that can be activated by heat, light, or water. The form may also be photosensitive. In essence, these polymers are able to spontaneously alter structure when exposed to water, light, or heat. Printing light-reactive ink using an ink-jet printer onto a target made of polystyrene allowed for the creation of one example of a material that can change its form.

In order to create response forces, which are required for movement and contact with the surrounding environment, any soft robot has to have an actuation system. Because of the flexible nature of these robots, the soft actuation systems need to be able to move without the usage of stiff materials, such as the bones that are found in organisms or the metal frame that is often found in rigid robots. In spite of this, several control solutions to the soft actuation issue do exist and have been put to use; each of these systems has a unique set of benefits and drawbacks. The following is a list of several examples of control techniques, along with the relevant materials for each approach.

One example of this would be the use of electrostatic force, which might be used in:

Dielectric Elastomer Actuators (DEAs) are shape-shifting devices made of elastomers that are controlled by a high-voltage electric field (example of working DEA).

These actuators are capable of producing significant forces.

have high specific power (W kg-1), create enormous strains (>1000 percent), The smart and reconfigurable materials known as shape memory polymers (SMPs) are an outstanding example of thermal actuators that may be utilized for actuation. These materials also fall under the category of "smart" materials.

When the temperature is raised over a certain point, these materials will "remember" their prior configuration and return to it.

Take, for instance:

crosslinked polymers can be strained at temperatures above their glass-transition (Tg) or melting-transition (Tm) and then cooled down.

In the event that the temperature is raised once more, The tension will be relieved, and the form of the material will return to how it was before it was altered.

Polyurethane is an example of a special-purpose plastic (PU) , teraphthalic acid made with polyethylene (PET), polyethyleneoxide (PEO), in addition to other substances.

Another control method for soft robotic actuation is based on shape memory alloys.

Altering the pressure inside of a flexible tube is the foundation of another kind of control used in the construction of soft robots known as pneumatic artificial muscles. Because of this, it will behave similarly to a muscle, shortening and lengthening as necessary to exert force on the component to which it is linked. Because these muscles are controlled by valves, the robot can keep its form without requiring any further input of energy while still being able to move. However, in order for this approach to operate well, an external supply of compressed air is normally required. The Proportional Integral Derivative controller, sometimes known as PID, is the algorithm that is most frequently used for pneumatic muscles. Tuning the settings of the PID controller allows for the dynamic response of pneumatic muscles to be controlled to varying degrees.

Robots rely heavily on their sensors as one of its most crucial building blocks. It should come as no surprise that the optimum sensors for soft robots are soft sensors. Soft sensors can often monitor deformation, which allows one to infer information about the position or stiffness of the robot.

Some examples of soft sensors include the following:

Soft stretch sensors

Soft bending sensors

Soft pressure sensors

Soft force sensors

Measurements of the following are used by these sensors:

Piezoresistivity:polymer consisting of conductive particles that are filled, microfluidic pathways (liquid metal,), Piezoelectricity, Capacitance, Magnetic fields as well as

Optical loss, Loss of acoustic quality

After then, the results of these measurements may be input into a control system.

There is potential for the use of soft robotics in the medical field, particularly in invasive surgical procedures. Because of their ability to change form, soft robots may be manufactured to help in surgical procedures. It is essential for soft robots to be able to modify their shape in order to be able to maneuver around the many structures that are found in the human body. Fluidic actuation is one method that might be used to successfully do this task.

The development of bendable exosuits is another potential use for soft robots.

for the purpose of patient rehabilitation, helping out the senior citizens, or only increasing the user's own physical prowess.

These materials were used by a team from Harvard University to develop an exosuit, which was done so that the wearer may benefit from the added strength that an exosuit provides.

without the drawbacks that are associated with the way that hard materials constrain the natural mobility of a person.

The exosuits are metal...
