Preface

Emmanuel PROUFF1, Guénaël RENAULT2, Matthieu RIVAIN3 and Colin O'FLYNN4,5

1LIP6, Sorbonne Université, Paris, France

2Agence nationale de la sécurité des systèmes d'information, Paris, France

3CryptoExperts, Paris, France

4Dalhousie University, Halifax, Canada

5NewAE Technology Inc, Halifax, Canadas

The idea for this project was born during a discussion with Damien Vergnaud. Damien had been asked to propose a series of volumes covering the different domains of modern cryptography for the SCIENCES series. He offered us the opportunity to take charge of the Embedded Cryptography books, which sounded like a great challenge to take on. In particular, we thought it was perfectly timely as the field was gaining increasing importance with the growing development of complex mobile systems and the internet of things.

The field of embedded cryptography, as a research domain, was born in the mid-1990s. Until that time, the evaluation of a cryptosystem and the underlying attacker model were usually agnostic of implementation aspects whether the cryptosystem was deployed on a computer or on some embedded hardware like a smart card. Indeed, the attacker was assumed to have no other information than the final results of a computation and, possibly, the corresponding inputs. In this black-box context, defining a cryptanalytic attack and evaluating resistance to it essentially consisted of finding flaws in the abstract definition of the cryptosystem.

In the 1990s, teams of researchers published the first academic results highlighting very effective means of attack against embedded systems. These attacks were based on the observation that a system's behavior during a computation strongly depends on the values of the data manipulated (which was previously known and exploited by intelligence services). Consequently, a device performing cryptographic computation does not behave like a black box whose inputs and outputs are the only known factors. The power consumption of the device, its electromagnetic radiation and its running time are indeed other sources that provide the observer with information on the intermediate results of the computation. Teams of researchers have also shown that it was possible to disrupt a computation using external energy sources such as lasers or electromagnetic pulses.

Among these so-called physical attacks, two main families emerge. The first gathers the (passive) side-channel attacks, including timing attacks proposed by Kocher in 1996 and power analysis attacks proposed by Kocher et al. in 1999, as well as the microarchitectural attacks that have considerably developed after the publication of the Spectre and Meltdown attacks in 2018. This first family of attacks focuses on the impact that the data manipulated by the system have on measurable physical quantities such as time, current consumption or energy dissipation related to state changes in memories. The second family gathers the (active) fault injection attacks, whose first principles were introduced by Boneh et al. in 1997. These attacks aim to put the targeted system into an abnormal state of functioning. They consist, for example, of ensuring that certain parts of a code are not executed or that operations are replaced by others. Using attacks from either of these families, an adversary might learn sensitive information by exploiting the physical leakage or the faulted output of the system.

Since their inception, side-channel attacks and fault injection attacks, along with their countermeasures, have significantly evolved. Initially, the embedded systems industry and a limited number of academic labs responded with ad-hoc countermeasures. Given the urgency of responding to the newly published attacks, these countermeasures were reasonably adequate at the time. Subsequently, the invalidation of many of these countermeasures and the increasing sophistication of attack techniques highlighted the need for a more formalized approach to security in embedded cryptography. A community was born from this observation in the late 1990s and gathered around a dedicated conference known as cryptographic hardware and embedded systems (CHES). Since then, the growth of this research domain has been very significant, resulting from the strong stake of the industrial players and the scientific interest of the open security issues. Nowadays, physical attacks involve state-of-the-art equipment capable of targeting nanoscale technologies used in the semiconductor industry. The attackers routinely use advanced statistical analyses or signal processing, while the defenders designing countermeasures calls on concepts from algebra, probability theory, or formal methods. More recently, and notably with the publication of the Spectre and Meltdown attacks, side-channel attacks have extended to so-called microarchitectural attacks, exploiting very common optimization techniques in modern CPUs such as out-of-order execution or speculative execution. Twenty-five years after the foundational work, there is now a large community of academic and industrial scientists dedicated to these problems. Embedded cryptography has gradually become a classic topic in cryptography and computer security, as illustrated by the increasing importance of this field in major cryptography and security conferences besides CHES, such as CRYPTO, Eurocrypt, Asiacrypt, Usenix Security, IEEE S&P or ACM CCS.

Pedagogical material

For this work, it seemed important to us to have both scientifically ambitious and pedagogical content. We indeed wanted this book to appeal not only to researchers in embedded cryptography but also to Master's students interested in the subject and curious to take their first steps. It was also important to us that the concepts and notions developed in the book be as illustrated as possible and therefore accompanied by a pedagogical base. In addition to the numerous illustrations proposed in the chapters, we have made pedagogical material available (attack scripts, implementation examples, etc.) to test and deepen the various concepts. These can be found on the following GitHub organization: https://github.com/embeddedcryptobook.

Content

This book provides a comprehensive exploration of embedded cryptography. It comprises 40 chapters grouped into nine main parts, and spanning three volumes. The book primarily addresses side-channel and fault injection attacks as well as their countermeasures. Part 1 of Volume 1 is dedicated to Software Side-Channel Attacks, namely, timing attacks and microarchitectural attacks, primarily affecting software; whereas Part 2 is dedicated to Hardware Side-Channel Attacks, which exploit hardware physical leakages, like power consumption and electromagnetic emanations. Part 3 focuses on the second crucial family of physical attacks against embedded systems, namely, Fault Injection Attacks.

A full part of the book is dedicated to Masking in Part 1 of Volume 2, which is a widely used countermeasure against side-channel attacks and which has become an important research topic since their introduction in 1999. This part covers a variety of masking techniques, their security proofs and their formal verification. Besides general masking techniques, efficient and secure embedded cryptographic implementations are very dependent on the underlying algorithm. Consequently, Part 2, Cryptographic Implementations, is dedicated to the implementation of specific cryptographic algorithm families, namely, AES, RSA, ECC and post-quantum cryptography. This part also covers hardware acceleration and constant-time implementations. Secure embedded cryptography needs to rely on secure hardware and secure randomness generation. In cases where hardware alone is insufficient for security, we must rely on additional software techniques to protect cryptographic keys. The latter is known as white-box cryptography. The next three parts of the book address those aspects. Part 3, Volume 2, Hardware Security, covers invasive attacks, hardware countermeasures and physically unclonable functions (PUF).

Part 1 of this volume is dedicated to White-Box Cryptography: it covers general concepts, practical attack tools, automatic (gray-box) attacks and countermeasures as well as code obfuscation, which is often considered as a complementary measure to white-box cryptography. Part 2 is dedicated to Randomness and Key Generation in embedded cryptography. It covers both true and pseudo randomness generation as well as randomness generation for specific cryptographic algorithms (prime numbers for RSA, random nonces for ECC signatures and random errors for post-quantum schemes).

Finally, we wanted to include concrete examples of real-world attacks against embedded cryptosystems. The final part of this series of books contains those examples of Real World Applications. While not exhaustive, we selected representative examples illustrating the practical exploitation of the attacks presented in this book, hence demonstrating the necessity of the science of embedded cryptography.

Acknowledgments

This series of books results from a collaborative work and many persons from the embedded cryptography community have contributed to its development. We have tried to cover (as broadly as possible) the field of embedded cryptography and the many research directions related to this field. This has not been an easy task given the dynamism and growth of the field over the past...
