In this book, the author has presented an introduction to the practical application of some of the essential technical topics related to computer-aided engineering (CAE). These topics include interactive computer graphics (ICG), computer-aided design (CAD), computer and computer-integrated manufacturing (CIM). aided analysis (CAA) Unlike the few texts available, the present work attempts to bring all these seemingly specialised topics together and to demonstrate their integration in the design process through practical applications to real engineering problems and case studies. This book is the result of the author's research and teaching activities for several years of postgraduate and undergraduate courses in mechanical design of rotating machinery, computer-aided engineering, of finite elements, solid mechanics, engineering practical applications and properties of materials at Cranfield Institute of dynamics Technology, Oxford Engineering Science and the University of Manchester Institute of Science and Technology (UMIST). It was soon realised that no books on the most powerful and versatile tools available to engineering designers existed. To satisfy this developing need, this book, on the use of computers to aid the design process and to integrate design, analysis and manufacture, was prepared.
Sprache
Verlagsort
Verlagsgruppe
Illustrationen
Dateigröße
ISBN-13
978-94-009-3409-2 (9789400934092)
DOI
10.1007/978-94-009-3409-2
Schweitzer Klassifikation
1 Introduction.- 1.1 The Developing Design Process.- 1.2 Design Methodology.- 1.3 Interactive Computer Graphics (ICG).- 1.4 Computer-Aided Engineering (CAE).- 1.4.1 Computer-Aided Design (CAD).- 1.4.2 Computer-Aided Analysis (CAA).- 1.4.3 Computer-Aided Draughting (CAD).- 1.4.4 Computer-Integrated Manufacturing (CIM).- 1.5 Initial Graphics Exchange Specification (IGES).- References.- 2 Three-Dimensional Automated Modelling.- 2.1 Automated Computer Graphics.- 2.2 Different Types of Modelling.- 2.2.1 Wire-Frame Modelling.- 2.2.2 Surface Modelling.- 2.2.3 Solid Modelling.- 2.3 Merits of Solid Modelling.- 2.4 Limitations of Solid Modelling.- References.- 3 Computer-Aided Design.- 3.1 Introduction.- First Case Study: Computer-Aided Design of Centrifugal Shot-Peening Equipment.- 3.2 The Shot-Peening Process.- 3.3 Historical Background.- 3.4 Design Constraints and Requirements.- 3.5 Conceptual Designs.- Second Case Study: Computer-Aided Design of a Fluid Coupling.- 3.6 Principle of Operation.- 3.7 Design Constraints and Requirements.- 3.8 Flow Models and Analysis.- 3.9 Conceptual Design.- 3.10 Evaluation of Coupling Design.- 3.11 Modified Design.- 3.12 The Need for Engineering Analysis.- References.- 4 Fundamentals of the Finite Element Method.- 4.1 Introduction.- 4.2 Fundamental Concept of the Finite Element Method.- 4.3 Fundamentals of Linear Elasticity.- 4.4 Principles of Finite Elements.- 4.5 Interpolation Polynomial Functions.- 4.6 Isoparametric Finite Element Representation.- 4.7 Derivation of a General Expression for Element Stiffness Matrix.- 4.8 Computer Implementation of Finite Element.- 4.8.3 Element Stiffness Matrix Generation and Assembly.- 4.9 Conclusions.- References.- 5 Computer-Aided Analysis.- 5.1 Introduction.- 5.2 General Purpose Finite Element Software.- 5.3 Computer-Aided System for Data Processing.- 5.4 Interactive Mesh Generation.- 5.5 Non-Linear Structural Analysis.- First Case Study: Computer-Aided Analysis of Wheel- Assembly.- 5.6 Structural Stress Analysis.- 5.7 Dynamic Response Studies.- Second Case Study: Computer-Aided Analysis of Fluid Coupling.- 5.8 Structural Stress Analysis and Dynamic Response Studies.- 5.9 Conclusions.- References.- 6 Computer-Integrated Manufacturing.- 6.1 Computer-Controlled Machine Tools.- 6.2 Types of Control Systems for NC Machines.- 6.3 NC Part-Programming Languages.- 6.4 NC Programming with Interactive Graphics.- 6.5 Tool Path Generation.- First Case Study: Computer-Integrated Manufacturing of Critical Components of Wheel-Assembly.- 6.6 Choice of Materials.- 6.7 Manufacture of Wheel-Assembly.- 6.8 Development of NC Machining Programs.- Second Case Study: Computer-Integrated Manufacturing of Fluid Coupling.- 6.9 Choice of Materials and NC Machining Programs.- 6.10 Concluding Remarks.- References.
