Heat Transfer 4

Preface ix

Introduction xi

List of Notations xix

Chapter 1 Concepts of Gas-Liquid Flows 1

1.1 Introduction and basic concepts 1

1.2 Gas-liquid flows 2

1.2.1 The physics of two-phase flows 3

1.2.2 Classification of flows 16

1.2.3 Topologies of a heated vertical flow 23

1.2.4 Calculation of fluxes 27

1.3 Dispersed phase flows: mists and sprays 35

1.3.1 Mist 35

1.3.2 Spray generation 37

1.3.3 Spray characterization: particle sizing 38

1.3.4 Spray vaporization: the case of the isolated drop 42

1.4 Several examples 43

Chapter 2 Convection of Species 63

2.1 Introduction 63

2.2 Characterization of a mixture: definitions 63

2.3 Law of diffusive transfer: Fick's law 64

2.4 Similarity of transport equations 66

2.5 Solving the equations of diffusive transport 69

2.5.1 Analogies 69

2.5.2 Non-reactive boundary layer: concentration fixed at the wall 71

2.5.3 Non-reactive boundary layer: wall catalysis 73

2.5.4 Reactive boundary layer 79

Chapter 3 Phase Change Materials 81

3.1 Introduction 81

3.2 PCM for cooling mechatronics devices 84

3.2.1 Description of heat transfer and PCM behavior 85

3.2.2 PCM behavior 87

3.3 Numerical model 88

3.3.1 Description of the 3D model 88

3.3.2 Heat sink without PCMs 90

3.3.3 Heat sink with PCMs 91

3.4 Conclusion 95

Chapter 4 Electro-Thermo-Mechanical Modeling of Systems 97

4.1 Introduction 97

4.2 Theory of electro-thermo-mechanical coupling 98

4.2.1 Electro-thermal phenomena 98

4.2.2 Numerical formulation of the electro-thermo-mechanical coupling 100

4.3 Finite element simulation of the electro-thermo-mechanical behavior 103

4.3.1 Strong coupling of the electro-thermo-mechanical modeling 104

4.3.2 Weak coupling of the electro-thermo-mechanical modeling 105

4.4 Example of electro-thermo-mechanical simulation of an HBT transistor 105

4.4.1 Global model of HPA 106

4.4.2 Local model of an HBT transistor 110

4.5 Modal analysis of mechatronic components 113

4.5.1 Writing the equation of the vibration problem 113

4.5.2 Variational formulation 115

4.5.3 Finite element approximation 115

4.5.4 Resolution in the frequency domain 117

4.6 Stochastic modal analysis of mechatronics components 118

4.7. Numerical identification of the elastic parameters of electronic components 119

4.8 Example of modeling and simulation of the vibratory behavior of mechatronic components 120

4.9 Conclusion 127

Appendices 129

Appendix 1 Physical Properties of Common Fluids 131

Appendix 2 Physical Properties of Common Solids 133

Appendix 3 Thermodynamic Properties of Water Vapor 137

Appendix 4 Table of Functions: erf (x) erfc(x) and ierfc(x) 141

References 143

Index 151
