Introduction

1.1 Introduction

Fluid machinery is classified as those devices that transform fluid energy to shaft work or vice versa. The history of fluid machinery is long and the design technology of fluid machinery has developed with the development of fluid mechanics. Although the exact governing equations for single phase Newtonian viscous fluid, that is, the Navier-Stokes equations, were derived in middle of the nineteenth century, various approximate analysis methods, such as those with inviscid assumptions, were still used in the analysis of fluid flow before the Navier-Stokes equations were practically solved by numerical analysis using electronic computers more than a hundred years later. Thereafter, owing to the rapid development of computers, computational fluid dynamics (), which solves the governing differential equations, becomes practical in the analysis of fluid flow.

Due to the complexity of the flow path in fluid machinery, application of three-dimensional (3D) CFD to the aerodynamic or hydrodynamic analysis of fluid machinery was somewhat delayed, but recently, CFD has been widely used in the analysis and design of fluid machinery. In the early stages, CFD was only used in the analysis of flow fields in fluid machinery due to the long computing time. But, continuous enhancement in computing power made the design optimization of fluid machinery using CFD practical. Thus, now CFD is utilized not only in the analysis of the flow in fluid machinery, but also in design through systematic optimization algorithms. However, instead of replacing the conventional design methods of fluid machinery, design optimization using CFD is being used as a supplementary design due to excessive computing times when it is used for the entire design of a fluid machine.

A typical design procedure recommended for the design of fluid machinery using CFD is as follows; a preliminary design using an approximate analysis method to determine a basic model of the fluid machine considered, a parametric study using 3D CFD to find the sensitivities of performance parameters on some selected geometric/operational parameters, and single- or multi-objective design optimization of the fluid machine using the design variables selected through parametric study. The design optimization requires repeated evaluations of the objective function(s), which is selected among the performance parameters of the fluid machine, and the number of objective function evaluations depends on the number of design variables and the optimization algorithm employed. An increase in the number of design variables in an optimization is generally expected to improve the results of the optimization, but the number of design variables for optimization is restricted mainly by the computational time. Therefore, design optimization could become more popular in fluid machinery design if computing power is further enhanced.

1.2 Fluid Machinery: Classification and Characteristics

The fluid machines that transform fluid energy to shaft work are called turbines; more specifically, gas, steam, wind, and hydraulic turbines, depending on the working fluid. The other group of fluid machines that transform shaft work to fluid energy includes pumps, fans, blowers, and compressors. All the machines in this group using liquids are called pumps. But, if gases are used for the work, machines in this group are divided into fans, blowers, and compressors, depending on the magnitude of pressure rise.

Fluid machinery is also divided into two categories; turbomachinery and positive displacement fluid machinery. In turbomachinery, rotating blades (rotors) perform continuous energy transfer from or to the fluid flow passing through the blade passages. However, in positive displacement fluid machinery, there is a displacement of a certain amount of working fluid without relative motion between the fluid and moving part of the machine in rotating or reciprocating motion. In other words, the working fluid does not flow in certain parts of these machines. The following sections in this chapter are mostly concerned with turbomachinery.

Turbomachinery can be also categorized according to the change in the flow direction through the impeller as shown in Figure 1.1. If the flow direction does not change through the impeller, those machines are called axial flow turbomachines. Machines where the flow direction changes perpendicularly through the impeller are called radial flow (or centrifugal) turbomachines. If the change in flow direction is neither axial nor radial, the machines are called mixed flow turbomachines. Also, the rotors of turbomachinery may be enclosed in a casing or exposed to the environment without. Most turbomachines belong to the former group of enclosed turbomachines, but some, such as the wind turbine, prop fan, and ship propeller, belong to the latter group of extended turbomachines.

Figure 1.1 Classification of turbomachinery types. Source:

Reprinted from Lakshminarayana 1996 (Figure 1.1 from original source), © 1996, with the permission of John Wiley & Sons, Inc.

An important flow phenomenon found only in fluid machinery employing liquid as the working fluid is cavitation, which indicates generation of gas bubbles at normal temperature of operation due to a decrease in the local static pressure. In pumps or hydraulic turbines, cavitation occurs by the rotating blades that cause low local pressure. Repeated breaking down of bubbles near the solid wall induces erosion damage and also noise. Thus, cavitation is an important factor to be considered in the design of hydraulic machinery. On the other hand, in fluid machines that use gas as a working fluid and operate at high speed, the compressibility of gas causes unique flow phenomena such as shock waves that are not found in hydraulic machinery.

A typical parameter, which is used to classify various types of turbomachinery, is specific speed. The specific speed is defined as a non-dimensional parameter combining operating parameters of turbomachinery as follows;

Constant specific speed indicates the flow conditions that are similar in geometrically similar turbomachinery. However, if the gravitational acceleration, g, is assumed constant, the parameter becomes a dimensional parameter, NQ1/2/(?H)3/4. The specific speed, Ns is the most important parameter in turbomachinery that can be used in the selection of turbomachinery type as shown in Figure 1.1 . The range of specific speeds for a specified type of turbomachinery shown in Figure 1.2 indicates the range where the turbomachine type shows maximum efficiency.

Figure 1.2 Specific speed suitability ranges of various designs. Source:.

Csanady 1964

1.3 Analysis of Fluid Machinery

Analysis of turbomachinery should involve the analyses in a variety of fields; fluid mechanics, thermodynamics, solid mechanics, rotor dynamics, acoustics, material science, mechanical control, manufacturing, and so on. However, aerodynamic/hydrodynamic performance is essential in the evaluation of the basic performance of turbomachinery. Since it is difficult to include all the analyses here, only aerodynamic/hydrodynamic analysis and design methods are introduced in this chapter.

The history of turbomachinery is quite long. For example, waterwheels have been utilized by human beings for several thousands of years. The design of such ancient fluid machines was required even before the basic theory of fluid dynamics was set up. Therefore, the analysis method of fluid machinery was developed with the development of fluid mechanics. Until the numerical calculation of 3D Navier-Stokes equations became possible by using electronic computers in the middle of the twentieth century, analysis of turbomachinery was based on various approximate fluid mechanical theories as shown in Table 1.1. Analysis using inviscid equations and one-dimensional analysis using empirical formulas for energy losses are typical examples of such approximate analysis. Thus, many simple design methods based on these approximate analyses have developed over a long time, but the rapid development of electronic computers since the late twentieth century makes the numerical calculation of full Navier-Stokes equations practical. And, recently, 3D CFD has even become popular in the analysis of turbomachinery.

Table 1.1 Various approximations for flow analysis.
