From the System to the Software
1.1. Introduction
The automation of numerous command systems (in railways, the aeronautics, automotive, nuclear industries, etc.) and/or process control systems (production, etc.), and the replacement of logical or analog systems involving little interaction by highly-integrated systems, have led to a considerable expansion of the domain of functional safety, taking account of the features and peculiarities of computer systems.
Dependability relates to applications for which it is crucial to ensure a continuous good level of service (reliability), because human lives are at stake (transport, nuclear energy, etc.), because of the high level of investment which would be lost were the calculation to go wrong (space, chemical production process, etc.), or indeed because of the cost of the problems that could be caused by failure (e.g. in the banking process, reliability of the transport network, etc.). It should be noted that for several years, account has been taken of the environmental impacts (e.g. with accidental spills of chemical products into the environment, impact on ecosystems, recycling, etc.).
Since the very beginning of research into such systems, the problems linked to validation of those systems have been at the heart of designers' concerns: it is useful to prove the mechanisms to react to the occurrence of failures are well designed, to check that design (by means of simulations, tests, evidence, etc.) and convincingly estimate projected, meaningful values measuring the performances of the functional safety devices.
The difficulty then lies in accurately identifying the various actors involved in the process (users, operators, managers, maintenance personnel, service providers, assessors, authorities, etc.), the different elements in the system, the interactions between those elements, the interactions with the users and the factors which have an impact on the operational safety, ultimately with identification of the electronic and/or programmable elements.
The aim of this first chapter is to offer an examination of the software in the context in which it is used, which is a system, and recap on the links and the constraints which need to be taken into account in creating software.
1.2. Command/control system
Figure 1.1 1 shows an example of a railway system. The Operation Control Center (OCC - photo a) controls the whole of the line and passes operational commands to the trains and to the signaling management system (photo c shows a manual operation control center).
Figure 1.1. The system in its environment2
The operation control center3 sends commands to the ground via a set of relays (photo d shows an example of a room containing the relays linked to the signaling system). In response to the commands, the ground equipment adopts the desired behavior (in photo e, we can see maneuver signals).
Figure 1.1 demonstrates the complexity associated with the concrete system, and highlights the point that a complex system is based not on one piece of software, but on many. Each of these software programs is associated with safety objectives which likely differ from one program to another.
The software involved in supervision does not have as much impact on people's safety as does the software relating to automated control of the trains. For this reason, in the context of systems requiring certification (aeronautics, railways, the nuclear sector, systems based on programmable electronics, etc.), we assign a given level of safety to each software application.4
This level of safety is associated with a scale, ranging from "non-critical" to "highly critical". The concept of safety assurance levels and the scales associated therein will be presented in Chapters 2 and 3.
Figure 1.2. The system in its environment
Figure 1.2 highlights the fact that the system being constructed is closely linked with an environment which responds to the commands issued by the system. It is therefore necessary to acquire a view of the state of the process to be controlled and to have a means of command which is capable of relaying the commands to the environment. The environment may be composed of physical elements, but as a general rule, there are interactions with human parties (operators, users, maintenance personnel, etc.).
During the requirements analysis phase, it is essential to clearly identify all the actors (operators, maintenance personnel, customers, etc.) and identify all the devices which interact with the system. The requirements analysis phase is essential, but can still give rise to numerous omissions and misunderstandings.
Figure 1.3. Example of modeling of the system in its environment
Figure 1.3 presents an example of the modeling of a system to control a level crossing. This system can control the intersection of at least one road with a railway track. This system interacts with various actors (both human and machine): an OCC (as shown in the Figure 1.1), the road users (trucks, cars, etc.), railway users and operators in charge of operation and/or maintenance.
We have chosen to construct a class diagram which models the fact that the decentralized level-crossing management system using a communication system (DRBCS) comprises a level crossing which is itself made up of a railway and a roadway.
The important point in Figure 1.3 lies in identifying the actors which interact with the management system, including the road users, the trains, the OCC and especially the maintenance operators or other personnel (whom the model identifies as "special people").
It is crucial to identify all the actors involved at system level; otherwise there is a risk of forgetting actions - e.g. maintenance activities - but it is also possible to overlook disturbances or malfunctions. We can point to the classic example5 of the efficiency of a Wi-Fi network, which may correlate to the density of auxiliary networks connected to the system.
Hereinafter, we shall not discuss how to deal with the human factor, because whilst the human factor is an essential one, it does not directly relate to the critical software-based equipment, except for:
- - the activities of creation of the software application - hence the need to formalize the skills and responsibilities of the people in charge of the software, as indicated in Chapter 5 of the standard;
- - the activities of maintenance and rollout, which are dealt with by Chapter 9 of CENELEC 50128:2011 [CEN 11a].
As regards the identification of the actors involved, it is more usual to speak of identification of the stakeholders; for further information, see Chapter 11 of [BOU 14c].
1.3. System
Our aim in this section is to lay down the vocabulary relating to the creation of a software-based device. To begin with, we must remember that a software application is directly linked to a device, and that without hardware architecture, there can be no software. Indeed, the validation of a program (see Chapter 5) requires the hardware architecture, and the results are applicable only to that particular hardware. For this reason, the first definitions we shall give relate to the concept of a system and of a software-based system.
DEFINITION 1.1 (System).- A system is a set of elements interacting with one another, which is organized in such a way as to achieve one or more predetermined results.
The "organized" part of Definition 1.1 can be seen in the system's organization into different levels, as illustrated by Figure 1.4.
Figure 1.4. From the system to the software
Figure 1.4 offers a hierarchical view of the system. This is the view which is used in the railway domain. Hence, a railway line is viewed as a system, which is divided into a number of subsystems: the signaling control subsystem, the passenger transfer subsystem, etc. The signaling control subsystem, for its part, is divided into a number of devices, or classes of equipment: onboard equipment, ground equipment and line equipment.
A system performs several functions. A system function can be subdivided into a variety of subsystems, with each subsystem performing functions which are subfunctions of the whole system's functions. At system level, this representation needs to be accompanied by models which illustrate the interactions between the functions, as shown by the example given in Figure 1.5.
Figure 1.5. Example of the subdivision of a system
Figure 1.6. Example of distribution6
Thus, a subsystem hosts a variety of functions, which can then be divided between several different pieces of equipment. A piece of equipment is not a functional element in itself; it must be joined by other equipment in order to perform a subsystem-level function.
In terms of a railway system, the difficulty lies in the fact that a train is home to many system functions, and therefore that it contains equipment which contributes to these different functions. For example, the installation of an auto-pilot subsystem involves installing...
