Chapter 1

Fundamentals of Drug Delivery

Rebecca A. Bader

Syracuse Biomaterials Institute, Syracuse University, Syracuse, NY, USA

1.1 Introduction: History and Future of Drug Delivery

As depicted in Fig. 1.1, as drug discovery has evolved, the need for innovate methods to effectively deliver therapeutics has risen. In the early 1900s, there began a shift away from the traditional herbal remedies characteristic of the “age of botanicals” toward a more modern approach based on developments in synthetic chemistry [1, 2]. Through the 1940s, drug discovery needs were directed by the needs of the military, that is, antibiotics were developed and produced to treat injured soldiers [3]. As more pharmaceuticals were rapidly identified by biologists and chemists alike, people became more cognizant of the impact therapeutics could have on everyday life. During the late 1940s to the early 1950s, drugs were, for the first time, formulated into microcapsules to simplify administration and to facilitate a sustained, controlled therapeutic effect [4]. For example, Spansules®, microcapsules containing drug pellets surrounded by coatings of variable thickness to prolong release, were developed by Smith Kline and French Laboratories and rapidly approved for use [5]. Many of these early microencapsulation techniques, particularly the Wurster process, whereby drug cores are spray coated with a polymer shell, are still in use today [6, 7].

Figure 1.1 Drug delivery (a) and drug discovery (b) have followed similar trajectories with the need for drug delivery rising with the identification of new therapeutic compounds.

Although a number of advanced methods for controlled and/or targeted drug delivery were proposed in the 1960s, building on the conventional drug delivery method of microencapsulation, these techniques were not fully implemented until the 1970s [8, 9]. During this decade, biotechnology and molecular biology began to play a significant role in the drug discovery process, culminating in an increased understanding of the etiology of numerous diseases and the development of protein-based therapeutics. Likewise, computer screening, predictive software, combinatorial chemistry, and high throughput screening significantly accelerated the rate at which lead compounds for new therapeutic compounds could be identified [1, 4]. As is discussed further in Chapter 2, drug carrier systems, such as implants, coatings, micelles, liposomes, and polymer conjugates, were proposed to address the growing need to deliver the newly identified therapeutic compounds with maximum efficacy and minimal risk of negative side effects [8, 9] (Fig. 1.2).

Figure 1.2 The temporal and spatial distribution of drugs is impacted by absorption, distribution, metabolism, and excretion (ADME).

In sum, over time, as technology has advanced for drug discovery, there has been a paradigm shift in drug delivery from simplifying the administration of old drugs to creating systems that can make new drugs work. This is particularly true as we continue to identify and develop therapeutics based on proteins and nucleic acids that are difficult to administer in a patient-friendly manner and/or with the necessary site-specificity to reverse adverse consequences. However, as drug delivery technology has advanced for new drugs, many of the old drugs have likewise benefited through increased predictability of pharmacokinetic/pharmacodynamic profiles, decreased side effects, and enhanced efficacy. This text is intended to explain how these advanced drug delivery techniques, particularly those related to the application of polymers, have improved the efficacy of old and new drugs alike. Chapter 1 serves as the foundation for all subsequent chapters, defining the necessary terminology related to drug delivery and pharmaceutics.

1.2 Terminology

1.2.1 Pharmacology

Pharmacology, the science of drugs, is composed of two primary branches, pharmacodynamics and pharmacokinetic. In broad terms, pharmacokinetics refers to what the body does to the drug whereas pharmacodynamics describes what the drug does to the body. In the subsequent sections, a brief overview of these two branches of study are given in order to highlight some of the basic pharmacological terminology frequently encountered in both drug discovery and delivery

1.2.1.1 Pharmacokinetics.

Pharmacokinetics tracks the time course of drugs and drug delivery systems through the body. The processes that impact the temporal and spatial distribution of drugs are absorption, distribution, metabolism, excretion (ADME). Following administration, the drugs are absorbed by the bloodstream, distributed to tissues and organs throughout the body, and eventually eliminated by metabolism or excretion. Although a summary of these processes with associated parameters is provided in Table 1.1, each of these terms are described in further detail in Section 1.3 [10, 11].

Table 1.1 Pharmacokinetic Parameters

Process Parameter Definition Absorption Absorption rate constant () First-order rate constant for absorption Bioavailability () The extent of drug absorption Distribution Plasma drug concentration () The concentration of drug in the plasma Volume of distribution () The mass amount of drug given (dose) divided by the plasma concentration (Cp). Vd is an apparent volume with no direct physiological relevance Unbound fraction The fraction of drug not bound to protein, that is, pharmaceutically active Elimination (metabolism and excretion) Metabolism rate constant () First-order rate constant for elimination by metabolism Excretion rate constant () First-order rate constants for elimination by excretion Elimination rate constant () Extrarenal (metabolic) clearance The volume of plasma cleared of drug per unit time by metabolism Renal clearance The volume of plasma cleared of drug per unit time by metabolism Total clearance Total clearance = renal clearance + extrarenal Clearance Half-life () The time necessary for the plasma drug concentration to be reduced 50%

1.2.1.2 Pharmacodynamics.

Because pharmacodynamics broadly refers to what the drug does to the body, pharmacodynamics measurements involve looking at toxicity, as well as therapeutic efficacy. These measurements frequently involve examining dose–response curves to determine the optimal range over which drugs can be administered with maximum therapeutic impact and minimal negative side effects. Pharmacodynamics also involves examining the mechanism by which drugs act, that is, drug–receptor interactions. Typically, these studies are used to identify the amount of drug necessary to reduce interactions of endogenous agonists with the receptor [12]. These concepts related to pharmacodynamics will be explored in greater detail in Section 1.4.

1.2.2 Routes of Administration

The route by which drugs are administered can have a profound impact on the pharmacokinetic properties given in Table 1.1. One of the goals of drug delivery is to facilitate administration by routes that normally have an adverse impact on the associated therapeutic pharmacokinetic properties. For example, as is discussed further in Chapter 2, effective oral administration of numerous drugs is not feasible because of poor uptake through the mucosal epithelial barrier of the intestine and a low resultant bioavailability. Furthermore, orally administered drugs are subject to what is referred to as the first pass effect, whereby the bioavailability is reduced by metabolism within the liver and/or gut wall. Carrier systems have been designed to (i) increase intercellular transport by disrupting the epithelial barrier, (ii) facilitate intracellular transport through targeting of the absorptive epithelial cells, and/or (iii) reduce the destruction of drugs by liver enzymes [13–16].

The most explored routes of drug administration are summarized in Table 1.2. Although 90% of drugs are administered orally due to convenience and high patient compliance, oral drug delivery is associated with low and/or variable bioavailability as a result of the harsh environment of the gastrointestinal tract and the impermeable nature of the mucosal epithelial barrier. In contrast, parenteral forms of administration (intravenous, subcutaneous, and intramuscular) yield rapid effects and high bioavailability (100% for intravenous); however, patient compliance is extremely low as a result of the discomfort because of the injection. Transdermal delivery is a favorable route of administration because of high patient acceptability and ready access to the site of absorption; however, this method has historically been limited to small, lipophilic drugs that can passively diffuse through the skin barrier [17, 18]. New techniques are currently being developed to extend transdermal delivery to polar and/or macromolecular compounds. For example, ultrasound and iontophoresis provide a driving force for the passage of small,...
