Analog and Mixed-Signal Electronics
Beschreibung
Weitere Details
Weitere Ausgaben
Andere Ausgaben
Person
Karl D. Stephan, PhD, is Professor in the Ingram School of Engineering, Texas State University, USA. Dr Stephan has published six book chapters and over 80 journal and conference papers in the fields of micr wave engineering, atmospheric physics, the history of technology, and engineering ethics.
Inhalt
Preface xi
Acknowledgments xiii
About the Companion Website xv
1 Introduction to Analog and Mixed-Signal Electronics 1
1.1 Introduction 1
1.2 Organization of the Book 3
1.2.1 Chapter 2: Basics of Electronic Components and Devices 3
1.2.2 Chapter 3: Linear System Analysis 3
1.2.3 Chapter 4: Nonlinearities in Analog Electronics 3
1.2.4 Chapter 5: Op Amp Circuits in Analog Electronics 4
1.2.5 Chapter 6: The High-Gain Analog Filter Amplifier 4
1.2.6 Chapter 7: Waveform Generation 4
1.2.7 Chapter 8: Analog-to-Digital and Digital-to-Analog Conversion 4
1.2.8 Chapter 9: Phase-Locked Loops 4
1.2.9 Chapter 10: Power Electronics 5
1.2.10 Chapter 11: High-Frequency (Radio-Frequency) Electronics 5
1.2.11 Chapter 12: Electromagnetic Compatibility 6
Bibliography 6
Problems 6
2 Basics of Electronic Components and Devices 8
2.1 Introduction 8
2.2 Passive Devices 9
2.2.1 Resistors 9
2.2.2 Capacitors 11
2.2.3 Inductors 12
2.2.4 Connectors 13
2.2.5 Antennas 14
2.3 Active Devices 15
2.3.1 Diodes 15
2.3.2 Field-Effect Transistors 17
2.3.3 BJTs 22
2.3.4 Power Devices 24
Bibliography 29
Problems 30
3 Linear Systems Analysis 33
3.1 Basics of Linear Systems 33
3.1.1 Two-Terminal Component Models 34
3.1.2 Two-Port Matrix Analysis 42
3.2 Noise and Linear Systems 48
3.2.1 Sources of Noise 49
3.2.2 Noise in Designs 53
Bibliography 56
Problems 56
Project Problem: Measurement of Inductor Characteristics 59
Equipment and Supplies 59
Description 59
4 Nonlinearities in Analog Electronics 62
4.1 Why All Amplifiers Are Nonlinear 62
4.2 Effects of Small Nonlinearity 63
4.2.1 Second-Order Nonlinearity 63
4.2.2 Third-Order Nonlinearity 67
4.3 Large-Scale Nonlinearity: Clipping 69
4.4 The Big Picture: Dynamic Range 74
Bibliography 76
Problems 76
5 O p Amp Circuits in Analog Electronics 78
5.1 Introduction 78
5.2 The Modern Op Amp 80
5.2.1 Ideal Equivalent-Circuit Model 80
5.2.2 Internal Block Diagram of Typical Op Amp 81
5.2.3 Op Amp Characteristics 85
5.3 Analog Circuits Using Op Amps 88
5.3.1 Linear Op Amp Circuits 92
5.3.2 Nonlinear Op Amp Circuits 105
Bibliography 115
Problems 115
6 The High-Gain Analog Filter Amplifier 124
6.1 Applications of High-Gain Filter Amplifiers 124
6.1.1 Audio-Frequency Applications 125
6.1.2 Sensor Applications 126
6.2 Issues in High-Gain Amplifier Design 130
6.2.1 Dynamic-Range Problems 130
6.2.2 Oscillation Problems 131
6.3 Poles, Zeroes, Transfer Functions, and All That 134
6.4 Passive Analog Filters 137
6.4.1 One-Pole Lowpass Filter 137
6.4.2 One-Pole, One-Zero Highpass Filter 141
6.4.3 Complex-Pole Bandpass Filter 143
6.4.4 Bandstop Filters 149
6.5 Active Analog Filters 149
6.5.1 Sallen-Key Lowpass Filter with Butterworth Response 150
6.5.2 Biquad Filter with Lowpass, Bandpass, or Highpass Response 158
6.5.3 Switched-Capacitor Filters 162
6.6 Design Example: Electric Guitar Preamp 164
Bibliography 169
Problems 169
7 Waveform Generation 175
7.1 Introduction 175
7.2 "Linear" Sine-Wave Oscillators and Stability Analysis 176
7.2.1 Stable and Unstable Circuits: An Example 176
7.2.2 Poles and Stability 180
7.2.3 Nyquist Stability Criterion 181
7.2.4 The Barkhausen Criterion 186
7.2.5 Noise in Oscillators 189
7.3 Types of Feedback-Loop Quasilinear Oscillators 193
7.3.1 R-C Oscillators 195
7.3.2 Quartz-Crystal Resonators and Oscillators 198
7.3.3 MEMS Resonators and Oscillators 202
7.4 Types of Two-State or Relaxation Oscillators 204
7.4.1 Astable Multivibrator 205
7.4.2 555 Timer 207
7.5 Design Aid: Single-Frequency Series-Parallel and Parallel-Series Conversion Formulas 209
7.6 Design Example: BJT Quartz-Crystal Oscillator 211
Bibliography 219
Problems 219
8 Analog-to-Digital and Digital-to-Analog Conversion 225
8.1 Introduction 225
8.2 Analog and Digital Signals 226
8.2.1 Analog Signals and Measurements 226
8.2.2 Accuracy, Precision, and Resolution 227
8.2.3 Digital Signals and Concepts: The Sampling Theorem 230
8.2.4 Signal Measurements and Quantum Limits 234
8.3 Basics of Analog-to-Digital Conversion 235
8.3.1 Quantization Error 235
8.3.2 Output Filtering and Oversampling 237
8.3.3 Resolution and Speed of ADCs 239
8.4 Examples of ADC Circuits 242
8.4.1 Flash Converter 242
8.4.2 Successive-Approximation Converter 244
8.4.3 Delta-Sigma ADC 245
8.4.4 Dual-Slope Integration ADC 250
8.4.5 Other ADC Approaches 252
8.5 Examples of DAC Circuits 253
8.5.1 R-2R Ladder DAC 255
8.5.2 Switched-Capacitor DAC 256
8.5.3 One-Bit DAC 258
8.6 System-Level ADC and DAC Operations 259
Bibliography 262
Problems 262
9 Phase-Locked Loops 269
9.1 Introduction 269
9.2 Basics of PLLs 270
9.3 Control Theory for PLLs 271
9.3.1 First-Order PLL 273
9.3.2 Second-Order PLL 274
9.4 The CD4046B PLL IC 280
9.4.1 Phase Detector 1: Exclusive-OR 280
9.4.2 Phase Detector 2: Charge Pump 282
9.4.3 VCO Circuit 285
9.5 Loop Locking, Tuning, and Related Issues 286
9.6 PLLs in Frequency Synthesizers 288
9.7 Design Example Using CD4046B PLL IC 289
Bibliography 294
Problems 294
10 Power Electronics 298
10.1 Introduction 298
10.2 Applications of Power Electronics 300
10.3 Power Supplies 300
10.3.1 Power-Supply Characteristics and Definitions 300
10.3.2 Primary Power Sources 303
10.3.3 AC-to-DC Conversion in Power Supplies 306
10.3.4 Linear Voltage Regulators for Power Supplies 309
10.3.5 Switching Power Supplies and Regulators 318
10.4 Power Amplifiers 337
10.4.1 Class A Power Amplifier 338
10.4.2 Class B Power Amplifier 346
10.4.3 Class AB Power Amplifier 347
10.4.4 Class D Power Amplifier 355
10.5 Devices for Power Electronics: Speed and Switching Efficiency 360
10.5.1 BJTs 361
10.5.2 Power FETs 361
10.5.3 IGBTs 361
10.5.4 Thyristors 362
10.5.5 Vacuum Tubes 362
Bibliography 363
Problems 363
11 High-Frequency (RF) Electronics 370
11.1 Circuits at Radio Frequencies 370
11.2 RF Ranges and Uses 372
11.3 Special Characteristics of RF Circuits 375
11.4 RF Transmission Lines, Filters, and Impedance-Matching Circuits 376
11.4.1 RF Transmission Lines 376
11.4.2 Filters for Radio-Frequency Interference Prevention 385
11.4.3 Transmitter and Receiver Filters 387
11.4.4 Impedance-Matching Circuits 389
11.5 RF Amplifiers 400
11.5.1 RF Amplifiers for Transmitters 400
11.5.2 RF Amplifiers for Receivers 406
11.6 Other RF Circuits and Systems 416
11.6.1 Mixers 417
11.6.2 Phase Shifters and Modulators 420
11.6.3 RF Switches 423
11.6.4 Oscillators and Multipliers 423
11.6.5 Transducers for Photonics and Other Applications 426
11.6.6 Antennas 428
11.7 RF Design Tools 433
Bibliography 435
Problems 435
12 E lectromagnetic Compatibility 446
12.1 What is Electromagnetic Compatibility? 446
12.2 Types of EMI Problems 448
12.2.1 Communications EMI 448
12.2.2 Noncommunications EMI 453
12.3 Modes of EMI Transfer 454
12.3.1 Conduction 454
12.3.2 Electric Fields (Capacitive EMI) 456
12.3.3 Magnetic Fields (Inductive EMI) 458
12.3.4 Electromagnetic Fields (Radiation EMI) 461
12.4 Ways to Reduce EMI 465
12.4.1 Bypassing and Filtering 465
12.4.2 Grounding 470
12.4.3 Shielding 474
12.5 Designing with EMI and EMC in Mind 479
12.5.1 EMC Regulators and Regulations 479
12.5.2 Including EMC in Designs 479
Bibliography 481
Problems 481
Appendix: Test Equipment for Analog and Mixed-Signal Electronics 489
A.1 Introduction 489
A.2 Laboratory Power Supplies 490
A.3 Digital Volt-Ohm-Milliammeters 492
A.4 Function Generators 494
A.5 Oscilloscopes 496
A.6 Arbitrary Waveform Generators 499
A.7 Other Types of Analog and Mixed-Signal Test Equipment 500
A.7.1 Spectrum Analyzers 500
A.7.2 Logic Analyzers 501
A.7.3 Network Analyzers 501
Index 503
