This second edition of the original volume adds significant new innovations for revolutionizing the processes and methods used in petroleum reservoir simulations. With the advent of shale drilling, hydraulic fracturing, and underbalanced drilling has come a virtual renaissance of scientific methodologies in the oil and gas industry. New ways of thinking are being pioneered, and Dr. Islam and his team have, for years now, been at the forefront of these important changes.
This book clarifies the underlying mathematics and physics behind reservoir simulation and makes it easy to have a range of simulation results along with their respective probability. This makes the risk analysis based on knowledge rather than guess work. The book offers by far the strongest tool for engineers and managers to back up reservoir simulation predictions with real science. The book adds transparency and ease to the process of reservoir simulation in way never witnessed before. Finally, No other book provides readers complete access to the 3D, 3-phase reservoir simulation software that is available with this text.
A must-have for any reservoir engineer or petroleum engineer working upstream, whether in exploration, drilling, or production, this text is also a valuable textbook for advanced students and graduate students in petroleum or chemical engineering departments.
Reihe
Auflage
Sprache
Verlagsort
Verlagsgruppe
Zielgruppe
Produkt-Hinweis
Fadenheftung
Gewebe-Einband
Maße
Höhe: 231 mm
Breite: 155 mm
Dicke: 36 mm
Gewicht
ISBN-13
978-1-119-03851-1 (9781119038511)
Copyright in bibliographic data and cover images is held by Nielsen Book Services Limited or by the publishers or by their respective licensors: all rights reserved.
Schweitzer Klassifikation
M. R. Islam is Professor of Petroleum Engineering at the Civil and Resource Engineering Department of Dalhousie University, Canada. He has over 700 publications to his credit, including 6 books. He is on the editorial boards of several scholarly journals, and, in addition to his teaching duties, he is also director of Emertec Research and Development Ltd. and has been on the boards of a number of companies in North America and overseas./p>
Dr. S. Hossein Mousavizadegan is currently on the faculty of marine technology at the Amirkabir University of Technology in Tehran as an assistant professor, specializing in mathematical and numerical modeling of fluid dynamics.
Dr. Shabbir Mustafiz is a research engineer with the Alberta Research Council in Edmonton, Canada. Shabbir has published over 25 journal papers and has a Ph.D. in Civil Engineering, on the topic of petroleum reservoir simulation, from Dalhousie University and he is the current SPE Scholarship Chair for the Edmonton Section.
Jamal H. Abou-Kassem is Professor of Petroleum Engineering at the UAE U. in the United Arab Emirates, where he has taught since 1993. Abou-Kassem is a coauthor of two textbooks on reservoir simulation and an author or coauthor of numerous technical articles in the areas of reservoir simulation and other petroleum and natural gas-related topics.
