Integrated Passive Component Technology
Published on 24. February 2010
Software
Other digital
450 pages
978-0-471-72293-9 (ISBN)
Description
This is a thorough survey of the state-of-the-art in Integrated Passive Component Technology. Describes the processes available for creating integrated passives, measuring their properties, and applying them. Brings reader up to date in a fast-moving technology. Enables reader to implement the technology into a manufacturing environment. Covers existing and potential technologies for various substrate systems such as FR4, ceramic, and HDI. Describes applications favorable to integrated passives and the economic tradeoffs associated with their implementation.
Reviews / Votes
"...a comprehensive look at the reasons and current challenges...[of integrating] passive devices into board or IC...just the right dose of the math to explain the physics and theory behind the technology." ( IEEE Circuits & Devices Magazine , Jan/Feb 2005) "...an interesting and useful book; I wholeheartedly recommend it."(Circuit World, Vol.30, No. 2003)More details
Language
English
Place of publication
Chicester
United Kingdom
Publishing group
John Wiley and Sons Ltd
Target group
Professional and scholarly
Dimensions
Height: 250 mm
Width: 150 mm
Thickness: 15 mm
Weight
666 gr
ISBN-13
978-0-471-72293-9 (9780471722939)
Copyright in bibliographic data and cover images is held by Nielsen Book Services Limited or by the publishers or by their respective licensors: all rights reserved.
Schweitzer Classification
Persons
RICHARD K. ULRICH, PhD, is a professor of Chemical Engineering at the University of Arkansas at Fayetteville. He is a NEMI committee member, a Visiting Associate Editor for IEEE Transactions on Advanced Packaging, and past chair of the Electrochemical Society's Dielectric Science and Technology Division. LEONARD W. SCHAPER, Jr., Dr Engr Sc, is a professor of Electrical Engineering at the University of Arkansas in Fayetteville. He is a Fellow of both the IEEE and the International Microelectronics and Packaging Society. He chairs the IEEE CPMT Technical Committee on Discrete and Integral Passives.
Content
Contributors. Preface. 1 Introduction ( Richard K. Ulrich ). 1.1 Status and Trends in Discrete Passive Components. 1.2 Definitions and Configurations of Integrated Passives. 1.3 Comparison to Integrated Active Devices. 1.4 Substrates and Interconnect Systems for Integrated Passives. 1.5 Fabrication of Integrated Passives. 1.6 Reasons for Integrating Passive Devices. 1.7 Problems with Integrating Passive Devices. 1.8 Applications for Integrated Passives. 1.9 The Past and Future of Integrated Passives. 1.10 Organization of this Book. References. 2 Characteristics and Performance of Planar Resistors ( Richard K. Ulrich ). 2.1 Performance Parameters. 2.2 Resistance in Electronic Materials. 2.3 Sizing Integrated Resistors. 2.4 Trimming. References. 3 Integrated Resistor Materials and Processes ( Richard K. Ulrich ). 3.1 Single-Component Metals. 3.2 Metal Alloys and Metal-Nonmetal Compounds. 3.3 Semiconductors. 3.4 Cermets. 3.5 Polymer Thick Film. 3.6 Ink Jet Deposition. 3.7 Commercialized Processes. 3.8 Summary. References. 4 Dielectric Materials for Integrated Capacitors ( Richard K. Ulrich ). 4.1 Polarizability and Capacitance. 4.2 Capacitance Density. 4.3 Temperature Effects. 4.4 Frequency and Voltage Effects. 4.5 Aging Effects. 4.6 Composition and Morphology Effects. 4.7 Leakage and Breakdown. 4.8 Dissipation Factor. 4.9 Comparison to EIA Dielectric Classifications. 4.10 Matching Dielectric Materials to Applications. References. 5 Size and Configuration of Integrated Capacitors ( Richard K. Ulrich ). 5.1 Comparison of Integrated and Discrete Areas. 5.2 Layout Options. 5.3 Tolerance. 5.4 Mixed Dielectric Strategies. 5.5 CV Product. 5.6 Maximum Capacitance Density and Breakdown Voltage. References. 6 Processing Integrated Capacitors ( Richard K. Ulrich ). 6.1 Sputtering. 6.2 CVD, PECVD and MOCVD. 6.3 Anodization. 6.4 Sol-Gel and Hydrothermal Ferroelectrics. 6.5 Thin- and Thick-Film Polymers. 6.6 Thick-Film Dielectrics. 6.7 Interlayer Insulation. 6.8 Interdigitated Capacitors. 6.9 Capacitor Plate Materials. 6.10 Trimming Integrated Capacitors. 6.11 Commercialized Integrated Capacitor Technologies. 6.12 Summary. References. 7 Defects and Yield Issues ( Richard K. Ulrich ). 7.1 Causes of Fatal Defects in Integrated Capacitors. 7.2 Measurement of Defect Density. 7.3 Defect Density and System Yield. 7.3.1 Predicting Yield from Defect Density. 7.4 Yield Enhancement Techniques for Capacitors. 7.5 Conclusions. References. 8 Electrical Performance of Integrated Capacitors ( Richard K. Ulrich and Leonard W. Schaper ). 8.1 Modeling Ideal Passives. 8.2 Modeling Real Capacitors. 8.3 Electrical Performance of Discrete and Integrated Capacitors. 8.4 Dissipation Factor of Real Capacitors. 8.5 Measurement of Capacitor Properties. 8.6 Summary. References. 9 Decoupling ( Leonard W. Schaper ). 9.1 Power Distribution. 9.2 Decoupling with Discrete Capacitors. 9.3 Decoupling with Integrated Capacitors. 9.4 Dielectrics and Configurations for Integrated Decoupling. 9.5 Integrated Decoupling as an Entry Application. References. 10 Integrated Inductors ( Geert J. Carchon and Walter De Raedt ). 10.1 Introduction. 10.2 Inductor Behavior and Performance Parameters. 10.3 Inductor Performance Prediction. 10.4 Integrated Inductor Examples. 10.5 Use of Inductors in Circuits: Examples. 10.6 Conclusions. Acknowledgments. References. 11 Modeling of Integrated Inductors and Resistors for Microwave Applications ( Zhenwen Wang, M. Jamal Deen, and A. H. Rahal ). 11.1 Introduction. 11.2 Modeling of Spiral Inductors. 11.3 Modeling of Thin-Film Resistors. 11.4 Conclusions. References. Appendix: Characteristics of Microscript Lines. 12 Other Applications and Integration Technologies ( Elizabeth Logan, Geert J. Carchon, Walter De Raedt, Richard K. Ulrich, and Leonard W. Schaper ). 12.1 Demonstration Devices Fabricated with Integrated Passives. 12.2 Commercialized Thin-Film Build-Up Integrated Passives. 12.3 Other Integrated Passive Technologies. 12.4 Summary. Acknowledgments. References. 13 The Economics of Embedded Passives ( Peter A. Sandborn ). 13.1 Introduction. 13.2 Modeling Embedded Passive Economics. 13.3 Key Aspects of Modeling Embedded Passive Costs. 13.4 Example Case Studies. 13.5 Summary. Acknowledgments. References. 14 The Future of Integrated Passives ( Richard K. Ulrich ). 14.1 Status of Passive Integration. 14.2 Issues for Implementation on Organic Substrates. 14.3 Progress on Board-Level Implementation. 14.4 Three Ways In for Organic Boards. 14.5 Conclusion. Index. About the Editors.
