DESIGN OF NEW GRADIENT CEMENTED CARBIDES AND HARD COATINGS THROUGH CERAMIC GENOME
Weibin Zhanga, Yong Dua,*, Li Chena, Yingbiao Penga, Peng Zhoua, Weimin Chena, Kaiming Chenga, Lijun Zhanga, Wen Xieb, Guanghua Wenb, and Shequan Wangb
a State Key Lab of Powder Metallurgy, Central South University, Hunan, 410083, China
b Zhuzhou cemented carbide cutting tools limited company, Zhuzhou, Hunan, 412007, China
ABSTRACT
The concept of ceramic genome is briefly introduced, and its combination with CALPHAD (CALculation of PHAse Diagrams) method is a powerful tool for materials process optimization and alloy design. The quality of CALPHAD-type calculations is strongly dependent on the quality of the thermodynamic and diffusivity databases. The development of thermodynamic and diffusivity databases for cemented carbides is described. Several gradient cemented carbides sintered under vacuum and various partial pressures of N2 have been studied via experiment and simulation. Examples of ceramic genome applications in design and manufacture for different kinds of cemented carbides are shown using the databases and comparing where possible against experimental data, thereby validating their accuracies. Metastable Ti-Al-N coatings have been well acknowledged as protective layer for industrial applications due to their excellent mechanical, chemical and thermal properties. Here, we study the effect of Zr addition on structure and thermal properties of Ti1-xAlxN based coatings under the guidance of ab initio calculations. The preparation of Ti1-x-zAlxZrzN by magnetron sputtering verifies the suggested cubic (NaCl-type) structure for x below 0.6–0.7 and z ≤ 0.4. Alloying with Zr also promotes the formation of cubic domains but retards the formation of stable wurtzite AlN during thermal annealing.
INTRODUCTION
Cemented carbides have long been used in applications such as cutting, grinding, and drilling1. Cemented carbides2 are hard and tough tool materials consisting of micrometer-sized tungsten carbide embedded in a metal binder phase, usually rich in Co. Cubic carbides or carbonitrides based on Ta, Ti, and Nb are often added in cemented carbides to increase the resistance to plastic deformation or as gradient formers1. Some grain growth inhibitors such as Cr and V may also be added in small amounts. In order to increase cutting performance of the cemented carbide inserts, the wear surface are usually coated with a thin layer of hard material3. Due to the high deposition temperature and a large difference in thermal expansion coefficients between the coating and substrate, cracks would be introduced into the coating unavoidably4. And the formed cracks might easily propagate into the substrate to cause failure when coating tools are employed in metal machining5. In order to prevent crack propagation from the coating into the substrate, a gradient layer, which is free of cubic phases and enriched in binder phase, is introduced between coating and substrate5.
In the past decades, cemented carbides were mainly developed through a large degree of testing. However, there are numerous factors influencing the microstructure and properties of cemented carbides, such as alloy composition, sintering temperature, time and partial pressure and so on. These factors can only be varied in an infinite number of ways through experimental method. In order to shorten development time, reduce the cost and improve outcome, the concept of materials genome has been proposed. Computation, experimentation, and database are identified as three major components of materials genome. The ceramic genome can describe the interaction of the various process conditions, which presents the opportunity to design and produce new kinds of cemented carbides more efficiently. CALPHAD (CALculation of PHAse Diagrams) method is a powerful tool to establish the database of various properties in the ceramic genome. Computational thermodynamics, using, e.g. the Thermo-Calc and DICTRA packages, has shown to be a powerful tool for processing advanced materials in cemented carbides, which is more efficient on composition and process parameters optimization compared with expensive and time consuming experimental methods. With the development of thermodynamic and diffusivity databases, it is possible to make technical calculations on commercial products which are multicomponent alloys. On the basis of thermodynamic database, thermodynamic calculations can give an easy access to what phases form at different temperatures and alloy concentrations during the manufacture process. By combining CSUTDCC1 and CSUDDCC1 databases, DICTRA6 permits simulations of the gradient process, which is a major advance in the understanding of the gradient zone formation in the cemented carbides.
Ti-Al-N hard coatings with cubic (c) NaCl structure, where Al substitutes for Ti in the TiN-based structure (i.e., c-Ti1-xAlxN), are widely used in cutting tools because of their high hardness and wear resistance as well as good thermal properties7. Because of the spinodal decomposition of c-Ti1-xAlxN into nano-size cubic Ti-rich and Al-rich domains at elevated temperatures, the age-hardening abilities of Ti-Al-N coatings can improve the mechanical properties of coatings8. Due to solid solution strengthening, alloying Zr to Ti-Al-N coating can improve the hardness. Unfortunately, a huge amount of work is needed to find appropriate elements by using experimental method, while first-principles calculations on the investigation of structural and mechanical properties can reduce the workload effectively and provide the reasonable explanation for the experimental observation.
This paper is devoted to 1) describe the development of the thermodynamic and diffusion databases in cemented carbides, 2) design experiments to investigate the gradient zone formation under different sintering environments, 3) validate the accuracy and reliability of the presently established databases in ceramic genome by comparing the experimental and simulation results, 4)investigate the structural and thermal properties of Ti-Al-Zr-N hard coatings by first-principles calculations and experiment, and 5) present the schematical ceramic genome strategy for the development of new cemented carbides and hard coating.
ESTABLISHMENT OF THE CERAMIC GENOME
Development of Thermodynamic and Diffusivity Databases
The development of thermodynamic and diffusivity databases in cemented carbides has started from the major elements in gradient cemented carbides C-Co-Cr-W-Ta-Ti-Nb-N. The usage of ceramic genome in industry will necessarily require that thermodynamic and diffusivity databases provide data that is not only of high quality, but relevant to industrially complex materials.
Developed using the CALPHAD approach, the thermodynamic database, CSUTDCC1, is based on critical evaluations of binary, ternary and even higher order systems which enable making predictions for multicomponent systems and alloys of industrial importance. Six important phases in cemented carbides, e.g. liquid, WC, carbides or carbonitrides, binder (Co), and eta (M6C or M12C) phases, are the main focus during the modeling. A large number of additional phases are also included in CSUTDCC1, because many of the binary and ternary systems in CSUTDCC1 have been assessed over their entire composition and temperature ranges. It is important to have reliable descriptions for all the stable phases in the system when developing new alloys and exploring new composition ranges. The thermodynamic models describe the thermodynamic properties of various types of phases depending on the crystallography, order-disorder transitions, and magnetic properties of the phases. With parameters stored in database, many different models9, including the substitution solution model, sublattice model, order-disorder model, have been adopted for the phases in cemented carbide systems. The thermodynamic models for Gibbs energy of a phase can be represented by a general equation:
(1)
Here refGmθ represents the Gibbs energy of the pure elements of the phase and idGmθ represents the contribution due to the ideal mixing. The term EGmθ represents the excess energy and magnGmθ the magnetic contribution.
In contrast to extensive efforts on the establishment of thermodynamic database for multicomponent cemented carbides, diffusivities in the multicomponent cemented carbides have received limited investigations both experimentally and theoretically. In a multicomponent system, a large number of diffusivities need to be evaluated, making a database very complex. A superior alternative is to model atomic mobility instead. In this way, the number of the stored parameters in the database is substantially reduced and the parameters are independent. A detailed description for the atomic mobility is given by Andersson and Ågren10. The atomic mobility for an element B, MB, can be expressed as
(2)
where R is the gas constant, T the temperature, MB0 a frequency factor and QB the activation enthalpy. Both MB0 and QB are in general dependent on composition and temperature.
The simulation of gradient zone formation is based on the model for long-range diffusion occurring in a continuous matrix with dispersed phases. Due to the presence of dispersed phases (WC, carbides and carbonitrides), the diffusion is reduced in the matrix (the liquid binder phase)11. A so-called labyrinth factor λ(f), where f is the volume fraction of the...
