Chapter 1
Introduction to Real-Time Embedded Systems
Real-time embedded systems have become pervasive. They are in your cars, cell phones, Personal Digital Assistants (PDAs), watches, televisions, and home electrical appliances. There are also larger and more complex real-time embedded systems, such as air-traffic control systems, industrial process control systems, networked multimedia systems, and real-time database applications. It is reported that in the Lexus LS-460 released in September 2006, there are more than 100 microprocessors embedded when all optional features are installed. It is also estimated that 98% of all microprocessors are manufactured as components of embedded systems. In fact, our daily life has become more and more dependent on real-time embedded applications. This chapter explains the concepts of embedded systems and real-time systems, introduces the fundamental characteristics of real-time embedded systems, and defines hard and soft real-time systems. The automotive antilock braking system (ABS) is used as an example to show a real-world embedded system.
1.1 Real-Time Embedded Systems
An embedded system is a microcomputer system embedded in a larger system and designed for one or two dedicated services. It is embedded as part of a complete device that often has hardware and mechanical parts. Examples include the controllers built inside our home electrical appliances. Most embedded systems have real-time computing constraints. Therefore, they are also called real-time embedded systems. Compared with general-purpose computing systems that have multiple functionalities, embedded systems are often dedicated to specific tasks. For example, the embedded airbag control system is only responsible for detecting collision and inflating the airbag when necessary, and the embedded controller in an air conditioner is only responsible for monitoring and regulating the temperature of a room.
Another noteworthy difference between a general-purpose computing system and an embedded system is that a general-purpose system has full-scale operating system support, while embedded systems may or may not have operating system support at all. Many small-sized embedded systems are designed to perform simple tasks and thus do not need operating system support.
Embedded systems are reactive systems in nature. They are basically designed to regulate a physical variable in response to the input signal provided by the end users or sensors, which are connected to the input ports. For example, the goal of a grain-roasting embedded system is regulating the temperature of a furnace by adjusting the amount of fuel being injected into the furnace. The regulation or control is performed based on the difference between the desired temperature and the real temperature detected by temperature sensors.
Embedded systems can be classified based on their complexity and performance into small-scale, medium-scale, and large-scale. Small-scale systems perform simple functions and are usually built around low-end 8- or 16-bit microprocessors or microcontrollers. For developing embedded software for small-scale embedded systems, the main programming tools are an editor, assembler, cross-assembler, and integrated development environment (IDE). Examples of small-scale embedded systems are mouse and TV remote control. They typically operate on battery. Normally, no operating system is found in such systems.
Medium-scale systems have both hardware and software complexities. They use 16- or 32-bit microprocessors or microcontrollers. For developing embedded software for medium-scale embedded systems, the main programming tools are C, C++, JAVA, Visual C++, debugger, source-code engineering tool, simulator, and IDE. They typically have operating system support. Examples of medium-scale embedded systems are vending machines and washing machines.
Large-scale or sophisticated embedded systems have enormous hardware and software complexities, which are built around 32- or 64-bit microprocessors or microcontrollers, along with a range of other high-speed integrated circuits. They are used for cutting-edge applications that need hardware and software codesign techniques. Examples of large-scale embedded systems are flight-landing gear systems, car braking systems, and military applications.
Embedded systems can be non-real-time or real-time. For a non-real-time system, we say that it is correctly designed and developed if it delivers the desired functions upon receiving external stimuli or internal triggers, with a satisfied degree of QoS (Quality of Service). Examples are TV remote controls and calculators.
Real-time systems, however, are required to compute and deliver correct results within a specified period of time. In other words, a job of a real-time system has a deadline, being it hard or soft. If a hard deadline is missed, then the result is useless, even if it is correct. Consider the airbag control system in automobiles. Airbags are generally designed to inflate in the cases of frontal impacts in automobiles. Because vehicles change speed so quickly in a crash, airbags must inflate rapidly to reduce the risk of the occupant hitting the vehicle's interior. Normally, from the onset of the crash, the entire deployment and inflation process is about 0.04 seconds, while the limit is 0.1 seconds.
Non-real-time embedded systems may have time constraints as well. Imagining if it takes more than 5 seconds for your TV remote control to send a control signal to your TV and then the embedded device inside the TV takes another 5 seconds to change the channel for you, you will certainly complain. It is reasonable that consumers expect a TV to respond to remote control event within 1 second. However, this kind of constraints is only a measure of system performance.
Traditional application domains of real-time embedded systems include automotive, avionics, industrial process control, digital signal processing, multimedia, and real-time databases. However, with the continuing rapid advance in information and communication technology and the emergence of Internet of things and pervasive computing, real-time embedded applications will be found in any objects that can be made smart.
1.2 Example: Automobile Antilock Braking System
A distinguished application area of real-time embedded systems is automobiles. Automotive embedded systems are designed and developed to control engine, automatic transmission, steering, brake, suspension, exhaustion, and so on. They are also used in body electronics, such as instrument panel, key, door, window, lighting, air bag, and seat bag. This section introduces the ABS.
An ABS is an automobile safety system. It is designed to prevent the wheels of a vehicle from locking when brake pedal pressure is applied, which may occur all of a sudden in case of emergency or short stopping distance. A sudden lock of wheels will cause moving vehicles to lose tractive contact with the road surface and skid uncontrollably. For this reason, ABS also stands for antiskid braking system. The main benefit from ABS operation is retaining the directional control of the vehicle during heavy braking in rare circumstances.
1.2.1 Slip Rate and Brake Force
When the brake pedal is depressed during driving, the wheel velocity (the tangential speed of the tire surface) decreases, and so does the vehicle velocity. The decrease in the vehicle velocity, however, is not always synchronized with the wheel velocity. When the maximum friction between a tire and the road surface is reached, further increase in brake pressure will not increase the braking force, which is the product of the weight of the vehicle and the friction coefficient. As a consequence, the vehicle velocity is greater than the wheel speed, and the wheel starts to skid. The wheel slip rate, s, is defined as
where V, ?, and R denote the vehicle speed, wheel angular velocity, and wheel rolling radius, respectively. Under normal driving conditions, V = ?R and thus, s = 0. During severe braking, it is common to have ? = 0 and V > 0, which translates to s = 1, a case of wheel lockup.
Figure 1.1 describes the relationship among the slip rate, braking force, and cornering force. The continuous line in the figure represents the relationship between the slip rate and braking force. It shows that the braking force is the largest when the slip rate is between 10% and 20%. The braking distance is the shortest at this rate. With further increase in slip rate, the braking force is decreased, which results in a longer braking distance. The dashed line depicts the relationship between the slip rate and cornering force. The cornering force is generated by a vehicle tire during cornering. It works on the front wheels as steering force and on the rear wheels to keep the vehicle stable. It decreases as the slip rate increases. In case of a lockup, the cornering force becomes 0 and steering is disabled.
Figure 1.1 Relationship among the slip rate, braking force, and cornering force.
1.2.2 ABS Components
The ABS is composed of four components. They are speed sensors, valves, pumps, and an electrical control unit (ECU). Valves and pumps are often housed in hydraulic control units (HCUs).
1.2.2.1 Sensors
There are multiple types of sensors used in the ABS. A wheel speed sensor is a sender device used for reading a vehicle's wheel rotation rate. It is an electromagnet...
