A Hybrid Deep Learning Model for Emotion Conversion in Tamil Language

Satrughan Kumar Singh1*, Muniyan Sundararajan2 and Jainath Yadav1

1Department of Computer Science, Central University of South Bihar, Gaya, Bihar, India

2Department of Mathematics and Computer Science, Mizoram University, Aizawl, Mizoram, India

Abstract

In speech signal processing, emotion recognition is a challenging task in classifying speech into different emotions. In this chapter, we propose a hybrid model based on FFNN (feed forward neural network) and SVM (support vector machine) for automated emotion conversion in the Tamil language. The use of voice command indeed contributes to a better integrated human-machine interface integration where one can give voice command, which intelligent machine understands and obeys. The Tamil language is mostly syllabic for the synthetical analysis of speech signal recognition. The changes in speech signal processing are mainly observed in several acoustic parameters such as root mean square energy, short-time energy, mel-frequency cepstral coefficient, and zero crossing rate, which are subsequently used for discrimination of the generation of a new set of the feature vector. In this proposed model, firstly, the FFNN model is complemented on the training and test datasets. Thereafter, SVM is used to perform the classification task. In the proposed emotion transformation, emotions such as angry, happy, sad, calm, surprised, fearful, neutral, and disgust are considered as target emotions with the multi-layered signal processing framework. This framework is required for spectral mapping to convert neutral utterance into target emotional utterance that is evaluated by subjective tests. Finally, both subjective and objective tests reveal a high and increased accuracy with the proposed model for spectral mapping and also show that the proposed model is better than Gaussian mixture model (GMM), FFNN and some pre-trained convolutional neural network (CNN) architectural models.

Keywords: Spectral mapping, emotion conversion, GMM, FFNN, pre-trained CNN, FFNN+SVM, objective measure

1.1 Introduction

Speech signal processing for emotion conversion has been a recent emerging domain in the human-machine interface. Presently, people are constantly trying to make computers intelligent so that they can do almost all the work easily like humans [1]. The communication between human and computer occurs in both directions [2]. This communication should have two important features of speech technology, speech recognition and speech synthesis. It is known that humans use emotions frequently to convey the intended message. Therefore, it is expected that the machine should be able to understand and generate desired emotions [3, 26]. Most of the existing speech systems can generate only neutral style speech. In this situation, the transformation of emotion is applied to convert the neutral style speech to desired expressive style speech. The modules of emotion transformation are used for making speaking instruments for disabled people and telling the stories in an automatic way [5, 24]. Generation of emotional speech is a challenging research problem. Some research works have attempted to generate expressive speech using text-to-speech synthesis (TTS) technique. Researchers have used the following methods for expressive speech synthesis: (i) formant synthesis or rule-based synthesis, (ii) di-phone concatenation synthesis, (iii) unit selection synthesis, and (iv) Hidden Markov Model (HMM)-based parametric speech synthesis. Emotion transformation approach differs from expressive speech synthesizers because it takes input as neutral speech, while the input of expressive speech synthesizer is text. It can be used with any speech synthesizers to convert their neutral speech output to the desired emotional speech. It generates emotional speech by creating emotional parameters into neutral speech [6, 7]. A formant vocoder is used to synthesize the speech transformation, showing the contour mapping of the target emotion through neural network [25]. For synthesizing emotional speech, the most important issue is to identify features which carry the emotion-specific information. Among various speech features, the widely used features for discrimination of emotions are prosodic and spectral features. The existing emotion transformation techniques transform neutral to emotional speech using prosody manipulation [8-10]. In this chapter, we have generated emotional speech by mapping of spectral features from neutral to target emotions in Tamil language.

1.2 Dataset Collection and Database Preparation

Spectral feature mapping framework needs parallel utterances of source and target emotions to perform emotion transformation process. Around 30 to 50 parallel utterances are sufficient to build emotion-specific mapping functions [11, 12]. In this work, we selected 100 parallel utterances from the emotional speech database collected from one male and one female speaker in Tamil language. These utterances were recorded in eight emotions such as angry, happy, sad, calm, surprised, fearful, neutral, and disgust. Training facilitates a learning system for creating an acoustic training dataset [4]. For training and testing purposes, we used 70 and 30 parallel utterances, respectively.

1.3 Pre-Trained CNN Architectural Models

1.3.1 VGG16

VGG16 is a convolutional neural network (CNN) model which basically focuses on depth. VGG takes 224 x 224 pixel RGB image. It uses a small receptive field (3 x 3 with stride of 1) followed by a ReLu unit. VGG16 has three fully connected layers; the first two have 4096 channels and the third has 1000 channels, one for each class. All of VGG16's hidden layers use ReLu. VGG has many variants, among which is VGG16, which is famous as its name is derived from its architecture using 16 layers in total among 13 convolution layers, two fully connected layers, and one output layer.

1.3.2 ResNet50

ResNet50 is known as residual network. ResNet works on skip connection. As it is known, deep networks always suffer from vanishing gradients without adjustments. Tiny gradients make learning intractable. To overcome this problem, Microsoft introduced a deep residual learning framework. The skip connection provides the learning network to identity function for passing the input through the block without passing through the other weight layers and allowing the network to traverse through its layers without gaps.

1.4 Proposed Method for Emotion Transformation

In this chapter, feed forward neural network (FFNN) was explored for emotion transformation. In the literature, Gaussian mixture model (GMM) was used for mapping features from one domain to others. However, the weakness of GMM is that it uses the assumption that the shape of mapping function is Gaussian. In addition to it, GMM requires to fix the number of mixtures before the mapping process. These weaknesses motivated us to explore FFNN to develop an emotion transformation system. Normally, it contains two hidden layers for capturing global and local information between input and output parameters [13-15]. Any continuous valued function can be simulated by considering two or more hidden layers in the neural network [16]. Hence, two hidden layers are sufficient for developing mapping functions. We considered three hidden layers in place of two hidden layers to take the additional benefit of symmetric structure. The symmetric structure is useful to map input parameter to output parameter [16-20]. The FFNN is depicted in Figure 1.1. The third hidden layer of FFNN compresses the dimension of input parameters. It captures global information while other hidden layers capture local information required for developing mapping functions. The accurate mapping functions are developed by selecting an appropriate structure of FFNN. The mapping function F(t) can be expressed as following:

Figure 1.1 The diagram 5 layers feed forward neural network model.

Figure 1.2 Block diagram of the proposed model.

where g(t) = x, h(t) = a tanh(?t), a = 1.72 and ? = 0.66. W1, W2, W3, W4 are weight matrices of the neural network. Feed forward neural network uses back-propagation learning to learn the relation between input and output features.

The proposed model (see Figure 1.2) can be summarized as the stepwise process of preprocessing, acoustic features extraction from the preprocessed audio signals, training with FFNN model for acoustic feature vector set generation, and combining features in a single set. Finally, support vector machine (SVM) classifier is used to train with the hybrid feature vector.

1.4.1 Architecture of Emotion Conversion Framework

Emotion transformation process is performed in two steps: (i) training and (ii) testing. During the training process, GMM and FFNN models are developed to map mel-cepstral coefficients (MCEPs) from neutral to target emotional speech. The average and standard deviation of F0 are computed from both neutral and emotional speeches to perform mapping of F0 using Equation 1.2.

Figure 1.3 Block diagram showing testing process.

During the testing phase (see Figure 1.3), the mapped MCEPs and F0 are given as input to Mel-Log Spectrum Approximation (MLSA) filter [21] to...
