1
Introduction

Patrick Doreian3,4, Vladimir Batagelj1,2,5 and Anuska Ferligoj3,5

1IMFM Ljubljana

2IAM, University of Primorska, Koper

3FDV, University of Ljubljana

4University of Pittsburgh

5NRU HSE Moscow

This book focuses on network clustering regardless of the disciplines within which a network was established. In the initial conception for the book, our attention was driven primarily by concerns regarding blockmodeling and community detection as they applied to social networks. But as we looked further into this general topic to invite potential contributors, we realized that the domain was much broader. The wide variety of approaches contained in this volume exemplifies this diversity. For us, as we assembled this volume, this was an exciting learning experience, one we hope will be experienced by readers of this book.

There is no single best approach to network clustering. Put differently, there is no cookie-cutter approach fitting all such data sets. Yes, there are adherents of one (their) approach who think this is the case. As shown in the chapters that follow, none of the authors of the contributed chapters share this very narrow view. This is a wide-open realm with multiple exciting approaches. We reflect further on this in the concluding chapter. Here, we describe briefly the contents of the following chapters merely as an introduction to them. In our view, each chapter merits close attention.

1.1 On the Chapters

As the book is concerned with network clustering, Chapter 2 offers an extended examination of the network clustering literature. Identifying the citation network for this literature turned out to be a complex task. Methods for doing this are described in detail. The initial search used the Web of Science (WoS) to identify documents using search terms. There were multiple searches, with the first being for 2015 and the final network was obtained for February 2017. This literature expanded dramatically and in a complex fashion.

While a citation network is composed of links between works treated as nodes, there is more to consider when other types of units are included. These include authors, journals, and keywords. As part of a more general strategy, one starting from the citation network but using additional information, multiple two-mode networks were constructed. This included an authorship network with works authors, a journal network featuring works journals, and a keyword network with works keywords. They help give more insight into the one-mode citation network having only scientific productions.

Chapter 2 lists the most cited works, the most citing works, the most used keywords, and a discussion of the "boundary problem" as it relates to citation networks. One message from this chapter is that the way the boundary of a citation network is established affects greatly the data analytic results that follow. This implies using great care in constructing citation networks - not all citation networks will suffice for meaningful analyses.

Chapter 2 presents a wide range of analyses of the citation network for the network clustering literature. Components of the network were established. Both critical project main paths and key-route paths were identified. In the analysis of this network, a clear transition between the blockmodeling and the community detection literatures was revealed. Another technique used in Chapter 2 is the identification of link islands which have higher levels of internal cohesion as a way identifying some important subnetworks of this literature. The largest of these link islands featured works from the blockmodeling and community detection literatures. Since the transition from the former to the latter, it seems the two have developed independently. This seems problematic given our belief in the utility of useful ideas flowing between fields and sub-fields.

The other islands discussed in Chapter 2 come from the fields of engineering geology, geophysics, as well as electromagnetic fields and their impacts on humans. One of the searches used in the searches of the WoS database included the terms "block model" and "block". The latter crops up in other literatures, a surprise for us. In considering these other link islands, another surprise awaited the authors of this chapter. We are used to debates in the social network literature regarding the difference between static and temporal approaches to studying networks. This divide is present also in the natural sciences.

Chapter 2 also contains an examination of authors and measures of productivity within research groups, collaboration, and an examination of citations among authors contributing to the network clustering literature. Again, the stark division between the community detection and blockmodeling literatures was clear. Examined also are citations between journals publishing articles in the broad area of the network clustering literature. The methodological details of doing this, as outlined in this chapter, merit further attention.

Bibliographic coupling, which occurs when two works both cite a third work in their bibliographies, was also examined. This included a sustained assessment as to how this coupling is measured. These tools were applied to the network clustering literature, especially for the largest identified island. This included an examination of the most frequently used keywords in the social networks literature and the physicist-driven approach to studying social networks. While some keywords were the same, there were considerable differences, again illustrating the different concerns in these two literatures.

Chapter 3 provides an overview of "classical" clustering including both the clustering of networks and clustering in networks. The clustering problem is considered as a discrete optimization problem which turns to be, in most cases, NP hard. Therefore, local optimization or greedy methods are usually used for solving it. These methods can be adapted also for clustering in networks (or clustering with relational constraints). The hierarchical agglomerative clustering method can be extended for efficiently clustering large sparse networks. This is illustrated with an analysis of normalized author citation networks from the network clustering literature from Chapter 2.

Chapter 4 describes different approaches to community detection. The authors ask very useful questions which led them to provide helpful guidelines for researchers contemplating network clustering within a community detection framework. It starts with a bold claim that there is no precise definition of a community. We concur. Their focused review of community detection methods makes it clear that researchers need to have a clear idea as to why any method is selected prior to its use. The authors point to the problem that the same term can have different meanings in different subfields, reflecting what was found in Chapter 2. They argue "community detection should not be viewed as a well-defined problem but rather an umbrella term with many facets." This delightful image is equally applicable to blockmodeling within social network analysis!

Four different approaches to community detection are outlined. The first uses the cut-based perspective. The second is a clustering approach maximizing the internal density of clusters and the third is the stochastic equivalence perspective. Finally, there is a dynamical perspective focusing on the impact of communities and dynamic processes to establish a dynamically relevant coarse-grained partitions of network structure. Four sections follow which provide precise descriptions of the fundamental properties of these approaches and the results stemming from adopting them.

Their discussion makes it clear that there is no single "best" community detection algorithm and that there can be multiple equally valid partitions of a network depending on which of the four considered approaches is used. Again, this sentence holds fully when "blockmodeling" is used instead of "community detection". Of course, this applies to all the network clustering approaches presented in this volume.

Chapter 5 provides an extensive discussion of label propagation as a heuristic method initially proposed for community detection. There is natural segue between Chapters 4 and 5. Label propagation is a partially supervised machine learning algorithm assigning labels to previously unlabeled data points. At the start of the algorithm, subsets of nodes have labels, which amounts to a clustering of them. These labels are propagated to the unlabeled points throughout the course of the algorithm. Nodes carry a label denoting the community to which they belong. Membership in a community changes based on the labels that the neighboring nodes possess as the labels diffuse through the network.

The author is clear that while it is not the most accurate or the most robust clustering method, a label propagation algorithm is simple to implement and is exceptionally fast. Networks with hundreds of millions of nodes can be analyzed readily. The early work on this approach is described with the basic ideas presented for simple undirected networks. However, the author points out that it can be used for many more types of networks, including those with multiple edges between nodes, two-mode networks, and signed networks. It can be used also to identify and delineate...
