Power System Harmonics and Passive Filter Designs
Description
Alles über E-Books | Antworten auf Fragen rund um E-Books, Kopierschutz und Dateiformate finden Sie in unserem Info- & Hilfebereich.
Reviews / Votes
"Students and professionals will definitely find this book an essential resource that will be referenced for many years." (IEEE Electrical Engineering magazine, 1 January 2016)More details
Other editions
Additional editions


Person
Content
FOREWORD xv
PREFACE xix
ABOUT THE AUTHOR xxi
CHAPTER 1 POWER SYSTEM HARMONICS 1
1.1 Nonlinear Loads 2
1.2 Increases in Nonlinear Loads 3
1.3 Effects of Harmonics 4
1.4 Distorted Waveforms 4
1.5 Harmonics and Sequence Components 7
1.6 Harmonic Indices 9
1.7 Power Factor, Distortion Factor, and Total Power Factor 11
1.8 Power Theories 13
1.9 Amplification and Attenuation of Harmonics 27
References 28
CHAPTER 2 FOURIER ANALYSIS 31
2.1 Periodic Functions 31
2.2 Orthogonal Functions 31
2.3 Fourier Series and Coefficients 33
2.4 Odd Symmetry 35
2.5 Even Symmetry 36
2.6 Half-Wave Symmetry 37
2.7 Harmonic Spectrum 41
2.8 Complex form of Fourier Series 41
2.9 Fourier Transform 43
2.10 Dirichlet Conditions 52
2.11 Power Spectrum of a Function 54
2.12 Convolution 56
2.13 Sampled Waveform: Discrete Fourier Transform 57
2.14 Fast Fourier Transform 64
References 69
CHAPTER 3 HARMONIC GENERATION-1 71
3.1 Harmonics in Transformers 71
3.2 Energization of a Transformer 79
3.3 Delta Windings of Three-Phase Transformers 82
3.4 Harmonics in Rotating Machine Windings 92
3.5 Cogging and Crawling of Induction Motors 97
3.6 Synchronous Generators 102
3.7 Saturation of Current Transformers 104
3.8 Ferroresonance 105
3.9 Power Capacitors 111
3.10 Transmission Lines 112
References 112
CHAPTER 4 HARMONIC GENERATION-II 115
4.1 Static Power Converters 115
4.2 Single-Phase Bridge Circuit 115
4.3 Reactive Power Requirements of Converters 122
4.4 Three-Phase Bridge Circuit 124
4.5 Harmonics on Output (DC) Side 133
4.6 Inverter Operation 135
4.7 Diode Bridge Converters 139
4.8 Switch-Mode Power (SMP) Supplies 142
4.9 Home Appliances 143
4.10 Arc Furnaces 144
4.11 Cycloconverters 147
4.12 Thyristor-Controlled Reactor 150
4.13 Pulse Width Modulation 154
4.14 Voltage Source Converters 158
4.15 Wind Power Generation 162
4.16 Fluorescent Lighting 165
4.17 Adjustable Speed Drives 167
4.18 Pulse Burst Modulation 174
4.19 Chopper Circuits and Electric Traction 175
4.20 Slip Frequency Recovery Schemes 177
4.21 Power Semiconductor Devices 178
References 181
CHAPTER 5 INTERHARMONICS AND FLICKER 183
5.1 Interharmonics 183
5.2 Sources of Interharmonics 183
5.3 Arc Furnaces 192
5.4 Effects of Interharmonics 196
5.5 Reduction of Interharmonics 198
5.6 Flicker 198
5.7 Flicker Testing 202
5.8 Control of Flicker 205
5.9 Tracing Methods of Flicker and Interharmonics 208
5.10 Torsional Analysis 210
5.11 Subsynchronous Resonance 217
References 225
CHAPTER 6 HARMONIC REDUCTION AT THE SOURCE 229
6.1 Phase Multiplication 230
6.2 Varying Topologies 230
6.3 Harmonic Cancellation: Commercial Loads 232
6.4 Input Reactors to the PWM ASDs 235
6.5 Active Filters 237
6.6 Active Current Shaping 248
6.7 Hybrid Connections of Active and Passive Filters 251
6.8 Impedance Source Inverters 255
6.9 Matrix Converters 259
6.10 Mutilevel Inverters 262
6.11 Switching Algorithms for Harmonic Control 270
6.12 Theory of Resultants of Polynomials 271
References 277
CHAPTER 7 ESTIMATION AND MEASUREMENTS OF HARMONICS 281
7.1 Waveform without Ripple Content 282
7.2 Waveform with Ripple Content 288
7.3 Phase Angle of Harmonics 298
7.4 Measurements of Harmonics 304
7.5 Measuring Equipment 309
7.6 Transducers for Harmonic Measurements 312
7.7 Characterizing Measured Data 314
7.8 Probabilistic Concepts 316
7.9 Summation of Harmonic Vectors with Random Angles 323
7.10 Central Limit Theorem 326
7.11 Kalman Filtering 326
References 329
CHAPTER 8 EFFECTS OF HARMONICS 331
8.1 Rotating Machines 332
8.2 Effect of Negative Sequence Currents on Synchronous Generators 335
8.3 Insulation Stresses 337
8.4 Transformers 345
8.5 Cables 359
8.6 Capacitors 361
8.7 Voltage Notching 362
8.8 EMI (Electromagnetic Interference) 363
8.9 Overloading of Neutral 367
8.10 Protective Relays and Meters 369
8.11 Circuit Breakers and Fuses 372
8.12 Telephone Influence Factor 372
References 377
CHAPTER 9 HARMONIC RESONANCE 379
9.1 Two-Port Networks 379
9.2 Resonance in Series and Parallel RLC Circuits 383
9.3 Practical LC Tank Circuit 391
9.4 Reactance Curves 396
9.5 Foster's Networks 397
9.6 Harmonic Resonance 400
9.7 Harmonic Resonance in a Distribution System 404
9.8 Elusiveness of Resonance Problems 405
9.9 Resonance Due to Single-Tuned Filters 408
9.10 Switched Capacitors for Power Factor Improvement 410
9.11 Secondary Resonance 411
9.12 Multiple Resonances in a Distribution Feeder 415
9.13 Part-Winding Resonance in Transformer Windings 416
9.14 Composite Resonance 419
9.15 Resonance in Transmission Lines 421
9.16 Zero Sequence Resonance 421
9.17 Factors Affecting Harmonic Resonance 423
References 424
CHAPTER 10 HARMONIC DISTORTION LIMITS ACCORDING TO STANDARDS 427
10.1 Standards for Limitation of Harmonics 427
10.2 IEEE 519 Harmonic Current and Voltage Limits 429
10.3 Point of Common Coupling (PCC) 432
10.4 Applying IEEE 519 Harmonic Distortion Limits 433
10.5 Time Varying Characteristics of Harmonics 435
10.6 IEC Harmonic Current Emission Limits 436
10.7 Voltage Quality 440
10.8 Commutation Notches 444
10.9 Applying Limits to Practical Power Systems 449
References 450
CHAPTER 11 APPLICATION OF SHUNT CAPACITOR BANKS 453
11.1 Shunt Capacitor Banks 453
11.2 Location of Shunt Capacitors 458
11.3 Ratings of Capacitors 459
11.4 Shunt Capacitor Bank Arrangements 465
11.5 Fusing 468
11.6 Connections of Banks 476
11.7 Unbalance Detection 479
11.8 Destabilizing Effect of Capacitor Banks 481
11.9 Switching Transients of Capacitor Banks 483
11.10 Control of Switching Transients 486
11.11 Switching Capacitors with Motors 489
11.12 Switching Devices 490
11.13 Switching Controls 498
References 501
CHAPTER 12 MODELING OF SYSTEM COMPONENTS FOR HARMONIC ANALYSIS 503
12.1 Transmission Lines 503
12.2 Cables 532
12.3 Zero Sequence Impedance of OH Lines and Cables 538
12.4 Filter Reactors 539
12.5 Transformers 540
12.6 Induction Motors 554
12.7 Synchronous Generators 556
12.8 Load Models 557
12.9 System Impedance 559
12.10 Three-Phase Models 561
12.11 Uncharacteristic Harmonics 563
12.12 Converters 564
References 566
CHAPTER 13 HARMONIC MODELING OF SYSTEMS 569
13.1 Electrical Power Systems 569
13.2 Extent of Network Modeling 572
13.3 Impact of Loads and Generation 573
13.4 Short-Circuit and Fundamental Frequency Load Flow Calculations 574
13.5 Industrial Systems 578
13.6 Distribution Systems 582
13.7 Transmission Systems 589
13.8 Compensation of Transmission Lines 593
13.9 Commercial Buildings 598
13.10 Residential Loads 599
13.11 HVDC Transmission 599
References 605
CHAPTER 14 HARMONIC PROPAGATION 607
14.1 Harmonic Analysis Methods 608
14.2 Frequency Domain Analysis 608
14.3 Frequency Scan 610
14.4 Voltage Scan 611
14.5 Harmonic Analysis Methods 612
14.6 Time Domain Analysis 620
14.7 Sensitivity Methods 620
14.8 Unbalanced AC System and HVDC Link 622
14.9 Hybrid Frequency and Time Domain Concept 623
14.10 Probabilistic Concepts 626
14.11 Computer-Based Programs 631
14.12 Harmonic Analyses of a Large Industrial System 632
14.13 Long Transmission Line 653
14.14 34.5 kV UG Cable 673
14.15 5-Bus Transmission System 673
References 682
CHAPTER 15 PASSIVE FILTERS 685
15.1 Filter Types 685
15.2 Single-Tuned Filters 690
15.3 Harmonic Filter Detuning and Unbalance 699
15.4 Relations in an ST Filter 699
15.5 Selection of Q Factor 701
15.6 Double-Tuned Filter 702
15.7 Bandpass Filters 704
15.8 Damped Filters 705
15.9 Type C Filter 710
15.10 Zero Sequence Traps 716
15.11 Series-Type Low-Pass Filter 717
15.12 Transfer Function Approach for Filter Designs 718
15.13 Optimization Techniques of Filter Designs 723
15.14 Genetic Algorithms for Filter Designs 728
15.15 HVDC-DC Filters 731
15.16 Limitations of Passive Filters 734
15.17 Flowchart for Design of Filters 735
15.18 Filter Components 735
15.19 Failure of Harmonic Filters 741
References 741
CHAPTER 16 PRACTICAL PASSIVE FILTER DESIGNS 745
16.1 Study 1: Small Distribution System with Major Six-Pulse Loads 745
16.2 Study 2: Filters for Arc Furnance Loads 756
16.3 Study 3: Filters for Two 8000-Hp ID Fan Drives 770
16.4 Study 4: Double-Tuned filter on a Three-Winding Transformer 782
16.5 Study 5: PV Solar Generation Plant 785
16.6 Study 6: Impact of Harmonics at a Distance 799
16.7 Study 7: Wind Generation Farm 804
INDEX 829
Chapter 1
Power System Harmonics
The electrical power systems should be designed not only for the sinusoidal currents and voltages but also for nonlinear and electronically switched loads. There has been an increase in such loads in the recent times, and these can introduce harmonic pollution, distort current and voltage waveforms, create resonances, increase the system losses, and reduce the useful life of the electrical equipment. Harmonics are one of the major problems of ensuring a certain power quality. This requires a careful analysis of harmonic generation and their measurements and the study of the deleterious effects, harmonic controls, and limitation to acceptable levels. Interest in harmonic analysis dates back to the early 1990s in connection with high voltage DC (HVDC) systems and static var compensators (SVC; Reference [1]). The analytical and harmonic limitation technology has progressed much during this period (see Reference [2] for a historical overview of the harmonics in power systems).
DC power is required for a number of applications from small amount of power for computers, video equipment, battery chargers, UPS (uninterrptible power supplies) systems to large chunks of power for electrolysis, DC drives, and the like. A greater percentage of office and commercial building loads are electronic in nature, which have DC as the internal operating voltage. Fuel and solar cells and batteries can be directly connected to a DC system, and the double conversion of power from DC to AC and then from AC to DC can be avoided. A case study conducted by Department of Electrical Power Engineering, Chalmers University of Technology, Gothenburg, Sweden is presented in [3]. This compares reliability, voltage drops, cable sizing, grounding and safety: AC verses DC distribution system. In Reference [4], DC shipboard distribution system envisaged by US Navy is discussed. Two steam turbine synchronous generators are connected to 7000 V DC bus through rectifiers, and DC loads are served through DC-DC converters. However, this is not a general trend, bulk and consumer power distribution systems are AC; and we will not be discussing industrial or commercial DC distribution systems in this book, except that HVDC converter interactions with respect to harmonics and DC filters are of interest and discussed in the appropriate chapters.
Harmonics in power systems originate due to varied operations, for example, ferroresonance, magnetic saturation, subsynchronous resonance, and nonlinear and electronically switched loads. Harmonic emission from nonlinear loads predominates.
1.1 Nonlinear Loads
To distinguish between linear and nonlinear loads, we may say that linear time-invariant loads are characterized so that an application of a sinusoidal voltage results in a sinusoidal flow of current. These loads display constant steady-state impedance during the applied sinusoidal voltage. Incandescent lighting is an example of such a load. The electrical motors not supplied through electronic converters also approximately meet this definition. The current or voltage waveforms will be almost sinusoidal, and their phase angles displaced depending on power factor of the electrical circuit. Transformers and rotating machines, under normal loading conditions, approximately meet this definition. Yet, it should be recognized that flux wave in the air gap of a rotating machine is not sinusoidal. Tooth ripples and slotting in rotating machines produce forward and reverse rotating harmonics. Magnetic circuits can saturate and generate harmonics. Saturation in a transformer on abnormally high voltage produces harmonics, as the relationship between magnetic flux density and the magnetic field intensity in a magnetic material (the transformer core) is not linear. Yet, the harmonics emissions from these sources are relatively small (Chapter 3).
In a nonlinear device, the application of a sinusoidal voltage does not result in a sinusoidal flow of current. These loads do not exhibit constant impedance during the entire cycle of applied sinusoidal voltage. Nonlinearity is not the same as the frequency dependence of impedance, that is, the reactance of a reactor changes in proportion to the applied frequency, but it is linear at each applied frequency if we neglect saturation and fringing. However, nonlinear loads draw a current that may even be discontinuous or flow in pulses for a part of the sinusoidal voltage cycle.
Mathematically, linearity implies two conditions:
- Homogeneity
- Superposition
Consider the state of a system defined in the state equation form:
1.1If is the solution to this differential equation with initial conditions at and input , :
1.2then homogeneity implies that
1.3where is a scalar constant. This means that with input is equal to times with input for any scalar .
Superposition implies that
1.4That is, with inputs is equal to the sum of with input and with input .Thus, linearity is superimposition plus homogeneity.
1.2 Increases in Nonlinear Loads
Nonlinear loads are continuously on the increase. It is estimated that, during the next 10 years, more than 60% of the loads on utility systems will be nonlinear. Also much of the electronic load growth involves residential sector and household appliances. Concerns for harmonics originate from meeting a certain power quality, which leads to the related issues of (1) effects on the operation of electrical equipment, (2) harmonic analysis, and (3) harmonic control. A growing number of consumer loads are sensitive to poor power quality, and it is estimated that power quality problems cost US industry tens of billion of dollars per year. Although the expanded use of consumer automation equipment and power electronics is leading to higher productivity, these heavy loads are a source of electrical noise and harmonics and are less tolerant to poor power quality. For example, adjustable speed drives (ASDs) are less tolerant to voltage sags and swells as compared to an induction motor; and a voltage dip of 10% of certain time duration may precipitate ASD shutdown. These generate line harmonics and a source containing harmonics impacts their operation, leading to further generation of harmonics. This implies that the nonlinear loads which are a source of generation of harmonics are themselves relatively less tolerant to the poor power quality that originates from harmonic emission from these loads.
Some examples of nonlinear loads are as follows:
- ASD systems
- Cycloconverters
- Arc furnaces
- Rolling mills
- Switching mode power supplies
- Computers, copy machines, television sets, and home appliances
- Pulse burst modulation
- Static var compensators (SVCs)
- Thyristor-controlled reactors (TCRs)
- HVDC transmission, harmonics originate in converters
- Electric traction, chopper circuits
- Wind and solar power generation
- Battery charging and fuel cells
- Slip frequency recovery schemes of induction motors
- Fluorescent lighting and electronic ballasts
- Electrical vehicle charging systems
- Silicon-controlled rectifier (SCR) heating, induction heating, and arc welding.
The harmonics are also generated in conventional power equipment, such as transformer and motors. Saturation and switching of transformers generate harmonics. The harmonic generation is discussed in Chapters 3-5. The application of capacitor banks for power factor corrections and reactive power support can cause resonance and further distortions of waveforms (Chapter 9). Earlier rotating synchronous condensers have been replaced with modern shunt capacitors or SVCs (Chapter 4).
1.3 Effects of Harmonics
Harmonics cause distortions of the voltage and current waveforms, which have adverse effects on electrical equipment. The estimation of harmonics from nonlinear loads is the first step in a harmonic analysis, and this may not be straightforward. There is an interaction between the harmonic producing equipment, which can have varied topologies, and the electrical system. Over the course of years, much attention has been focused on the analysis and control of harmonics, and standards have been established for permissible harmonic current and voltage distortions (Chapter 10). The effects of harmonics are discussed in Chapter 8.
1.4 Distorted Waveforms
Harmonic emissions can have varied amplitudes and frequencies. The most common harmonics in power systems are sinusoidal components of a periodic waveform, which have frequencies that can be resolved into some multiples of the fundamental frequency. Fourier analysis is the mathematical tool employed for such analysis, and Chapter 2 provides an overview.
The components in a Fourier series that are not an integral multiple of the power frequency are called noninteger harmonics (Chapter 5).
The distortion produced by nonlinear loads can be resolved into a number of categories:
-
A distorted waveform having a Fourier series with fundamental frequency equal to power system frequency and a periodic steady state exists. This is the most common case in harmonic studies. The waveform shown in Fig. 1.1 is synthesized from the harmonics shown in Table 1.1. The waveform in Fig. 1.1 is symmetrical about the x-axis and can be described by the...
