1
Coding and Addressing Modes
This chapter focuses on two important characteristics of Instruction Set Architecture (ISA) (cf. § V1-3.5), which are instruction encoding and addressing modes.
1.1. Encoding and formatting an instruction
The instruction1 is represented in a computer using a binary word in the format i bits, a multiple of the format n of the data and, in general, a multiple of the byte. We use the expression machine code to mean all those binary words representing the instruction to be executed. Instruction encoding depends on the architecture of the target processor. It is formed at least of an instruction code and, potentially, of one or more operands as Figure 1.1 illustrates.
Figure 1.1. Breakdown of an instruction
This instruction can be broken down into fields2. The instruction code, also called operation code (abridged to opcode), in format c, has one or more fields. The essential one is the function code. It defines the operation to be executed. Its format of f bits defines the maximum number of instructions F (= 2f) in the instruction set3. Other fields can be added to this such as, for example, one that specifies the addressing mode (the addressing mode field) of the operands to the format as Figure 1.2 illustrates (VAX4 approach from the Digital Equipment Corporation (DEC)). The processor therefore has 2a addressing modes. Besides simplifying the encoding, one benefit is to separate the encoding of the function from that of the address, which makes it possible to make the instruction set symmetrical (cf. § 3.1.3). This instruction code generally takes the format of the data n of the processor to optimize access to primary memory. Since in our example n is fixed, the architect of the microprocessor or MPU (MicroProcessor Unit) must therefore compromise between the number of instructions and the number of addressing modes if the field exists. One field may be favored to the detriment of the other.
Figure 1.2. An example of the structure of an operation code
If the instruction requires, the operation code is followed by one or more operand fields (Figure 1.3), and their number is dependent on the operation (unary or binary) and the architecture. This operand field in the format o bits makes it possible to specify, depending on the addressing mode chosen, the value of the reference of the location of the operand needed for calculation or, potentially, the result. An operand's storage location, which is imposed by the programmer, compiler or linker or architecture, is a register or memory location. An instruction to one operand is called a "monadic", and one with two operands, "dyadic". When there are two operands, we speak of source and destination operands or sink operands or sometimes simply left and right operands. We cite the VAX mini-computer with a variable format as an example of encoding. The operation code included one to two bytes. It was eventually followed by no more than six operand specifiers, mainly address specifiers, making it possible to design the operand. The MPU MC6800 instruction format included one to three bytes, the first being an operation code indicating the addressing mode.
Figure 1.3. Format of an instruction with two operands
Table 1.1 shows the different address combinations for IA-32 instruction set (IA for Intel Architecture, also called i386). Combinations not indicated are not possible either due to the architecture or to their incoherence. We cite impossible memory (to) memory combinations in most architectures, as it is necessary to pass through a register and an immediate-register or immediate-memory, which cannot be done because of the impossibility of allocating a value to a constant.
Table 1.1. Possible address combinations in family IA-32
Operands Destination Source Register Immediate Memory Immediate Register Register Memory Register Register MemoryThe identification field (ID) of the operand(s) specifies the format and addressing mode (register or memory reference) as well as the direction of transfer (Figure 1.4). In a RISC microprocessor (Reduced Instruction Set Computer, this will be covered in a future book by the author on microprocessors), this field is included in the instruction's code through simplification and in view of the reduced number of instructions and addressing modes.
Figure 1.4. An instruction with several operands
By construction, the format of the instruction is fixed (fixed length), short or long, or variable (variable length). The value of a fixed format is a multiple of the byte in general. Its value will have a direct consequence for the incrementation value of the Program Counter (PC, cf. § V3-3.1.3). The benefit is that it will be possible to align the instructions (cf. § 3.1.2), thus accelerating memory reading or writing by reducing the number of memory accesses. The division of the instruction into subfields, for example, one for the instruction class (cf. Chapter 2), the second for the function, the third for the type of operands and the last for the operands and a unique format allowing simplification of the hardware, the counterpart being a larger format. A variable format, a multiple of the MPU data format, complicates the Control Unit (CU), and it has an impact on the number of machine cycles (cf. § V3-2.4.1) needed for decoding. During this phase, the decoder should determine the size of the instruction as quickly as possible. This information is needed, for example, for debugging, to determine the instruction boundaries or limits in the machine code (interruptible "at instruction boundaries"). On the other hand, it has the advantage of obtaining programs that take up less memory. In fact, a simple instruction such as nop (no operation, cf. § 2.8.5) will classically take up one byte compared to a word with several bytes with a fixed format. The format's variability makes it difficult to use a pipeline or a superscalar execution (this will be covered in a future book by the author on microprocessors). As an example of a fixed format, we cite the format n = 32 bits for MIPS Technologies microprocessors. Even if the format is fixed, the number of fields may vary as well as the format. Encoding uses three types, which are Register (R-type), Immediate (I-type) and Jump (J-type) format (Figure 1.5). The operation code, completed possibly by the function field, specifies the instruction. For the first type, the second field is a specifier of the source register (rs). The following specifies the target or destination register (rt or rd), which receives the result or branching condition. The last field is an immediate value, a jump or address displacement. For the J type, the operand is the jump address in a 26-bit format. For the last type, the third field is a destination register specifier (rd). The penultimate field indicates the value of a possible shift (0 = no shift). Note the conventions rt = rs + immediate and rd = rs + rt. This simple encoding should be compared with that of the Arm® family, which can show as many as 21 types (Arm 2000).
Figure 1.5. Three fixed formats for MIPS instructions
None of these different fields have been standardized and are dependent on the manufacturer and the MPU family. For example, for Bayliss et al. (1981), an instruction is formed of four fields, which are the function fields (opcode), reference fields, and format and class fields. The class specifies the number of operands and their types. The necessary format field if there is at least one operand indicates their location (memory, register or pile, for example). The reference field gives their location explicitly. Their operation code field specifies the operation to be executed.
Figure 1.6 shows the typical variable instruction of an existing microprocessor. The instruction code has a format of 6 bits. The direction bit D indicates the direction of transfer (0 = source specified by the field reg, 1 = destination specified by the field). The bit W specifies the transfer format (0 = byte, 1 = word of 16 bits). The 2rd byte is called a "post-byte". The mode field indicates whether the transfer involves only the registers or if the memory is involved, the two displacement fields therefore indicate the length of the latter. We recognize the Little Endian byte order (LE (Cohen 1981), cf. § 2.6.2 from Darche (2012)) typical of Intel architecture since the Least Significant Byte (LSB) is first stored in the memory, in the order of the increasing addresses. To finish, the R/M (Register/Memory) field, poorly named, specifies the addressing mode, that is, the method of calculating the effective address (cf. § 1.2). Another format exists where the instruction is coded on a single byte. Thus, the format of these instructions can vary from 1 to 6 bytes. It...
