WCDMA (UMTS) Deployment Handbook

List of Contributors xi Foreword xiii Preface xv Acknowledgments xvii Acronyms xix 1 Introduction to UMTS Networks 1 Patrick Chan, Andrea Garavaglia and ChristopheChevallier 1.1 UMTS Network Topology 2 1.2 WCDMA Concepts 5 1.3 WCDMA Network Deployment Options 17 1.4 The Effects of Vendor Implementation 19 2 RF Planning and Optimization 21 Christophe Chevallier 2.1 Introduction 21 2.2 Overview of the Network Deployment Process 21 2.3 Link Budgets 25 2.4 Network Planning Tools 51 2.5 Interference Considerations during Network Planning 60 2.6 Topology Planning 61 2.7 Parameter Settings and Optimization during Network Planning62 2.8 RF Optimization 63 3 Capacity Planning and Optimization 73 Christophe Chevallier 3.1 Basic UMTS Traffic Engineering 73 3.2 Effect of Video-Telephony and PS Data on Traffic Engineering85 3.3 Multiservice Traffic Engineering 90 3.4 Capacity Planning 97 3.5 Optimizing for Capacity 108 4 Initial Parameter Settings 115 Christopher Brunner, Andrea Garavaglia and ChristopheChevallier 4.1 Introduction 115 4.2 Physical Layer Parameters 120 4.3 Intra-frequency Cell Reselection Parameters 124 4.4 Access Parameter Recommendations 136 4.5 Intra-frequency Handover Parameters 137 5 Service Optimization 153 Andrea Forte, Patrick Chan and Christophe Chevallier 5.1 KPI and Layered Optimization Approach 153 5.2 Voice Service Optimization 156 5.3 Video-Telephony Service Optimization 185 5.4 PS Data Service Optimization 196 6 Inter-System Planning and Optimization 211 Andrea Garavaglia, Christopher Brunner and ChristopheChevallier 6.1 Introduction 211 6.2 Inter-System Boundary Planning 212 6.3 Inter-System Transitions in Connected Mode 216 6.4 Inter-System Transitions in Idle Mode 235 6.5 Test Setup for Inter-System Handover and Cell ReselectionPerformance Assessment 242 6.6 Optimizing Inter-System Parameters 243 6.7 Additional Inter-System Planning and Optimization Issues254 7 HSDPA 257 Kevin P. Murray and Sunil Patil 7.1 Motivations for High Speed Downlink Packet Access (HSDPA)257 7.2 HSDPA Concepts 260 7.3 HSDPA Planning 268 7.4 HSDPA Operation and Optimization 291 7.5 HSDPA Key Performance Indicators (KPI) 309 7.6 Test Setup 311 8 Indoor Coverage 315 Patrick Chan, Kenneth R. Baker and ChristopheChevallier 8.1 Introduction 315 8.2 Design Approach and Economic Considerations 315 8.3 Coverage Planning and Impact on Capacity 323 8.4 Optimizing Indoor Systems 352 References 366 Index 369
