System Approach to Business Operations and Information Engineering

1.1. System approach to conduct business operations

1.1.1. General considerations

The system approach is instrumental in tackling complexity in the managerial as well as technical worlds. The system concept is a modeling tool based on interacting entities. Its purpose is to understand complex structures by (de)composing them into entities having specific functions and interacting with each other.

The "composition" approach is implemented when designing a real or virtual object. The "decomposition" approach is implemented when analyzing some existing part of the world.

In both approaches, systems are constructed with a view to identifying certain function capabilities perceived by the users to be desirable. Examples of function-based systems include: defending the country, transmitting messages, transporting people and goods, manufacturing goods, exchanging products and services, etc.

In general, users are known not to be able to articulate all their requirements and expectations. Therefore, at the planning stage, there always exists a considerable uncertainty about many aspects of the system to be built, or, in other words, the system behavior. That explains why prototypes have to be built for checking whether the users' requirements are adequately fulfilled.

Systems do not exist in isolation. Each operates within a definite environment. But the ways a system interacts with its environment may prove to be of a wide variety. In other words, how and when some types of interaction take place have to be ascribed to uncertain or random events. As a result in certain circumstances, the system behavior can run out of control. These circumstances refer to events or sequences of events which have not been taken into account at the design stage of the system.

1.1.2. System description

1. Describing a system implies:
2. - describing its constituent entities as attributes;
3. - describing the inter-entity relationships;
4. - describing the relationships between entities and the environment.
5. Each entity can be a system in itself.

When a business unit is described as a system, the purpose is to control its business operations. Three entities have to be identified, i.e. the controlled system, the controlling system and the information system (IS). The controlled system, often called the transformation system, because it converts inputs into outputs, is modeled generally as a process. The relationships between these three entities are shown in Figure 1.1.

It is noteworthy to elaborate on Figure 1.1 for understanding the features of the system approach to business description. What is meant by direct and indirect control? Direct control refers to the direct action on the controlled process to maintain or change its state. Indirect control resorts to some entity external to the system for influencing the state of the controlled process by means of inputs.

Let us take an example to explain how the messages exchanged between the entities involved are articulated and how their contents trigger decisions. The controlled process is assumed to be a manufacturing process made of storage and production activities. A message coming from the market place (environment data) is captured and processed by the IS. The message content says that a market slump is forecast. It is directed to the production scheduler in an appropriate format (control data). As a consequence, the scheduler decides to reduce the production level by releasing orders to the manufacturing shops (direct control) on the basis of inventory levels (process data) and to send orders to suppliers to decrease the number of deliveries (indirect control).

Figure 1.1. Relationships between the various entities of a business unit within the framework of a system approach

1. Describing any business organization as a system means:
2. - identifying and modeling the system to be controlled (WHAT);

1. - identifying decision-making functions (WHO) and defining management rules (HOW);
2. - producing the IS requirement.

1.2. Information engineering

1.2.1. Information as a resource

1. Central to any human activity is the process of decision-making, i.e.:
2. - defining a goal;
3. - identifying a number of alternative actions which may lead to the goal;
4. - evaluating the consequences of each action;
5. - selecting the action which is most likely to lead to the desired goal.

The decision maker, in general, faces uncertainty mainly about the results of the envisaged action. Decisions vary in uncertainty associated with their outcomes. The greater the uncertainty, the greater the risk of a negative outcome. This uncertainty can be reduced or even completely removed by obtaining the relevant information about the courses of action in progress. It follows that information is defined as a resource by means of which uncertainty is reduced.

For large systems, as a rule, a part of the required information on the behavior of system environment becomes available only after the system has been put in operation. For this reason, there is a need for incorporating a control function of a sort into the very system. The role of control is to make decisions on the system behavior effective. When some deviation from the set goals is detected corrective control action is engineered to reach the set goals.

1.2.2. Explicit and implicit information

Information may be explicit or implicit. Implicit information or knowhow is that piece of information which is an integral part of skill and can be gained only by apprenticeship from an expert. The term "expert" is used here to denote a person who knows how to perform an activity without necessarily understanding why his/her methods work. In contrast, explicit information or know-how exists independently from any skill. It can be readily represented, stored and made available for general use.

1.2.3. Clarification of some terms

The body of knowledge, methods and established practices related to the handling of information as well as the associated devices will be called information technology. Systems of artifacts, the purpose of which is to handle information will be called here information systems. The engineering discipline concerned with the design, production, installation, operation and maintenance of ISs will be called information engineering.

1.2.4. Characteristics of information systems

It is quite clear that no organization could operate without some type of IS. The main functional capabilities an IS must fulfill are:

1. - capturing data;
2. - processing data;
3. - memorizing data.

These are followed in order to support the decision makers to conduct business operations.

- Contents of an information system

Even if users are not aware of this fact, IS designers posit that ISs are a modeled vision of the business universe. Whatever the assumptions made about the chosen representation of the business universe, IS constructs reflect how the enterprise is organized and operates. It implies that business information systems contain, in a way or another, a description of the enterprise's organizational structures, functioning mechanisms and deliverables. The contents of business information system include:

1. - static properties of operations and controls;
2. - description of deliverables (products or services);
3. - dynamic behavior of operations.

Several types of ISs are considered in businesses.

- Transaction processing systems

A transaction is a business operation modifying the state of the enterprise. Whenever a transaction occurs, data describing the transaction is created. Capturing, storing, processing, distributing and reporting of transaction data is the objective of transaction processing systems.

Let us consider an example. When a client places an order, an order form is created where the order content is described in terms of items, quantities and delivery dates and payment conditions. This order triggers updating of the inventory, sending an invoice, launching the manufacturing of new items, recording provisional income in the balance sheet, etc.

Somehow transaction processing systems are the front office of management information systems (MISs)

- Management information systems

MISs must give a relevant, accurate, significant and updated image of business activities and incoming and outcoming goods flows. Today, this is achieved by means of artifacts (software programs and databases) modeling the activities and goods flows involved.

1.2.5. Information system content for a manufacturing company

The IS content comprises the models representing the business from different points of view (processes/functions/organization). As an example, the products/services delivered, the control pattern and the infrastructure can be modeled for a manufacturing company as shown in Figure 1.2.

1.3. System approach to describing inventory-controlled storage
