Introduction

In computer science, a string s is defined as a finite sequence of characters from a finite alphabet S. Apart from the alphabet, an important characteristic of a string s is its length which, in this book, will be denoted by |s|. A string is, generally, understood to be a data type i.e. a string is used to represent and store information. For example, words in a specific language are stored in a computer as strings. Even the entire text may be stored by means of strings. Apart from fields such as information and text processing, strings arise in the field of bioinformatics. This is because most of the genetic instructions involved in the growth, development, functioning and reproduction of living organisms are stored in a molecule which is known as deoxyribonucleic acid (DNA) which can be represented in the form of a string in the following way. DNA is a nucleic acid that consists of two biopolymer strands forming a double helix (see Figure 1.1). The two strands of DNA are called polynucleotides as they are composed of simpler elements called nucleotides. Each nucleotide consists of a nitrogen-containing nucleobase as well as deoxyribose and a phosphate group. The four different nucleobases of DNA are cytosine (C), guanine (G), adenine (A) and thymine (T). Each DNA strand is a sequence of nucleotides that are joined to one another by covalent bonds between the sugar of one nucleotide and the phosphate of the next. This results in an alternating sugar-phosphate backbone (see Figure 1.1). Furthermore, hydrogen bonds bind the bases of the two separate polynucleotide strands to make double-stranded DNA. As a result, A can only bind with T and C can only bind with G. Therefore, a DNA molecule can be stored as a string of symbols from S = {A, C, T, G} that represent one of the two polynucleotide strands. Similarly, most proteins can be stored as a string of letters from an alphabet of 20 letters, representing the 20 standard amino acids that constitute most proteins.

Figure 1.1. DNA double helix (image courtesy of Wikipedia)

As a result, many optimization problems in the field of computational biology are concerned with strings representing, for example, DNA or protein sequences. In this book we will focus particularly on recent works concerning string problems that can be expressed in terms of combinatorial optimization (CO). In early work by Papadimitriou and Steiglitz [PAP 82], a CO problem is defined by a tuple (, f), where is a finite set of objects and is a function that assigns a non-negative cost value to each of the objects s ? . Solving a CO problem requires us to find an object s* of minimum cost value1. As a classic academic example, consider the well-known traveling salesman problem (TSP). In the case of the TSP, set consists of all Hamiltonian cycles in a completely connected, undirected graph with positive edge weights. The objective function value of such a Hamiltonian cycle is the sum of the weights of its edges.

Unfortunately, most CO problems are difficult to optimality solve in practice. In theoretical terms, this is confirmed by corresponding results about non-deterministic (NP)-hardness and non-approximability. Due to the hardness of CO problems, a large variety of algorithmic and mathematical approaches have emerged to tackle these problems in recent decades. The most intuitive classification labels these approaches as either complete/exact or approximate methods. Complete methods guarantee that, for every instance of a CO problem of finite size, there is an optimal solution in bounded time [PAP 82, NEM 88]. However, assuming that P ? NP, no algorithm that solves a CO problem classified as being NP-hard in polynomial time exists [GAR 79]. As a result, complete methods, in the worst case, may require an exponential computation time to generate an evincible optimal solution. When faced with large size, the time required for computation may be too high for practical purposes. Thus, research on approximate methods to solve CO problems, also in the bioinformatics field, has enjoyed increasing attention in recent decades. In contrast to complete methods, approximate algorithms produce, not necessarily optimal, solutions in relatively acceptable computation times. Moreover, note that in the context of a combinatorial optimization problem in bioinformatics, finding an optimal solution is often not as important as in other domains. This is due to the fact that often the available data are error prone.

In the following section, we will give a short introduction into some of the most important complete methods, including integer linear programming and dynamic programming. Afterward, some of the most popular approximate methods for combinatorial optimization are reviewed. Finally, the last part of this chapter outlines the string problems considered in this book.

1.1. Complete methods for combinatorial optimization

Many combinatorial optimization problems can be expressed in terms of an integer programming (IP) problem, in a way that involves maximizing or minimizing an objective function of a certain number of decision variables, subject to inequality and/or equality constraints and integrality restrictions on the decision variables.

Formally, we require the following ingredients:

1. 1) a n-dimensional vector , where each xj, j = 1, 2, . , n, is called a decision variable and x is called the decision vector;
2. 2) m scalar functions of the decision vector x;
3. 3) a m-dimensional vector , called the right-hand side vector;
4. 4) a scalar function of the decision vector x.

With these ingredients, an IP problem can be formulated mathematically as follows:

where ~ ? {=, =, =}. Therefore, the set

is called a feasible set and consists of all those points that satisfy the m constraints gi(x) ~ bi, i = 1, 2, . , m. Function z is called the objective function. A feasible point x* ? X, for which the objective function assumes the minimum (respectively maximum) value i.e. z(x*) = z(x) (respectively z(x*) = z(x)) for all x ? X is called an optimal solution for (IP).

In the special case where is a finite set, the (IP) problem is a CO problem. The optimization problems in the field of computational biology described in this book are concerned with strings and can be classified as CO problems. Most of them have a binary nature, i.e. a feasible solution to any of these problems is a n-dimensional vector x ? {0, 1}n, where for each xi it is necessary to choose between two possible choices. Classical binary CO problems are, for example, the 0/1 knapsack problem, assignment and matching problems, set covering, set packing and set partitioning problems [NEM 88, PAP 82].

In what follows, unless explicitly noted, we will refer to a general integer linear programming (ILP) problem in standard form:

where is the matrix of the technological coefficients aij, i = 1, 2, . , m, j = 1, 2, . , n, and are the m-dimensional array of the constant terms and the n-dimensional array of the objective function coefficients, respectively. Finally, is the n-dimensional array of the decision variables, each being non-negative and integer. ILP is linear since both the objective function [1.1] and the m equality constraints [1.2] are linear in the decision variables x1, . , xn.

Note that the integer constraints [1.3] define a lattice of points in n, some of them belonging to the feasible set X of ILP. Formally, , where (Figure 1.2).

Figure 1.2. Graphical representation of the feasible region X of a generic ILP problem: , where

Many CO problems are computationally intractable. Moreover, in contrast to linear programming problems that may be solved efficiently, for example by the simplex method, there is no single method capable of solving all of them efficiently. Since many of them exhibit special properties, because they are defined on networks with a special topology or because they are characterized by a special cost structure, the scientific community has historically lavished its efforts on the design and development of ad hoc techniques for specific problems. The remainder of this section is devoted to the description of mathematical programming methods and to dynamic programming.

1.1.1. Linear programming relaxation

A simple way to approximately solving an ILP using mathematical programming techniques is as follows:

a) Relax the integer constraints [1.3], obtaining the following continuous linear programming problem in the standard form:

ILP-c is called the linear programming relaxation of ILP. It is the problem that arises by the replacement of the integer constraints [1.3] by weaker...
