Algorithms for Communications Systems and their Applications
Description
The definitive guide to problem-solving in the design of communications systems
In Algorithms for Communications Systems and their Applications, 2nd Edition, authors Benvenuto, Cherubini, and Tomasin have delivered the ultimate and practical guide to applying algorithms in communications systems. Written for researchers and professionals in the areas of digital communications, signal processing, and computer engineering, Algorithms for Communications Systems presents algorithmic and computational procedures within communications systems that overcome a wide range of problems facing system designers.
New material in this fully updated edition includes:
- MIMO systems (Space-time block coding/Spatial multiplexing /Beamforming and interference management/Channel Estimation)
- OFDM and SC-FDMA (Synchronization/Resource allocation (bit and power loading)/Filtered OFDM)
- Improved radio channel model (Doppler and shadowing/mmWave)
- Polar codes (including practical decoding methods)
- 5G systems (New Radio architecture/initial access for mmWave/physical channels)
The book retains the essential coding and signal processing theoretical and operative elements expected from a classic text, further adopting the new radio of 5G systems as a case study to create the definitive guide to modern communications systems.
More details
Other editions
Additional editions
Persons
Nevio Benvenuto, Professor, DEI-Telecommunications Group, University of Padua, Italy. Nevio received his Ph.D. in engineering from the University of Massachusetts, Amherst, in 1983.
Giovanni Cherubini, IBM Research Zurich, Switzerland. Giovanni Cherubini received M.S. and Ph.D. degrees from the University of California, San Diego, in 1984 and 1986, respectively, all in Electrical Engineering.
Stefano Tomasin, Associate Professor, Department of Information Engineering, University of Padova, Italy. Stefano received the Ph.D. degree in Telecommunications Engineering from the University of Padova, Italy, in 2003.
Content
