Static and Dynamic Performance Limitations for High Speed D/A Converters
Springer (Publisher)
Published on 29. February 2004
Book
Hardback
XVI, 218 pages
978-1-4020-7761-6 (ISBN)
Description
Static and Dynamic Performance Limitations for High Speed D/A Converters
discusses the design and implementation of high speed current-steering CMOS digital-to-analog converters.
Starting from the definition of the basic specifications for a D/A converter, the elements determining the static and dynamic performance are identified. Different guidelines based on scientific derivations are suggested to optimize this performance. Furthermore, a new closed formula has been derived to account for the influence of the transistor mismatch on the achievable resolution of the current-steering D/A converter. To allow a thorough understanding of the dynamic behavior, a new factor has been introduced. Moreover, the frequency dependency of the output impedance introduces harmonic distortion components which can limit the maximum attainable spurious free dynamic range. Finally, the last part of the book gives an overview on different existing transistor mismatch models and the link with the static performance of the D/A converter.
Starting from the definition of the basic specifications for a D/A converter, the elements determining the static and dynamic performance are identified. Different guidelines based on scientific derivations are suggested to optimize this performance. Furthermore, a new closed formula has been derived to account for the influence of the transistor mismatch on the achievable resolution of the current-steering D/A converter. To allow a thorough understanding of the dynamic behavior, a new factor has been introduced. Moreover, the frequency dependency of the output impedance introduces harmonic distortion components which can limit the maximum attainable spurious free dynamic range. Finally, the last part of the book gives an overview on different existing transistor mismatch models and the link with the static performance of the D/A converter.
More details
Series
Edition
2004 ed.
Language
English
Place of publication
New York
United States
Target group
Professional and scholarly
Research
Product notice
sewn/stitched
Cloth over boards
Illustrations
XVI, 218 p.
Dimensions
Height: 241 mm
Width: 160 mm
Thickness: 18 mm
Weight
530 gr
ISBN-13
978-1-4020-7761-6 (9781402077616)
DOI
10.1007/978-1-4757-6579-3
Schweitzer Classification
Other editions
Additional editions

Anne van den Bosch | Michiel Steyaert | Willy M.C. Sansen
Static and Dynamic Performance Limitations for High Speed D/A Converters
E-Book
06/2013
Springer
€149.79
Available for download

Anne van den Bosch | Michiel Steyaert | Willy M.C. Sansen
Static and Dynamic Performance Limitations for High Speed D/A Converters
Book
12/2010
Springer
€160.49
Shipment within 15-20 days
Content
1 Introduction.- 2 The D/A Converter: Functionality and Specifications.- 3 CMOS D/A Converter Architectures.- 4 Static Behaviour of Current Steering D/A converters.- 5 Dynamic Behaviour of Current Steering D/A Converters.- 6 A Design Methodology for High Performance CMOS Current Steering D/A Converters.- 7 Realisations.- 8 Transistor Mismatch: Evolution and Relevance.- Appendix 1.- Appendix 2.
