Simulation Techniques and Solutions for Mixed-Signal Coupling in Integrated Circuits
Published on 10. October 2012
Book
Paperback/Softback
XXIII, 280 pages
978-1-4613-5942-5 (ISBN)
Description
The goal ofputting "systems on a chip" has been a difficultchallenge that is only recently beginning to be met. Since the world is "analog"putting systems on achip requires putting analog interfaces on the samechip as digital processing functions. Since some processing functions are accomplished more efficiently in analog cir- cuitry, chips with a large amountofanalog and digital circuitry are beingdesigned. Whethera small amountor analog circuitryiscombined with varying amounts ofdig- ital circuitry or the other way around, theproblems encountered in marrying analog and digital circuitryarethe samebutwith differentscope. Someofthe mostprevalent problems are chip/packagecapacitiveand inductivecoupling, ringing on the RLC tuned circuits thatfonn the chip/package powersupply rails and off-chip drivers and receivers, coupling betweencircuits through thechip substrate bulk, and radiated emissions from the chip/package interconnects. To aggravate the problemsofdesign- ers who have to deal with the complexityofmixed-signal coupling is the lackofveri- fication techniques to simulate the problem.
In addition to considering RLC models for the various chip/package/board level parasitics, mixed-signal circuitdesigners must also model coupling through the common substrate when simulating ICs to obtain an accurate estimateofcoupled noise in their designs. Unfortunately, accurate simulationofsubstratecoupling has only recently begun to receive attention andtech- niques for the same are not widely known. This bookaddresses two majorissuesofthe mixed-signal coupling problem - how to simulate it and how to overcome it. It identifies someofthe problems that will be encountered, gives examplesofactual hardware experiences, offers simulation te- xxi SIMULATION TECHNIQUES AND SOLUTIONS FOR MIXED-SIGNAL COUPLING IN IC. niquesandsuggestspossiblesolutions.
In addition to considering RLC models for the various chip/package/board level parasitics, mixed-signal circuitdesigners must also model coupling through the common substrate when simulating ICs to obtain an accurate estimateofcoupled noise in their designs. Unfortunately, accurate simulationofsubstratecoupling has only recently begun to receive attention andtech- niques for the same are not widely known. This bookaddresses two majorissuesofthe mixed-signal coupling problem - how to simulate it and how to overcome it. It identifies someofthe problems that will be encountered, gives examplesofactual hardware experiences, offers simulation te- xxi SIMULATION TECHNIQUES AND SOLUTIONS FOR MIXED-SIGNAL COUPLING IN IC. niquesandsuggestspossiblesolutions.
More details
Series
Edition
Softcover reprint of the original 1st ed. 1995
Language
English
Place of publication
New York
United States
Target group
Professional and scholarly
Research
Illustrations
XXIII, 280 p.
Dimensions
Height: 235 mm
Width: 155 mm
Thickness: 17 mm
Weight
470 gr
ISBN-13
978-1-4613-5942-5 (9781461359425)
DOI
10.1007/978-1-4615-2239-3
Schweitzer Classification
Other editions
Additional editions
Nishath K. Verghese | Timothy J. Schmerbeck | David J. Allstot
Simulation Techniques and Solutions for Mixed-Signal Coupling in Integrated Circuits
Book
12/1994
Kluwer Academic Publishers
€164.50
Shipment within 15-20 days
Content
1 Introduction.- 2 Sources of Noise and Methods of Coupling.- 2.1 Semiconductor Device Noise and Phenomena.- 2.2 Noise from Switching Voltage and Current.- 2.3 Inductive Coupling.- 2.4 Capacitive Coupling.- 2.5 Substrate Coupling.- 2.6 Summary.- 3 Semiconductor Device Simulation.- 3.1 Significance.- 3.2 Basic Equations.- 3.3 Boundary Conditions.- 3.4 Models of Physical Parameters.- 3.5 Spatial Discretization.- 3.6 Solution Methods.- 3.7 A Representative Example.- 3.8 Summary.- 4 Simplified Substrate Modeling and Rapid Simulation.- 4.1 Simplified Equation.- 4.2 Spatial Discretization.- 4.3 Boundary Conditions.- 4.4 Solution Methods.- 4.5 Asymptotic Waveform Evaluation (AWE).- 4.6 Substrate AWE Macromodels.- 4.7 Transient Simulation of AWE Macromodels.- 4.8 Substrate DC Macromodels.- 4.9 Matrix Solution.- 4.10 Results.- 4.11 Summary.- 5 Mesh Generation.- 5.1 Adaptive Mesh Refinement.- 5.2 A Priori Mesh Refinement.- 5.3 Summary.- 6 Substrate Modeling in Heavily-Doped Bulk Processes.- 6.1 Motivation.- 6.2 Single Node Substrate Model.- 6.3 Modified Single Node Substrate Model.- 6.4 Summary.- 7 Substrate Resistance Extraction for Large Circuits.- 7.1 Nested Macromodeling.- 7.2 Interpolated Macromodeling.- 7.3 Summary.- 8 Modeling Chip/Package Power Distribution.- 8.1 Effect of Power Bus Structure on Noise coupling.- 8.2 Summary.- 9 Controlling Substrate Coupling in Heavily-Doped Bulk Processes.- 9.1 Characterization of noise coupling concepts.- 9.2 P+ Bulk Wafer Characterization.- 9.3 Effect of Substrate contact placement on coupled noise.- 9.4 Effect of Package Inductance on Substrate noise.- 9.5 Noise Coupling Control Techniques.- 9.6 Summary.- 10 Controlling Substrate Coupling in Bulk P- Wafers.- 10.1 Bulk P- Wafer Characteristics.- 10.2 Substrate Attenuation Structures.-10.3 Summary.- 11 Chip/Package Shielding and Good Circuit Design Practice.- 11.1 Far Field Radiated Emissions.- 11.2 Effect of Chip Signal Isolation/Shielding Techniques on Noise.- 11.3 Effect of Packaging on Noise.- 11.4 Effect of Card Layout and Referencing on Noise.- 11.5 Effect of Circuit Topology on Noise.- 11.6 Summary.- 12 A Design Example.- 12.1 Design of a Mixed-Signal IC.- 12.2 Summary.- Appendices.- A Mesh Moments.- B Convergence Behaviour of Iterative Methods.
