OLED Display Fundamentals and Applications
2nd Edition
Published on 9. June 2017
Book
Hardback
312 pages
978-1-119-18731-8 (ISBN)
Description
This new edition specifically addresses the most recent and relevant developments in the design and manufacture of OLED displays
* Provides knowledge of OLED fundamentals and related technologies for applications such as displays and solid state lighting along with processing and manufacturing technologies
* Serves as a reference for people engaged in OLED research, manufacturing, applications and marketing
* Includes coverage of white + color filter technology, which has become industry standard technology for large televisions
More details
Series
Edition
2. Auflage
Language
English
Place of publication
New York
United States
Target group
Professional and scholarly
Product notice
sewn/stitched
Cloth over boards
Dimensions
Height: 240 mm
Width: 161 mm
Thickness: 21 mm
Weight
630 gr
ISBN-13
978-1-119-18731-8 (9781119187318)
Schweitzer Classification
Other editions
Additional editions
Takatoshi Tsujimura
OLED Display Fundamentals and Applications
E-Book
03/2017
2nd Edition
Wiley
€93.99
Available for download
Takatoshi Tsujimura
OLED Display Fundamentals and Applications
E-Book
02/2017
2nd Edition
Wiley
€93.99
Available for download
Previous edition
Book
07/2012
Wiley
€73.90
Article exhausted; check for reprint
Person
Takatoshi Tsujimura is General Manager of the Konica Minolta Inc. He received an SID award for the development of the world's largest 20-inch OLED prototype and also received SID Fellow award for the development of 100% NTSC white + color filter technology. He has worked for Kodak and IBM and is an SID executive. Dr. Tsujimura was selected as one of the "10 best engineers/researchers in the 10 best Japanese companies" by Nikkei Electronics magazine.
