Basic Digital Electronics
J.A. Strong(Editor)
Chapman and Hall (Publisher)
Published on 7. February 1991
Book
Paperback/Softback
XII, 220 pages
978-0-412-39990-9 (ISBN)
Description
Modern electronics is the most visible result of research in solid state physics. Transistors and integrated circuits are used everywhere in ever increasing numbers. The microprocessor controlled coffee-pot exists. Most experimental physicists, and, indeed, experimental scientists in most disciplines, study their subject with the aid of apparatus containing significant amounts of electronics and much of that electronics is digital. In order to design experiments and apparatus or simply to understand how a piece of equipment works, an under standing of electronics has become increasingly important. In recognition that electronics has pervaded so many areas, courses in digital electronics are now a recommended part of physics and many other science degree courses. At the introductory level, digital electronics is, primarily, a practical subject with relatively few basic concepts and any complex ity arises from the coupling together of many simple circuits and the extensive use of feedback. Designing an electronic circuit and then getting it to work correctly provides an experience, and a sense of achievement, which is significantly different from most undergradu ate work as it more closely resembles project work than standard laboratory practicals.
More details
Series
Language
English
Place of publication
Dordrecht
Netherlands
Target group
Professional and scholarly
Research
Illustrations
XII, 220 p.
Dimensions
Height: 216 mm
Width: 140 mm
Thickness: 13 mm
Weight
298 gr
ISBN-13
978-0-412-39990-9 (9780412399909)
DOI
10.1007/978-94-011-3118-6
Schweitzer Classification
Content
1 Introduction.- 2 Basic gates.- 3 Gating circuits.- 4 Latches and flip-flops.- 5 Registers and counters.- 6 Memories.- 7 The analogue connection.- Appendix 1 Boolean algebra.- A1.1 Rules.- A1.2 Algebraic minimization.- A1.3 Minimization in product-of-sums form.- Appendix 2 Logic families.- A2.1 TTL circuits.- A2.2 Open-collector output.- A2.3 Tri-state output.- A2.4 Schmitt trigger inputs.- A2.5 Schottky TTL.- A2.6 Emitter-coupled logic (ECL).- A2.7 MOS logic.- A2.8 Conversion between TTL and CMOS.- A2.9 A CMOS oscillator circuit.- Appendix 3 Designing and testing.- A3.1 Designs and diagrams.- A3.2 Prototyping methods.- A3.3 Testing.- Answers to problems.- Further reading.
