Introduction to Adaptive Lenses
Will be published approx. on 15. May 2012
Book
Hardback
286 pages
978-1-118-01899-6 (ISBN)
Description
Presents readers with the basic science, technology, and applications for every type of adaptive lens
An adaptive lens is a lens whose shape has been changed to a different focal length by an external stimulus such as pressure, electric field, magnetic field, or temperature. Introduction to Adaptive Lenses is the first book ever to address all of the fundamental operation principles, device characteristics, and potential applications of various types of adaptive lenses.
This comprehensive book covers basic material properties, device structures and performance, image processing and zooming, optical communications, and biomedical imaging. Readers will find homework problems and solutions included at the end of each chapter--and based on the described device structures, they will have the knowledge to fabricate adaptive lenses for practical applications or develop new adaptive devices or concepts for advanced investigation.
Introduction to Adaptive Lenses includes chapters on:
* Optical lenses
* Elastomeric membrane lenses
* Electro-wetting lenses
* Dielectrophoretic lenses
* Mechanical-wetting lenses
* Liquid crystal lenses
This is an important reference for optical engineers, research scientists, graduate students, and undergraduate seniors.
Reviews / Votes
"The description of each is very thorough and well-referenced. Ren and Wu have made liberal use of diagrams and images, making the book easy to understand. Readers will find it stimulating and informative." (Optics & Photonics News, 1 February 2013)More details
Series
Edition
1. Auflage
Language
English
Place of publication
New York
United States
Target group
Professional and scholarly
College/higher education
Product notice
sewn/stitched
Cloth over boards
Dimensions
Height: 244 mm
Width: 161 mm
Thickness: 22 mm
Weight
542 gr
ISBN-13
978-1-118-01899-6 (9781118018996)
Schweitzer Classification
Other editions
Additional editions
Hongwen Ren | Shin-Tson Wu
Introduction to Adaptive Lenses
E-Book
03/2012
Wiley
€110.99
Available for download
Hongwen Ren | Shin-Tson Wu
Introduction to Adaptive Lenses
E-Book
03/2012
Wiley
€107.99
Available for download
Persons
HONGWEN REN, PhD, is an associate professor in the Department of Polymer-Nano Science Technology at Chonbuk National University in South Korea. A former research scientist at the University of Central Florida's College of Optics and Photonics, Dr. Ren has published over fifty journal papers, one book chapter, and obtained eight U.S. patents.
SHIN-TSON WU, PhD, is a Pegasus Professor at CREOL, the College of Optics and Photonics, University of Central Florida. He is a recipient of the 2011 SID Slottow-Owaki Prize, 2010 OSA Joseph Fraunhofer Award/Robert M. Burley Prize, 2008 SPIE G. G. Stokes Award, and 2008 SID Jan Rajchman Prize. He is a Fellow of the IEEE, OSA, SID, and SPIE. Dr. Wu has coauthored six books and over 400 journal papers, and holds over seventy issued U.S. patents. He was also the founding editor-in-chief of the IEEE/OSA Journal of Display Technology.
Content
