Power Quality Improvement Using Unified Power Quality Controller

The L-C series-filter and passive double-resonant circuits (PDR) are then discussed, along with the key circuit components of the design, the series inductor (LL) circuit, the PDR passive low-pass, and the passive double resonant circuit design for applying the induct filtering. After all, the proof of results in the high voltage delivery validation using UPQC in MATLAB/Simulink, IHUPQC has been demonstrated, 10kV distribution now is supported. With these effects, it being effective in regulating voltage and current and dynamic power generation, the simulation results show the performance of dynamic grid voltage & current regulation and dynamic load-harmonic regulation.
