A Quick Guide to Pressure Relief Valves (PRVs)
1st Edition
Published on 11. November 2004
Book
Paperback/Softback
160 pages
978-1-86058-457-2 (ISBN)
Description
This indispensable book systematically guides you through Pressure Relief Valves and how they work. It shows how protective devices perform an important function in preventing the accumulation of overpressure that can result in failure and the uncontrolled release of stored energy. They are therefore categorised as safety critical items of engineering equipment. The book goes on to show that their design and testing is heavily controlled by published technical standards because many countries are covered by statutory legislation.
The content of the book shows that service damage and degradation mechanisms are outlined for various applications - PRVs and bursting discs are used in a wide variety of process conditions, ranging from clean service to heavily corrosive process fluids. This results in a correspondingly large number of damage mechanisms that can prevent them from working if they are not inspected and tested correctly. Risk based inspection procedures are introduced in this book as a method of minimising the chances of failure, and therefore maintaining high levels of safety.
This Quick Guide to Pressure Relief Valves is intended to provide easily accessible technical information for engineers and technicians involved in the operation, testing and maintenance of pressure systems. It also covers other types of protective devises such as bursting discs.
The content of the book shows that service damage and degradation mechanisms are outlined for various applications - PRVs and bursting discs are used in a wide variety of process conditions, ranging from clean service to heavily corrosive process fluids. This results in a correspondingly large number of damage mechanisms that can prevent them from working if they are not inspected and tested correctly. Risk based inspection procedures are introduced in this book as a method of minimising the chances of failure, and therefore maintaining high levels of safety.
This Quick Guide to Pressure Relief Valves is intended to provide easily accessible technical information for engineers and technicians involved in the operation, testing and maintenance of pressure systems. It also covers other types of protective devises such as bursting discs.
More details
Series
Language
English
Place of publication
New York
United States
Target group
Professional and scholarly
Product notice
Paperback (trade)
Unsewn / adhesive bound
Dimensions
Height: 169 mm
Width: 103 mm
Thickness: 12 mm
Weight
143 gr
ISBN-13
978-1-86058-457-2 (9781860584572)
Copyright in bibliographic data and cover images is held by Nielsen Book Services Limited or by the publishers or by their respective licensors: all rights reserved.
Schweitzer Classification
Person
Cliff Matthews BSc, CEng, MBA, FIMechE is an experienced engineer with a wide knowledge of the inspection of pressure systems and the interpretation of engineering codes and standards.
