Metamaterials with Negative Parameters
Theory, Design, and Microwave Applications
1st Edition
Published on 8. February 2008
Book
Hardback
336 pages
978-0-471-74582-2 (ISBN)
Description
The first general textbook to offer a complete overview of metamaterial theory and its microwave applications Metamaterials with Negative Parameters represents the only unified treatment of metamaterials available in one convenient book. Devoted mainly to metamaterials that can be characterized by a negative effective permittivity and/or permeability, the book includes a wide overview of the most important topics, scientific fundamentals, and technical applications of metamaterials.
Chapter coverage includes: the electrodynamics of left-handed media, synthesis of bulk metamaterials, synthesis of metamaterials in planar technology, microwave applications of metamaterial concepts, and advanced and related topics, including SRR- and CSRR-based admittance surfaces, magneto- and electro-inductive waves, and sub-diffraction imaging devices. A list of problems and references is included at the end of each chapter, and a bibliography offers a complete, up-to-daterepresentation of the current state of the art in metamaterials.
Geared toward students and professionals alike, Metamaterials with Negative Parameters is an ideal textbook for postgraduate courses and also serves as a valuable introductory reference for scientists and RF/microwave engineers.
Chapter coverage includes: the electrodynamics of left-handed media, synthesis of bulk metamaterials, synthesis of metamaterials in planar technology, microwave applications of metamaterial concepts, and advanced and related topics, including SRR- and CSRR-based admittance surfaces, magneto- and electro-inductive waves, and sub-diffraction imaging devices. A list of problems and references is included at the end of each chapter, and a bibliography offers a complete, up-to-daterepresentation of the current state of the art in metamaterials.
Geared toward students and professionals alike, Metamaterials with Negative Parameters is an ideal textbook for postgraduate courses and also serves as a valuable introductory reference for scientists and RF/microwave engineers.
More details
Series
Language
English
Place of publication
United States
Publishing group
John Wiley & Sons Inc
Target group
Professional and scholarly
Product notice
sewn/stitched
Cloth over boards
Dimensions
Height: 240 mm
Width: 161 mm
Thickness: 23 mm
Weight
668 gr
ISBN-13
978-0-471-74582-2 (9780471745822)
Copyright in bibliographic data and cover images is held by Nielsen Book Services Limited or by the publishers or by their respective licensors: all rights reserved.
Schweitzer Classification
Other editions
Additional editions
Ricardo Marques | Ferran Martin | Mario Sorolla
Metamaterials with Negative Parameters
Theory, Design, and Microwave Applications
E-Book
09/2011
Wiley
€116.99
Available for download
Ricardo Marques | Ferran Martin | Mario Sorolla
Metamaterials with Negative Parameters
Theory, Design, and Microwave Applications
E-Book
02/2008
Wiley
€112.99
Available for download
Persons
Ricardo Marques is a Professor in the Departamento de Electronica y Electromagnetismo at the Universidad de Sevilla in Spain. Ferran Martin is a Professor in the Departament d'Enginyeria Electr?nica at the Universitat Autnoma de Barcelona in Spain.
Mario Sorolla is a Professor in the Departamento de Ingenieria Electrica yElectronica at the Universidad Publica de Navarra in Spain.
Professors Marques, Martin, and Sorolla have coauthored more than fifty research works in the field of metamaterials, published in relevant journals and conference proceedings, and have been responsible for various domestic and international projects. They hold several patents related to metamaterial applications.
Mario Sorolla is a Professor in the Departamento de Ingenieria Electrica yElectronica at the Universidad Publica de Navarra in Spain.
Professors Marques, Martin, and Sorolla have coauthored more than fifty research works in the field of metamaterials, published in relevant journals and conference proceedings, and have been responsible for various domestic and international projects. They hold several patents related to metamaterial applications.
Content
Dedicatory. Acknowledgements.
Preface.
1. The electrodynamics of left-handed media.
1.1. Wave propagation in left-handed media.
1.2. Energy density and group velocity.
1.3. Negative refraction.
1.4. Fermat principle.
1.5. Other effects in left-handed media.
1.5.1. Inverse Doppler effect.
1.5.2. Backward Cerenkov radiation.
1.5.3. Negative Goos-Haenchen shift.
1.6. Waves at interfaces..
1.6.1. Transmission and reflection coefficients.
1.6.2. Surface waves.
1.7. Waves through left-handed slabs..
1.7.1. Transmission and reflection coefficients.
1.7.2. Guided waves.
1.7.3. Backward leaky and complex waves.
1.8. Slabs with ?/?o-1 and ?/?o-1.
1.8.1. Phase compensation and amplification of evanescent modes.
1.8.2. Perfect tunneling.
1.8.3. The perfect lens.
1.8.4. The perfect-lens as a tunneling/matching device.
1.9. Losses and dispersion.
1.10. Indefinite media.
1.11. Problems.
References.
2. Synthesis of bulk metamaterials.
2.1. Scaling plasmas at microwave frequencies.
2.1.1. Metallic waveguides and plates as one- and two-dimensional plasmas.
2.1.2. Wire media.
2.1.3. Spatial dispersion in wire media.
2.2. Synthesis of negative magnetic permeability.
2.2.1. Analysis of the edge-coupled SRR.
2.2.2. Other SRR designs.
The broadside-coupled SRR.
The non-bianisotropic SRR.
The double split SRR.
Spirals.
2.2.3. Constitutive relationships for bulk SRR metamaterials.
2.2.4. Higher order resonances in SRRs.
2.2.5. Isotropic SRRs.
2.2.6. Scaling down SRRs to infrared and optical frequencies.
2.3. SRR-based left-handed metamaterials..
2.3.1. One-dimensional SRR-based left-handed metamaterials.
2.3.2. Two-dimensional and three-dimensional SRR-based lefthanded metamaterials.
2.3.3. On the application of the continuous medium approach to discrete SRR-based left-handed metamaterials.
2.3.4. The ?superposition? hypothesis..
2.3.5. On the numerical accuracy of the developed model for SRR-based metamaterials.
2.4. Other approaches to bulk metamaterial design.
2.4.1. Ferrite metamaterials.
2.4.2. Chiral metamaterials.
2.4.3. Other proposals.
2.5. Appendix.
2.6. Problems.
References.
3. Synthesis of metamaterials in planar technology.
3.1. The dual (backward) transmission line concept.
3.2. Practical implementation of backward transmission lines.
3.3. Two-dimensional (2D) planar metamaterials.
3.4. Design of left handed transmission lines by means of SRRs: the resonant type approach.
3.4.1. Effective negative permeability transmission lines.
3.4.2. Left handed transmission lines in microstrip and CPW technologies.
3.4.3. Size reduction.
3.5. Equivalent circuit models for SRRs coupled to conventional transmission lines.
3.5.1. Dispersion diagrams.
3.5.2. Implications of the model.
3.6. Duality and complementary split rings resonators (CSRRs).
3.6.1. Electromagnetic properties of CSRRs.
3.6.2. Numerical calculation and experimental validation.
3.7. Synthesis of metamaterial transmission lines by using CSRRs.
3.7.1. Negative permittivity and left handed transmission lines.
3.7.2. Equivalent circuit models for CSRR loaded transmission lines.
3.7.3. Parameter extraction.
3.7.4. Effects of cell geometry on frequency response.
3.8. Comparison between the circuit models of resonant type and dual left handed lines.
Problems.
References.
4. Microwave applications of metamaterial concepts.
4.1. Filters and diplexers.
4.1.1. Stop band filters.
4.1.2. Planar filters with improved stop band.
4.1.3. Narrow band pass filter and diplexer design.
4.1.3.1. Band pass filters based on alternate right/left handed (ARLH) sections implemented by means of SRRs.
4.1.3.2. Band pass filters and diplexers based on alternate right/left handed (ARLH) sections implemented by means of CSRRs.
4.1.4. CSRR-based band pass filters with controllable characteristics.
4.1.4.1. Band pass filters based on the hybrid approach: design methodology and illustrative examples.
4.1.4.2. Other CSRR-based filters implemented by means of right handed sections.
4.1.5. High pass filters and ultra wide band pass filters (UWBPFs) implemented by means of resonant type balanced CRLH metamaterial transmission lines.
4.1.6. Tunable filters based on varactor-loaded split rings resonators (VLSRRs).
4.1.6.1. Topology of the VLSRR and equivalent circuit model.
4.1.6.2. Validation of the model.
4.1.6.3. Some illustrative results: tunable notch filters and stop band filters.
4.2. Synthesis of metamaterial transmission lines with controllable characteristics and applications.
4.2.1. Miniaturization of microwave components.
4.2.2. Compact broadband devices.
4.2.3. Dual band components.
4.2.4. Coupled line couplers.
4.3. Antenna applications.
Problems.
References.
5. Advanced and related topics.
5.1. SRR and CSRR based admittance surfaces.
5.1.1. Babinet principle for a single split rings resonator.
5.1.2. Surface admittance approach for SRR planar arrays.
5.1.3. Babinet principle for CSRR planar arrays.
5.1.4. Behavior at normal incidence.
5.1.5. Behavior at general incidence.
5.2. Magneto- and electro-inductive waves.
5.2.1. The magneto-inductive wave equation.
5.2.2. Magneto-inductive surfaces.
5.2.3. Electro-inductive waves in CSRR arrays.
5.2.4. Applications of magneto- and electro-inductive waves.
5.3. Sub-diffraction imaging devices.
5.3.1. Some universal features of sub-diffraction imaging devices.
5.3.2. Imaging in the quasi-electrostatic limit. Role of surface plasmons.
5.3.3. Imaging in the quasi-magnetostatic limit. Role of magnetostatic surface waves.
5.3.4. Imaging by resonant impedance surfaces. Magneto-inductive lenses.
5.3.5. Canalization devices.
5.4. Problems.
References.
Preface.
1. The electrodynamics of left-handed media.
1.1. Wave propagation in left-handed media.
1.2. Energy density and group velocity.
1.3. Negative refraction.
1.4. Fermat principle.
1.5. Other effects in left-handed media.
1.5.1. Inverse Doppler effect.
1.5.2. Backward Cerenkov radiation.
1.5.3. Negative Goos-Haenchen shift.
1.6. Waves at interfaces..
1.6.1. Transmission and reflection coefficients.
1.6.2. Surface waves.
1.7. Waves through left-handed slabs..
1.7.1. Transmission and reflection coefficients.
1.7.2. Guided waves.
1.7.3. Backward leaky and complex waves.
1.8. Slabs with ?/?o-1 and ?/?o-1.
1.8.1. Phase compensation and amplification of evanescent modes.
1.8.2. Perfect tunneling.
1.8.3. The perfect lens.
1.8.4. The perfect-lens as a tunneling/matching device.
1.9. Losses and dispersion.
1.10. Indefinite media.
1.11. Problems.
References.
2. Synthesis of bulk metamaterials.
2.1. Scaling plasmas at microwave frequencies.
2.1.1. Metallic waveguides and plates as one- and two-dimensional plasmas.
2.1.2. Wire media.
2.1.3. Spatial dispersion in wire media.
2.2. Synthesis of negative magnetic permeability.
2.2.1. Analysis of the edge-coupled SRR.
2.2.2. Other SRR designs.
The broadside-coupled SRR.
The non-bianisotropic SRR.
The double split SRR.
Spirals.
2.2.3. Constitutive relationships for bulk SRR metamaterials.
2.2.4. Higher order resonances in SRRs.
2.2.5. Isotropic SRRs.
2.2.6. Scaling down SRRs to infrared and optical frequencies.
2.3. SRR-based left-handed metamaterials..
2.3.1. One-dimensional SRR-based left-handed metamaterials.
2.3.2. Two-dimensional and three-dimensional SRR-based lefthanded metamaterials.
2.3.3. On the application of the continuous medium approach to discrete SRR-based left-handed metamaterials.
2.3.4. The ?superposition? hypothesis..
2.3.5. On the numerical accuracy of the developed model for SRR-based metamaterials.
2.4. Other approaches to bulk metamaterial design.
2.4.1. Ferrite metamaterials.
2.4.2. Chiral metamaterials.
2.4.3. Other proposals.
2.5. Appendix.
2.6. Problems.
References.
3. Synthesis of metamaterials in planar technology.
3.1. The dual (backward) transmission line concept.
3.2. Practical implementation of backward transmission lines.
3.3. Two-dimensional (2D) planar metamaterials.
3.4. Design of left handed transmission lines by means of SRRs: the resonant type approach.
3.4.1. Effective negative permeability transmission lines.
3.4.2. Left handed transmission lines in microstrip and CPW technologies.
3.4.3. Size reduction.
3.5. Equivalent circuit models for SRRs coupled to conventional transmission lines.
3.5.1. Dispersion diagrams.
3.5.2. Implications of the model.
3.6. Duality and complementary split rings resonators (CSRRs).
3.6.1. Electromagnetic properties of CSRRs.
3.6.2. Numerical calculation and experimental validation.
3.7. Synthesis of metamaterial transmission lines by using CSRRs.
3.7.1. Negative permittivity and left handed transmission lines.
3.7.2. Equivalent circuit models for CSRR loaded transmission lines.
3.7.3. Parameter extraction.
3.7.4. Effects of cell geometry on frequency response.
3.8. Comparison between the circuit models of resonant type and dual left handed lines.
Problems.
References.
4. Microwave applications of metamaterial concepts.
4.1. Filters and diplexers.
4.1.1. Stop band filters.
4.1.2. Planar filters with improved stop band.
4.1.3. Narrow band pass filter and diplexer design.
4.1.3.1. Band pass filters based on alternate right/left handed (ARLH) sections implemented by means of SRRs.
4.1.3.2. Band pass filters and diplexers based on alternate right/left handed (ARLH) sections implemented by means of CSRRs.
4.1.4. CSRR-based band pass filters with controllable characteristics.
4.1.4.1. Band pass filters based on the hybrid approach: design methodology and illustrative examples.
4.1.4.2. Other CSRR-based filters implemented by means of right handed sections.
4.1.5. High pass filters and ultra wide band pass filters (UWBPFs) implemented by means of resonant type balanced CRLH metamaterial transmission lines.
4.1.6. Tunable filters based on varactor-loaded split rings resonators (VLSRRs).
4.1.6.1. Topology of the VLSRR and equivalent circuit model.
4.1.6.2. Validation of the model.
4.1.6.3. Some illustrative results: tunable notch filters and stop band filters.
4.2. Synthesis of metamaterial transmission lines with controllable characteristics and applications.
4.2.1. Miniaturization of microwave components.
4.2.2. Compact broadband devices.
4.2.3. Dual band components.
4.2.4. Coupled line couplers.
4.3. Antenna applications.
Problems.
References.
5. Advanced and related topics.
5.1. SRR and CSRR based admittance surfaces.
5.1.1. Babinet principle for a single split rings resonator.
5.1.2. Surface admittance approach for SRR planar arrays.
5.1.3. Babinet principle for CSRR planar arrays.
5.1.4. Behavior at normal incidence.
5.1.5. Behavior at general incidence.
5.2. Magneto- and electro-inductive waves.
5.2.1. The magneto-inductive wave equation.
5.2.2. Magneto-inductive surfaces.
5.2.3. Electro-inductive waves in CSRR arrays.
5.2.4. Applications of magneto- and electro-inductive waves.
5.3. Sub-diffraction imaging devices.
5.3.1. Some universal features of sub-diffraction imaging devices.
5.3.2. Imaging in the quasi-electrostatic limit. Role of surface plasmons.
5.3.3. Imaging in the quasi-magnetostatic limit. Role of magnetostatic surface waves.
5.3.4. Imaging by resonant impedance surfaces. Magneto-inductive lenses.
5.3.5. Canalization devices.
5.4. Problems.
References.
