Heat Transfer 4
Convection, Two-Phase Flows and Special Problems
1st Edition
Published on 20. December 2022
Book
Hardback
192 pages
978-1-78630-879-5 (ISBN)
Description
Heat is a branch of thermodynamics that occupies a unique position due to its involvement in the field of practice. Being linked to the management, transport and exchange of energy in thermal form, it impacts all aspects of human life and activity.
Heat transfers are, by nature, classified as conduction, convection (which inserts conduction into fluid mechanics) and radiation. The importance of these three transfer methods has resulted - justifiably - in a separate volume being afforded to each of them, with the subject of convection split into two volumes. This fourth volume is dedicated to convection, more specifically, the problem of particular convective transfers. Twophase convection is considered and a more recent and much lesser-known field is presented, that of phase change transfer. Particular significance is given to numerical applications, allowing the reader to handle orders of magnitude, an important point in all physics.
Heat Transfer 4 combines a basic approach with a deeper understanding of the discipline and will therefore appeal to a wide audience, from technician to engineer, from doctoral student to teacher-researcher.
Heat transfers are, by nature, classified as conduction, convection (which inserts conduction into fluid mechanics) and radiation. The importance of these three transfer methods has resulted - justifiably - in a separate volume being afforded to each of them, with the subject of convection split into two volumes. This fourth volume is dedicated to convection, more specifically, the problem of particular convective transfers. Twophase convection is considered and a more recent and much lesser-known field is presented, that of phase change transfer. Particular significance is given to numerical applications, allowing the reader to handle orders of magnitude, an important point in all physics.
Heat Transfer 4 combines a basic approach with a deeper understanding of the discipline and will therefore appeal to a wide audience, from technician to engineer, from doctoral student to teacher-researcher.
More details
Language
English
Place of publication
London
United Kingdom
Target group
Professional and scholarly
Product notice
sewn/stitched
Cloth over boards
Dimensions
Height: 240 mm
Width: 161 mm
Thickness: 15 mm
Weight
445 gr
ISBN-13
978-1-78630-879-5 (9781786308795)
Copyright in bibliographic data and cover images is held by Nielsen Book Services Limited or by the publishers or by their respective licensors: all rights reserved.
Schweitzer Classification
Other editions
Additional editions
E-Book
12/2022
1st Edition
Wiley
€130.99
Available for download
E-Book
11/2022
1st Edition
Wiley
€126.99
Available for download
Persons
Michel Ledoux was Professor and Vice-President at the University of Rouen, France. He was also Director of the UMR CNRS CORIA, then Regional Delegate for Research and Technology in Upper Normandy, France. Specializing in fluid mechanics and transfers, he has worked in the fields of reactive boundary layers and spraying. Currently retired, he is an adviser to the Conservatoire National des Arts et Metiers in Normandy, collaborating with the Institute of Industrial Engineering Techniques (ITII) in Vernon, France.
Abdelkhalak El Hami is Full Professor of Universities at INSA-RouenNormandie, France. He is the author/co-author of several books and is responsible for several European pedagogical projects. He is a specialist in fluid structure interaction and problems of optimization and reliability in multi physical systems.
Abdelkhalak El Hami is Full Professor of Universities at INSA-RouenNormandie, France. He is the author/co-author of several books and is responsible for several European pedagogical projects. He is a specialist in fluid structure interaction and problems of optimization and reliability in multi physical systems.
