Nitride Semiconductor Light-Emitting Diodes (LEDs)
Materials, Technologies and Applications
Published on 19. August 2016
Book
Paperback/Softback
650 pages
978-0-08-101406-6 (ISBN)
Description
The development of nitride-based light-emitting diodes (LEDs) has led to advancements in high-brightness LED technology for solid-state lighting, handheld electronics, and advanced bioengineering applications. Nitride Semiconductor Light-Emitting Diodes (LEDs) reviews the fabrication, performance, and applications of this technology that encompass the state-of-the-art material and device development, and practical nitride-based LED design considerations.
Part one reviews the fabrication of nitride semiconductor LEDs. Chapters cover molecular beam epitaxy (MBE) growth of nitride semiconductors, modern metalorganic chemical vapor deposition (MOCVD) techniques and the growth of nitride-based materials, and gallium nitride (GaN)-on-sapphire and GaN-on-silicon technologies for LEDs. Nanostructured, non-polar and semi-polar nitride-based LEDs, as well as phosphor-coated nitride LEDs, are also discussed. Part two covers the performance of nitride LEDs, including photonic crystal LEDs, surface plasmon enhanced LEDs, color tuneable LEDs, and LEDs based on quantum wells and quantum dots. Further chapters discuss the development of LED encapsulation technology and the fundamental efficiency droop issues in gallium indium nitride (GaInN) LEDs. Finally, part three highlights applications of nitride LEDs, including liquid crystal display (LCD) backlighting, infrared emitters, and automotive lighting.
Nitride Semiconductor Light-Emitting Diodes (LEDs) is a technical resource for academics, physicists, materials scientists, electrical engineers, and those working in the lighting, consumer electronics, automotive, aviation, and communications sectors.
Part one reviews the fabrication of nitride semiconductor LEDs. Chapters cover molecular beam epitaxy (MBE) growth of nitride semiconductors, modern metalorganic chemical vapor deposition (MOCVD) techniques and the growth of nitride-based materials, and gallium nitride (GaN)-on-sapphire and GaN-on-silicon technologies for LEDs. Nanostructured, non-polar and semi-polar nitride-based LEDs, as well as phosphor-coated nitride LEDs, are also discussed. Part two covers the performance of nitride LEDs, including photonic crystal LEDs, surface plasmon enhanced LEDs, color tuneable LEDs, and LEDs based on quantum wells and quantum dots. Further chapters discuss the development of LED encapsulation technology and the fundamental efficiency droop issues in gallium indium nitride (GaInN) LEDs. Finally, part three highlights applications of nitride LEDs, including liquid crystal display (LCD) backlighting, infrared emitters, and automotive lighting.
Nitride Semiconductor Light-Emitting Diodes (LEDs) is a technical resource for academics, physicists, materials scientists, electrical engineers, and those working in the lighting, consumer electronics, automotive, aviation, and communications sectors.
More details
Series
Language
English
Place of publication
Cambridge
United Kingdom
Publishing group
Elsevier Science & Technology
Target group
Professional and scholarly
Product notice
Paperback (trade)
Dimensions
Height: 234 mm
Width: 156 mm
Thickness: 34 mm
Weight
928 gr
ISBN-13
978-0-08-101406-6 (9780081014066)
Copyright in bibliographic data and cover images is held by Nielsen Book Services Limited or by the publishers or by their respective licensors: all rights reserved.
Schweitzer Classification
Other editions
New editions
Jian-Jang Huang | Hao-chung Kuo | Shyh-Chiang Shen
Nitride Semiconductor Light-Emitting Diodes (LEDs)
Materials, Technologies, and Applications
Book
10/2017
2nd Edition
Woodhead Publishing Ltd
€303.50
Shipment within 15-20 days
Additional editions
Jian-Jang Huang | Hao-chung Kuo | Shyh-Chiang Shen
Nitride Semiconductor Light-Emitting Diodes (LEDs)
Materials, Technologies and Applications
E-Book
12/2013
Woodhead Publishing Ltd
€240.00
Available for download
Jian-Jang Huang | Hao-chung Kuo | Shyh-Chiang Shen
Nitride Semiconductor Light-Emitting Diodes (LEDs)
Materials, Technologies and Applications
Book
12/2013
Woodhead Publishing Ltd
€282.73
Withdrawn from sale
Persons
Prof. JianJang Huang received the B.S. degree in Electrical Engineering (EE) and the M.S. degree in Graduate Institute of Photonics and Optoelectronics (GIPO) from National Taiwan University (NTU), Taipei, Taiwan, in 1994 and 1996, respectively, and the Ph.D. degree in Electrical Engineering from the University of Illinois, Urbana-Champaign, in 2002. He had worked with WJ (Watkins Johnson) Communications in California, as a Staff Scientist from 2002 to 2004. He then came back to Taiwan in 2004 and is currently the professor at NTU EE and GIPO.
Prof. Huang has been involved in the development of optoelectronic and electronic devices. He has developed a spin-coating method for nanosphere lithography (NSL) to significantly improve the performance of light emitting diodes (LEDs), solar cells and nanorod devices. His NSL approach has been licensed to several LED companies in Taiwan. He has also fabricated and characterized IGZO TFTs and the corresponding circuits on glass and flexible substrates. In recent years, his group has spent great efforts in realizing cancer cell probes using ZnO nanorods, and high-sensitivity protein sensors based on IGZO TFTs.
Prof. Huang is a member of the Phi Tau Phi Scholastic Honor Society. He received "Wu Da-Yu? award in 2008, the most prestigious one for young researchers in Taiwan sponsored by National Science Council. And in the same year, he received the award for the most excellent young electrical engineer from the Chinese Institute of Electrical Engineering. He has served in several IPO committees in Taiwan Stock Exchange. He is currently the board director of GCS holdings in Torrance, CA, USA and the conference chair of SPIE, International Conference on Solid-State Lighting. Professor H. C. Kuo received the B.S. degree in Physics from National Taiwan University, Taiwan the M.S. degree in Electrical and computer engineering from Rutgers University in 1995, and the Ph.D. from Center of Compound Semiconductor Microelectronics (CCSM) of University of Illinois- Urbana Champaign in 1998. He has an extensive professional career both in research and industrial research institutions that includes: Research Consultant in Lucent Technologies, Bell Lab (1995-97); Member of Technical Staff in Fiber-optics Division at Agilent Technologies, USA (1999-2001) and Manager of LuxNet Corporation, USA (2001-2002). Since October, 2002 he joined National Chiao Tung University as a faculty member of Institute of Electro-Optical Engineering. Professor Kuo is a member of the IEEE and a recipient of Yang faculty Award from the Foundation for the Advancement of Outstanding Scholarship, he was author and co-author of 70 SCI journal papers and 80 international conference papers. Shyh-Chiang Shen received his B.S. and M.S. degrees, both in electrical engineering, from National Taiwan University in 1993 and 1995, respectively. He received his Ph.D. degree in electrical engineering at the University of Illinois at Urbana-Champaign (UIUC) in 2001. During his graduate study at the University of Illinois, he was involved in the development of low-voltage RF MEMS switches and ion-implanted GaAs MESFET using e-beam direct gate-writing photolithography techniques.
Dr. Shen joined Xindium Technologies, Inc. as a senior processing engineer in June 2001. He developed a proprietary high-performance InP SHBT technology for 40Gb/s OEIC applications and InP-based power HBT technology for wireless communications. In August 2004, he joined the HSIC group at the University of Illinois as a postdoctoral research associate to work on exciting research projects. In January 2005, he joined the Georgia Institute of Technology as an Assistant Professor. Dr. Shen holds 7 awarded U.S. patents in the MEMS and microelectronics areas. His current research is focused on wide bandgap semiconductor microelectronics and optoelectronic devices for high-energy-efficiency applications.
Prof. Huang has been involved in the development of optoelectronic and electronic devices. He has developed a spin-coating method for nanosphere lithography (NSL) to significantly improve the performance of light emitting diodes (LEDs), solar cells and nanorod devices. His NSL approach has been licensed to several LED companies in Taiwan. He has also fabricated and characterized IGZO TFTs and the corresponding circuits on glass and flexible substrates. In recent years, his group has spent great efforts in realizing cancer cell probes using ZnO nanorods, and high-sensitivity protein sensors based on IGZO TFTs.
Prof. Huang is a member of the Phi Tau Phi Scholastic Honor Society. He received "Wu Da-Yu? award in 2008, the most prestigious one for young researchers in Taiwan sponsored by National Science Council. And in the same year, he received the award for the most excellent young electrical engineer from the Chinese Institute of Electrical Engineering. He has served in several IPO committees in Taiwan Stock Exchange. He is currently the board director of GCS holdings in Torrance, CA, USA and the conference chair of SPIE, International Conference on Solid-State Lighting. Professor H. C. Kuo received the B.S. degree in Physics from National Taiwan University, Taiwan the M.S. degree in Electrical and computer engineering from Rutgers University in 1995, and the Ph.D. from Center of Compound Semiconductor Microelectronics (CCSM) of University of Illinois- Urbana Champaign in 1998. He has an extensive professional career both in research and industrial research institutions that includes: Research Consultant in Lucent Technologies, Bell Lab (1995-97); Member of Technical Staff in Fiber-optics Division at Agilent Technologies, USA (1999-2001) and Manager of LuxNet Corporation, USA (2001-2002). Since October, 2002 he joined National Chiao Tung University as a faculty member of Institute of Electro-Optical Engineering. Professor Kuo is a member of the IEEE and a recipient of Yang faculty Award from the Foundation for the Advancement of Outstanding Scholarship, he was author and co-author of 70 SCI journal papers and 80 international conference papers. Shyh-Chiang Shen received his B.S. and M.S. degrees, both in electrical engineering, from National Taiwan University in 1993 and 1995, respectively. He received his Ph.D. degree in electrical engineering at the University of Illinois at Urbana-Champaign (UIUC) in 2001. During his graduate study at the University of Illinois, he was involved in the development of low-voltage RF MEMS switches and ion-implanted GaAs MESFET using e-beam direct gate-writing photolithography techniques.
Dr. Shen joined Xindium Technologies, Inc. as a senior processing engineer in June 2001. He developed a proprietary high-performance InP SHBT technology for 40Gb/s OEIC applications and InP-based power HBT technology for wireless communications. In August 2004, he joined the HSIC group at the University of Illinois as a postdoctoral research associate to work on exciting research projects. In January 2005, he joined the Georgia Institute of Technology as an Assistant Professor. Dr. Shen holds 7 awarded U.S. patents in the MEMS and microelectronics areas. His current research is focused on wide bandgap semiconductor microelectronics and optoelectronic devices for high-energy-efficiency applications.
