Antenna Arrays
A Computational Approach
Published on 14. May 2010
Book
Hardback
552 pages
978-0-470-40775-2 (ISBN)
Description
A comprehensive tutorial on the design and practical applications of antenna arrays
An antenna array is an assembly of antenna elements that maximizes a received or transmitted signal in a desired direction. This practical book covers a wide range of antenna array topics that are becoming increasingly important in wireless applications, with emphasis on array design, applications, and computer modeling.
Each chapter in Antenna Arrays builds upon the previous chapter, progressively addressing more difficult material. Beginning with basic electromagnetics/antennas/antenna systems information, the book then deals with the analysis and synthesis of arrays of point sources and their associated array factors. It presents a sampling of different antenna elements that replace these point sources, then presents element configurations that do not have to lie along a line or in a plane.
The complex and difficult-to-predict interactions of elements and electromagnetic waves are introduced, along with computer modeling and experiments that are necessary for predicting the performance of arrays where mutual coupling is important. Then, various approaches to getting signals to and from the array elements to a computer where the signal detection takes place are explored, as are the numerical techniques behind smart antennas.
The book emphasizes the computational methods used in the design and analysis of array antennas. Also featured are signal processing and numerical modeling algorithms, as well as pictures of antenna arrays and components provided by industry and government sources, with explanations of how they operate.
Fully course-tested, Antenna Arrays serves as a complete text in phased array design and theory for advanced undergraduate- and graduate-level courses in electronics and communications, as well as a reference for practicing engineers and scientists in wireless communications, radar, and remote sensing.
More details
Series
Edition
1. Auflage
Language
English
Place of publication
United States
Publishing group
John Wiley & Sons Inc
Target group
College/higher education
Professional and scholarly
Product notice
Unsewn / adhesive bound
Paper over boards
Dimensions
Height: 240 mm
Width: 161 mm
Thickness: 34 mm
Weight
985 gr
ISBN-13
978-0-470-40775-2 (9780470407752)
Schweitzer Classification
Other editions
Additional editions
E-Book
09/2010
Wiley-IEEE Press
€144.99
Available for download
Person
Randy Haupt earned his PhD in electrical engineering at the University of Michigan in 1987. He has been Senior Scientist and Department Head of Computational Electromagnetics at the Applied Research Laboratory at Pennsylvania State University since 2004, and also a member of the Graduate Faculty in Electrical Engineering.
