Small Antenna Handbook
Published on 2. December 2011
Book
Hardback
360 pages
978-0-470-89083-7 (ISBN)
Description
Now in an completely revised, updated, and enlarged Second Edition, Small Antennas in Portable Devices reviews recent significant theoretical and practical developments in the electrically small antenna area. Examining antenna designs that work as well as those that have limitations, this new edition provides practicing engineers and upper level and graduate students with new information on: work on improving bandwidth using spherical helix dipoles; work on electromagnetically coupled structures; exact derivation of the Q for electrically small antennas for both the TE and TM modes; and a new simplified Q formula.
Reviews / Votes
"It could be used in a graduate course in statistics, or by statisticians who want to learn the reasoning behind the Bayesian methods." (IEEE Electrical Insulation Magazine, 1 May 2013)More details
Series
Edition
1. Auflage
Language
English
Place of publication
United States
Publishing group
John Wiley & Sons Inc
Target group
Professional and scholarly
Product notice
Unsewn / adhesive bound
Paper over boards
Dimensions
Height: 240 mm
Width: 161 mm
Thickness: 24 mm
Weight
710 gr
ISBN-13
978-0-470-89083-7 (9780470890837)
Schweitzer Classification
Other editions
Additional editions
Robert C. Hansen | Robert E. Collin
Small Antenna Handbook
E-Book
08/2011
Wiley
€131.99
Available for download
Robert C. Hansen | Robert E. Collin
Small Antenna Handbook
E-Book
08/2011
Wiley
€131.99
Available for download
Previous edition
Book
06/2006
1st Edition
Wiley
€99.90
Article exhausted; check for reprint
Persons
Robert C. Hansen, PhD, DEng, has had a long and distinguished career in the aerospace industry. Beginning in 1949, he held key posts in a number of leading aerospace companies, including The Aerospace Corp., STL, Inc. (now TRW), and Hughes Aircraft Co. He is a Fellow of IEEE and IEE and is a member of the National Academy of Engineering. Since 1971, Dr. Hansen has been a consulting engineer for antennas and systems-related problems.
The Late Robert Collin, PhD, taught at Case Reserve Western University, where he was chairman of the Department of Electrical Engineering and Applied Physics. He was an invited professor at Pontifical Catholic University of Rio de Janeiro; Telebras Research Center, Brazil; and Beijing University, China. Dr. Collin was the author or coauthor of five books and more than 150 technical papers.
Content
PREFACE xiii
1. QUALITY FACTORS OF ESA 1
1.1 Introduction / 1
1.2 Chu Antenna Q / 4
1.3 Collin and Rothschild Q Analysis / 8
1.4 Thal Antenna Q / 14
1.5 Radian Sphere with Mu and/or Epsilon: TE Modes / 16
1.6 Radian Sphere with Mu and/or Epsilon: TM Modes / 22
1.7 Effects of Core Losses / 28
1.8 Q for Spheroidal Enclosures / 34
References / 36
2. BANDWIDTH AND MATCHING 39
2.1 Introduction / 39
2.2 Foster's Reactance Theorem and Smith Chart / 39
2.3 Fano's Matching Limitations / 41
2.4 Matching Circuit Loss Magnification / 46
2.5 Network and Z0 Matching / 48
2.6 Non-Foster Matching Circuits / 50
2.7 Matched and High-Z Preamp Monopoles / 51
2.7.1 A Short Monopole Matched at One Frequency / 52
2.7.2 Short Monopole with High-Impedance Amplifier / 54
References / 55
3. ELECTRICALLY SMALL ANTENNAS: CANONICAL TYPES 59
3.1 Introduction / 59
3.2 Dipole Basic Characteristics / 59
3.2.1 Dipole Impedance and Bandwidth / 59
3.2.2 Resistive and Reactive Loading / 67
3.2.3 Other Loading Configurations / 76
3.2.4 Short Flat Resonant Dipoles / 78
3.2.5 Spherical Helix Antennas / 82
3.2.6 Multiple Resonance Antennas / 84
3.2.6.1 Spherical Dipole; Arc Antennas / 84
3.2.6.2 Multiple Mode Antennas / 86
3.2.6.3 Q Comparisons / 87
3.2.7 Evaluation of Moment Method Codes for Electrically Small Antennas / 88
3.3 Partial Sleeve, PIFA, and Patch / 93
3.3.1 Partial Sleeve / 93
3.3.2 PIFA Designs / 94
3.3.3 Patch with Permeable Substrate / 98
3.4 Loops / 101
3.4.1 Air Core Loops, Single and Multiple Turns / 101
3.4.2 Permeable Core Loops / 107
3.4.3 Receiving Loops / 114
3.4.4 Vector Sensor / 116
3.5 Dielectric Resonator Antennas / 120
References / 127
4. CLEVER PHYSICS, BUT BAD NUMBERS 135
4.1 Contrawound Toroidal Helix Antenna / 135
4.2 Transmission Line Antennas / 138
4.3 Halo, Hula Hoop, and DDRR Antennas / 138
4.4 Dielectric-Loaded Antennas / 140
4.5 Meanderline Antennas / 141
4.6 Cage Monopole / 142
References / 143
5. PATHOLOGICAL ANTENNAS 147
5.1 Crossed-Field Antenna / 147
5.2 Infinite Efficiency Antenna / 149
5.3 E-H Antenna / 150
5.4 TE-TM Antenna / 150
5.5 Crossed Dipoles / 151
5.6 Snyder Dipole / 152
5.7 Loop-Coupled Loop / 155
5.8 Multiarm Dipole / 158
5.9 Complementary Pair Antenna / 158
5.10 Integrated Antenna / 159
5.11 Q 1/4 0 Antenna / 160
5.12 Antenna in a NIM Shell / 161
5.13 Fractal Antennas / 162
5.14 Antenna on a Chip / 170
5.15 Random Segment Antennas / 171
5.16 Multiple Multipoles / 171
5.17 Switched Loop Antennas / 173
5.18 Electrically Small Focal Spots / 174
5.19 ESA Summary / 174
References / 175
6. SUPERDIRECTIVE ANTENNAS 181
6.1 History and Motivation / 181
6.2 Maximum Directivity / 182
6.2.1 Apertures / 182
6.2.2 Arrays / 183
6.2.2.1 Broadside Arrays of Fixed Spacing / 183
6.2.2.2 Endfire Arrays / 186
6.2.2.3 Minimization Codes / 192
6.2.2.4 Resonant Endfire Arrays / 192
6.3 Constrained Superdirectivity / 194
6.3.1 Dolph-Chebyshev Superdirectivity / 194
6.3.2 Superdirective Ratio Constraint / 198
6.3.3 Bandwidth or Q Constraint / 200
6.3.4 Phase or Position Adjustment / 200
6.3.5 Tolerance Constraint / 201
6.4 Bandwidth, Efficiency, and Tolerances / 201
6.4.1 Bandwidth / 201
6.4.2 Efficiency / 205
6.4.3 Tolerances / 208
6.5 Miscellaneous Superdirectivity / 209
6.6 Superdirective Antenna Summary / 210
References / 210
7. SUPERCONDUCTING ANTENNAS 215
7.1 Introduction / 215
7.2 Superconductivity Concepts for Antenna Engineers / 215
7.3 Dipole, Loop, and Patch Antennas / 221
7.3.1 Loop and Dipole Antennas / 222
7.3.2 Microstrip Antennas / 223
7.3.3 Array Antennas / 225
7.3.4 Millimeter-Wave Antennas / 229
7.3.4.1 Waveguide Flat Plane Array / 229
7.3.4.2 Microstrip Planar Array / 230
7.3.5 Submillimeter Antennas / 232
7.3.6 Low-Temperature Superconducting Antennas / 232
7.4 Phasers and Delay Lines / 233
7.5 Superconducting Antenna Summary / 236
References / 236
APPENDIX A A WORLD HISTORY OF ELECTRICALLY SMALL ANTENNAS 243
APPENDIX B DEFINITIONS OF TERMS USEFUL TO ESA 277
APPENDIX C SPHERICAL SHELL OF ENG METAMATERIAL SURROUNDING A DIPOLE ANTENNA 279
APPENDIX D FREQUENCY DISPERSION LIMITS RESOLUTION IN VESELAGO LENS 307
AUTHOR INDEX 335
SUBJECT INDEX 343
