Control of Switching Systems by Invariance Analysis
Applcation to Power Electronics
1st Edition
Will be published approx. on 26. July 2013
Book
Hardback
144 pages
978-1-84821-606-8 (ISBN)
Description
This book presents correct-by-design control techniques for switching systems, using different methods of stability analysis. Switching systems are increasingly used in the electronics and mechanical industries; in power electronics and the automotive industry, for example. This is due to their flexibility and simplicity in accurately controlling industrial mechanisms. By adopting appropriate control rules, we can steer a switching system to a region centered at a desired equilibrium point, while avoiding "unsafe" regions of parameter saturation.
The authors explain various correct-by-design methods for control synthesis, using different methods of stability and invariance analysis. They also provide several applications of these methods to industrial examples of power electronics.
The authors explain various correct-by-design methods for control synthesis, using different methods of stability and invariance analysis. They also provide several applications of these methods to industrial examples of power electronics.
More details
Language
English
Place of publication
London
United Kingdom
Target group
Professional and scholarly
Product notice
sewn/stitched
Cloth over boards
Dimensions
Height: 242 mm
Width: 155 mm
Thickness: 18 mm
Weight
399 gr
ISBN-13
978-1-84821-606-8 (9781848216068)
Copyright in bibliographic data and cover images is held by Nielsen Book Services Limited or by the publishers or by their respective licensors: all rights reserved.
Schweitzer Classification
Other editions
Additional editions
Laurent Fribourg | Romain Soulat
Control of Switching Systems by Invariance Analysis
Applcation to Power Electronics
E-Book
08/2013
Wiley-ISTE
€139.99
Available for download
Laurent Fribourg | Romain Soulat
Control of Switching Systems by Invariance Analysis
Applcation to Power Electronics
E-Book
08/2013
Wiley-ISTE
€139.99
Available for download
Persons
Laurent Fribourg is head of the LSV (Laboratoire Specification et Verification) and Scientific Coordinator of the Institut Farman, Institut Federatif de Recherche CNRS, which brings together the expertise of five laboratories from ENS Cachan, in France, in the fields of modeling, simulation and validation of complex systems. He has published over 70 articles in international journals and reviewed proceedings of international conferences, in the domain of the theory of formal methods and their applications.
Romain Soulat is in the third year of his doctorate at the LSV at ENS Cachan in France, under the supervision of Laurent Fribourg. He is working on the modeling and verification of hybrid systems. In particular, his interests concern robustness in scheduling problems - especially as part of a collaborative project with EADS Astrium on the verification of a component in the launcher for the future Ariane 6 rocket. He has published 5 articles in reviewed proceedings of international conferences.
Romain Soulat is in the third year of his doctorate at the LSV at ENS Cachan in France, under the supervision of Laurent Fribourg. He is working on the modeling and verification of hybrid systems. In particular, his interests concern robustness in scheduling problems - especially as part of a collaborative project with EADS Astrium on the verification of a component in the launcher for the future Ariane 6 rocket. He has published 5 articles in reviewed proceedings of international conferences.
