Phase Locked Loops
J. Encinas(Author)
Springer (Publisher)
Published on 24. September 2012
Book
Paperback/Softback
IX, 193 pages
978-1-4613-6337-8 (ISBN)
Article exhausted; check different version
Description
This book is devoted to a detailed and comprehensive study of phase locked loops aimed at preparing the reader to design them and to understand their applications. It is written at a level corresponding to a final year electronics undergraduate or a postgraduate student. Linear and semidigital phase locked loops are studied in nine chapters. Most of this book is concerned with analogue PLLs, but there are chapters on semidigital PLLs and on applications. The mathematical tools and background required are described at the end of the book. Important symbols A Amplifier gain Mixer gain (V -1) A Filter bandwidth (Hz) Bi Low pass filter bandwidth (Hz) BL Unilateral equivalent noise bandwidth (Hz) Bn D(s) Polynomial of variable s Peak amplitude of signal voltage (V) Ee Peak amplitude of reference signal voltage (V) Er Carrier frequency (Hz) Ie Intermediate frequency (Hz) Ii Intermediate frequency (Hz) IIF Local oscillator frequency (Hz) it Reference frequency (Hz) Ir F(s) Transfer function of loop filter G Amplifier voltage gain k FM modulator sensitivity (rad s -1 V -1) m K Motor coefficient (rad s -1) Back-electromotive force coefficient (V s rad -1) K1 Reverse back -electromotive force coefficient (rad V -1 S -1) Ke PC conversion gain (V rad s -1) Kd Motor torque coefficient (N m A -1) KM 1 1 VCO conversion gain (rads- V- ) Ko Conversion gain of PLL (S-2) Kv m Modulation factor m Integer n Integer n Loop order N ,N Integers representing division 1 2 1
Reviews / Votes
`A detailed and comprehensive study of phase locked loops aimed at preparing the reader to design them and to understand their applications.'British Book News
More details
Series
Edition
Softcover reprint of the original 1st ed. 1993
Language
English
Place of publication
NY
United States
Target group
Professional and scholarly
Research
Illustrations
IX, 193 p.
Dimensions
Height: 23.5 cm
Width: 15.5 cm
Weight
332 gr
ISBN-13
978-1-4613-6337-8 (9781461363378)
DOI
10.1007/978-1-4615-3064-0
Schweitzer Classification
Other editions
Additional editions

J. Encinas
Phase Locked Loops
Book
04/1993
Chapman and Hall
€171.19
Article exhausted; check different version
Content
Elementary study of the PLL. Methods of analysis of the linear PLL. Response to pulse signals. Response to sinusoidal signals. Acquisition. Noise. Linear PLL bipolar integrated circuits. Semi-digital PLLs. Applications. Appendix.
