Reservoir Simulation and Well Interference
Parent-Child, Multilateral Well and Fracture Interactions
1st Edition
Will be published approx. on 20. March 2020
Book
Hardback
400 pages
978-1-119-28344-7 (ISBN)
Description
Co-written by a world-renowned petroleum engineer, this breakthrough new volume teaches engineers how to configure, place and produce horizontal and multilateral wells in geologically complicated reservoirs, select optimal well spacings and fracture separations, and how to manage factors influencing well productivity using proven cost-effective and user-friendly simulation methods.
Charged in the 1990s with solving some of petroleum engineering's biggest problems that the industry deemed "unsolvable," the authors of this innovative new volume solved those problems, not just using a well-published math model, but one optimized to run rapidly, the first time, every time. This not only provides numerical output, but production curves and color pressure plots automatically. And each in a single hour of desk time.
Using their Multisim software that is featured in this volume, secondary school students at the Aldine Independent School District delivered professional quality simulations in a training program funded by some of the largest energy companies in the world. Think what you, as a professional engineer, could do in your daily work. Valuable with or without the software, this volume is the cutting-edge of reservoir engineering today, prefacing each chapter with a "trade journal summary" followed by hands-on details, allowing readers to replicate and extend results for their own applications.
This volume covers parent-child, multilateral well, and fracture flow interactions, reservoir flow analysis, many other issues involving fluid flow, fracturing, and many other common "unsolvable" problems that engineers encounter every day. It is a must-have for every engineer's bookshelf.
Charged in the 1990s with solving some of petroleum engineering's biggest problems that the industry deemed "unsolvable," the authors of this innovative new volume solved those problems, not just using a well-published math model, but one optimized to run rapidly, the first time, every time. This not only provides numerical output, but production curves and color pressure plots automatically. And each in a single hour of desk time.
Using their Multisim software that is featured in this volume, secondary school students at the Aldine Independent School District delivered professional quality simulations in a training program funded by some of the largest energy companies in the world. Think what you, as a professional engineer, could do in your daily work. Valuable with or without the software, this volume is the cutting-edge of reservoir engineering today, prefacing each chapter with a "trade journal summary" followed by hands-on details, allowing readers to replicate and extend results for their own applications.
This volume covers parent-child, multilateral well, and fracture flow interactions, reservoir flow analysis, many other issues involving fluid flow, fracturing, and many other common "unsolvable" problems that engineers encounter every day. It is a must-have for every engineer's bookshelf.
More details
Series
Language
English
Place of publication
United States
Publishing group
John Wiley & Sons Inc
Target group
Professional and scholarly
Product notice
sewn/stitched
Cloth over boards
Dimensions
Height: 235 mm
Width: 157 mm
Thickness: 26 mm
Weight
722 gr
ISBN-13
978-1-119-28344-7 (9781119283447)
Copyright in bibliographic data and cover images is held by Nielsen Book Services Limited or by the publishers or by their respective licensors: all rights reserved.
Schweitzer Classification
Other editions
Additional editions
Wilson C. Chin | Xiaoying Zhuang
Reservoir Simulation and Well Interference
Parent-Child, Multilateral Well and Fracture Interactions
E-Book
03/2020
1st Edition
Wiley
€206.99
Available for download
Wilson C. Chin | Xiaoying Zhuang
Reservoir Simulation and Well Interference
Parent-Child, Multilateral Well and Fracture Interactions
E-Book
02/2020
1st Edition
Wiley
€206.99
Available for download
Persons
Wilson C. Chin, PhD, is an experienced petroleum engineer with over twenty books published by Wiley-Scrivener and other leading publishers and over a hundred articles published in scientific journals. He holds four dozen domestic and international patents and has received five major awards with the United States Department of Energy. Mr. Chin's interests include reservoir simulation, measurement while drilling, borehole electromagnetics, managed pressure drilling, formation testing, downhole vibrations, and drilling and cementing rheology.
Xiaoying Zhuang has almost a decade of experience in borehole rheology and reservoir fluid mechanics. From 2009 to 2011, she served as Co-Investigator for the United States Department of Energy in their sponsored research into well control, leading to a well-received book appearing in English and Chinese on the subject. "Jenny" has co-authored ten papers in her areas of technical interest.
Xiaoying Zhuang has almost a decade of experience in borehole rheology and reservoir fluid mechanics. From 2009 to 2011, she served as Co-Investigator for the United States Department of Energy in their sponsored research into well control, leading to a well-received book appearing in English and Chinese on the subject. "Jenny" has co-authored ten papers in her areas of technical interest.
Content
Preface xi
Acknowledgements xv
1 Parent-Child, Multilateral Well and Fracture Flow Interactions 1
Additional questions raised 1
Problem identified 2
Why call them frac hits? 5
Is a frac hit model possible? 5
1.1 Reference 7
2 Reservoir Flow Analysis - Concise and Rigorous Summary 9
2.1 Governing Equations and Numerical Formulation 9
Steady flows of liquids 10
Difference equation formulation 10
The iterative scheme 12
Modeling well constraints for liquids 13
Steady and unsteady nonlinear gas flows 15
Steady gas flows 16
Well constraints for gas flows 18
Transient, compressible flows 19
Compaction, consolidation and subsidence 22
Boundary conforming grids 23
Stratigraphic meshes for layered media 24
Modeling wellbore storage 25
2.2 References 27
3 Reservoir Simulation - Strengths, Limitations and Strategies 28
Deficiencies affecting all simulators 28
3.1 Rectangular versus Curvilinear Coordinates 29
3.2 Fracture Simulations and Analytical Subtleties 33
Aerodynamic analogies 33
3.3 A Digression - Advances in Geometric Modeling 35
3.3.1 Airfoil and three-dimensional wing flows 35
3.3.2 Two dimensional planar reservoir flows 36
3.4 Formulation Errors in Commercial Simulators 40
Commingled reservoirs 40
Unit mobility flow 40
Well constraints, pressures and rates, kh products 40
Upscaling methods and averaging 41
Geometric gridding 42
Input/output issues and 3D color graphics 42
Matrix solvers and numerical inversion 42
Meaning of farfield boundary conditions 43
Grid density 43
Simulator design philosophy 44
3.5 References 45
4 Parent-Child Well and Fracture Flow - A Simple Steady-State Example 46
4.1 A Simple Example - Steady Flow Parent-Child Well and Fracture Interactions 46
Reference examples 47
More interesting calculations 47
Closing remarks 53
4.2 Two Reference Single-Well Analyses 54
Reference Example A 54
Reference Example B 57
4.3 Detailed Two-Well and Fracture Flow Analyses 59
Run 1 - Two wells, different pressure constraints, homogeneous medium 59
Run 2 - Two wells, identical pressure constraints in homogeneous isotropic medium 81
Run 3 - Return to Run 1 well constraints, with Wells 1 and 2 joined using uniform fracture 84
Run 4 - Incomplete fracture penetration at Well 1 91
Closing remarks 96
4.4 References 96
5 Hydraulic Fracture Flow for Horizontal Wells in Anisotropic Media 97
5.1 Horizontal or Multilateral Wells Intersected by General Hydraulic Fractures in Fully Transient Flow 97
Run 1 99
Runs 2, 3 and 4 101
5.2 Detailed Software Analysis 105
5.2.1 Run 1. No fractures along vertical-to-horizontal well (for reference baseline comparisons) 105
5.2.2 Run 2. Horizontal well intersected by a single hydraulic fracture 142
5.2.3 Run 3. Horizontal well intersecting two fracture planes 147
5.2.4 Run 4. Horizontal well intersecting three fractures 149
5.2.5 Runs 5-6. Effects of anisotropy and fracture orientation 153
Run 5 153
Run 6 155
5.3 References 157
6 Cube Models in Reservoir Development 158
6.1 Well Spacings, Parent-Child Effects and Reservoir Strategy in Modern Drilling 158
6.1.1 Basic optimization problems 158
6.1.2 Reservoir flow simulation versus statistical modeling approaches 160
6.1.3 Cube model set-up and computed results 161
6.1.4 Reservoir optimization and cost effectiveness 166
6.1.5 Closing remarks 168
6.1.6 References 169
6.2 Detailed Software Analysis 170
6.3 A More Optimal Production Method 197
6.4 References 200
7 Simulating While Drilling - Extending a Vertical Well Horizontally During Transient Production 201
7.1 Declining Production with Horizontal Lateral Solution 201
7.2 Detailed Software Analysis 207
7.3 References 236
8 Simulating While Drilling - Adding a Complicated Multilateral Well During Transient Production from a Vertical 237
8.1 Vertical and Subsequent Multilateral Neighboring Well 238
8.2 Detailed Software Analysis 243
8.3 References 264
9 Heterogeneous, Anisotropic, Layered Reservoir with Finite Tilted Fracture Plane Produced by Multilateral Wells 265
9.1 Five Comparative Production Scenarios 266
Run 1. Uniform isotropic reservoir (base reference) 267
Run 2. Effect of high permeability fracture on Run 1 272
Run 3. Highly heterogeneous three layer reservoir, isotropic flow within each sub-domain, no fracture planes 274
Run 4. Effect of anisotropy on Run 1 (again, uniform kx, ky, with kz 50% smaller), no fractures 276
Run 5. Nonlinear gas flows, results compared with Run 1 liquid baseline, assuming uniform kx, ky and kz, no fractures 278
Closing remarks 279
9.2 Detailed Software Analysis 280
Run 1. Uniform isotropic reservoir (base reference) 281
Layered geological description 281
Software caution 283
Layered drilling description 287
Layer results and flow decline curves 300
Run 2. Effect of high permeability fracture on Run 1 308
Run 3. Highly heterogeneous three layer reservoir, isotropic flow within each sub-domain, no fracture planes 312
Run 4. Effect of anisotropy on Run 1 (again, uniform kx, ky, with kz 50% smaller), no fractures 316
Run 5. Nonlinear gas flows, results compared with Run 1 liquid baseline, assuming uniform kx, ky and kz, no fractures 321
9.3 Closing Remarks 328
9.4 References 328
10 Advanced Reservoir Modeling with Multisim 329
10.1 Features 330
Reservoir Description 330
Well System Modeling 330
Additional Simulator Features 330
10.2 Licensing Options 331
Multisim 331
Complementary Models 331
4D TurboView 331
Fluid Tracer 331
Formation Testing Suite 331
10.3 Disclaimer 332
End-User License Agreement (EULA) 332
Grant of license 332
Descriptions of other rights and limitations 333
Termination 334
Copyright 334
No warranties 334
Limitation of liability 334
Further disclaimers 335
Additional restrictions 335
End of EULA 335
Cumulative References 336
Index 351
About the Authors 359
Wilson C. Chin 359
Xiaoying Zhuang 376
Acknowledgements xv
1 Parent-Child, Multilateral Well and Fracture Flow Interactions 1
Additional questions raised 1
Problem identified 2
Why call them frac hits? 5
Is a frac hit model possible? 5
1.1 Reference 7
2 Reservoir Flow Analysis - Concise and Rigorous Summary 9
2.1 Governing Equations and Numerical Formulation 9
Steady flows of liquids 10
Difference equation formulation 10
The iterative scheme 12
Modeling well constraints for liquids 13
Steady and unsteady nonlinear gas flows 15
Steady gas flows 16
Well constraints for gas flows 18
Transient, compressible flows 19
Compaction, consolidation and subsidence 22
Boundary conforming grids 23
Stratigraphic meshes for layered media 24
Modeling wellbore storage 25
2.2 References 27
3 Reservoir Simulation - Strengths, Limitations and Strategies 28
Deficiencies affecting all simulators 28
3.1 Rectangular versus Curvilinear Coordinates 29
3.2 Fracture Simulations and Analytical Subtleties 33
Aerodynamic analogies 33
3.3 A Digression - Advances in Geometric Modeling 35
3.3.1 Airfoil and three-dimensional wing flows 35
3.3.2 Two dimensional planar reservoir flows 36
3.4 Formulation Errors in Commercial Simulators 40
Commingled reservoirs 40
Unit mobility flow 40
Well constraints, pressures and rates, kh products 40
Upscaling methods and averaging 41
Geometric gridding 42
Input/output issues and 3D color graphics 42
Matrix solvers and numerical inversion 42
Meaning of farfield boundary conditions 43
Grid density 43
Simulator design philosophy 44
3.5 References 45
4 Parent-Child Well and Fracture Flow - A Simple Steady-State Example 46
4.1 A Simple Example - Steady Flow Parent-Child Well and Fracture Interactions 46
Reference examples 47
More interesting calculations 47
Closing remarks 53
4.2 Two Reference Single-Well Analyses 54
Reference Example A 54
Reference Example B 57
4.3 Detailed Two-Well and Fracture Flow Analyses 59
Run 1 - Two wells, different pressure constraints, homogeneous medium 59
Run 2 - Two wells, identical pressure constraints in homogeneous isotropic medium 81
Run 3 - Return to Run 1 well constraints, with Wells 1 and 2 joined using uniform fracture 84
Run 4 - Incomplete fracture penetration at Well 1 91
Closing remarks 96
4.4 References 96
5 Hydraulic Fracture Flow for Horizontal Wells in Anisotropic Media 97
5.1 Horizontal or Multilateral Wells Intersected by General Hydraulic Fractures in Fully Transient Flow 97
Run 1 99
Runs 2, 3 and 4 101
5.2 Detailed Software Analysis 105
5.2.1 Run 1. No fractures along vertical-to-horizontal well (for reference baseline comparisons) 105
5.2.2 Run 2. Horizontal well intersected by a single hydraulic fracture 142
5.2.3 Run 3. Horizontal well intersecting two fracture planes 147
5.2.4 Run 4. Horizontal well intersecting three fractures 149
5.2.5 Runs 5-6. Effects of anisotropy and fracture orientation 153
Run 5 153
Run 6 155
5.3 References 157
6 Cube Models in Reservoir Development 158
6.1 Well Spacings, Parent-Child Effects and Reservoir Strategy in Modern Drilling 158
6.1.1 Basic optimization problems 158
6.1.2 Reservoir flow simulation versus statistical modeling approaches 160
6.1.3 Cube model set-up and computed results 161
6.1.4 Reservoir optimization and cost effectiveness 166
6.1.5 Closing remarks 168
6.1.6 References 169
6.2 Detailed Software Analysis 170
6.3 A More Optimal Production Method 197
6.4 References 200
7 Simulating While Drilling - Extending a Vertical Well Horizontally During Transient Production 201
7.1 Declining Production with Horizontal Lateral Solution 201
7.2 Detailed Software Analysis 207
7.3 References 236
8 Simulating While Drilling - Adding a Complicated Multilateral Well During Transient Production from a Vertical 237
8.1 Vertical and Subsequent Multilateral Neighboring Well 238
8.2 Detailed Software Analysis 243
8.3 References 264
9 Heterogeneous, Anisotropic, Layered Reservoir with Finite Tilted Fracture Plane Produced by Multilateral Wells 265
9.1 Five Comparative Production Scenarios 266
Run 1. Uniform isotropic reservoir (base reference) 267
Run 2. Effect of high permeability fracture on Run 1 272
Run 3. Highly heterogeneous three layer reservoir, isotropic flow within each sub-domain, no fracture planes 274
Run 4. Effect of anisotropy on Run 1 (again, uniform kx, ky, with kz 50% smaller), no fractures 276
Run 5. Nonlinear gas flows, results compared with Run 1 liquid baseline, assuming uniform kx, ky and kz, no fractures 278
Closing remarks 279
9.2 Detailed Software Analysis 280
Run 1. Uniform isotropic reservoir (base reference) 281
Layered geological description 281
Software caution 283
Layered drilling description 287
Layer results and flow decline curves 300
Run 2. Effect of high permeability fracture on Run 1 308
Run 3. Highly heterogeneous three layer reservoir, isotropic flow within each sub-domain, no fracture planes 312
Run 4. Effect of anisotropy on Run 1 (again, uniform kx, ky, with kz 50% smaller), no fractures 316
Run 5. Nonlinear gas flows, results compared with Run 1 liquid baseline, assuming uniform kx, ky and kz, no fractures 321
9.3 Closing Remarks 328
9.4 References 328
10 Advanced Reservoir Modeling with Multisim 329
10.1 Features 330
Reservoir Description 330
Well System Modeling 330
Additional Simulator Features 330
10.2 Licensing Options 331
Multisim 331
Complementary Models 331
4D TurboView 331
Fluid Tracer 331
Formation Testing Suite 331
10.3 Disclaimer 332
End-User License Agreement (EULA) 332
Grant of license 332
Descriptions of other rights and limitations 333
Termination 334
Copyright 334
No warranties 334
Limitation of liability 334
Further disclaimers 335
Additional restrictions 335
End of EULA 335
Cumulative References 336
Index 351
About the Authors 359
Wilson C. Chin 359
Xiaoying Zhuang 376
