Bipedal Robots
Modeling, Design and Walking Synthesis
1st Edition
Published on 23. December 2008
Book
Hardback
338 pages
978-1-84821-076-9 (ISBN)
Description
Bipedal Robots: Modeling, Design and Walking Synthesis
This book presents various techniques to carry out the gait modeling, the gait patterns synthesis, and the control of biped robots. Some general information on the human walking, a presentation of the current experimental biped robots, and the application of walking bipeds are given. The modeling is based on the decomposition on a walking step into different sub-phases depending on the way each foot stands into contact on the ground. The robot design is dealt with according to the mass repartition and the choice of the actuators. Different ways to generate walking patterns are considered, such as passive walking and gait synthesis performed using optimization technique. Control based on the robot modeling, neural network methods, or intuitive approaches are presented. The unilaterality of contact is dealt with using on-line adaptation of the desired motion.
This book presents various techniques to carry out the gait modeling, the gait patterns synthesis, and the control of biped robots. Some general information on the human walking, a presentation of the current experimental biped robots, and the application of walking bipeds are given. The modeling is based on the decomposition on a walking step into different sub-phases depending on the way each foot stands into contact on the ground. The robot design is dealt with according to the mass repartition and the choice of the actuators. Different ways to generate walking patterns are considered, such as passive walking and gait synthesis performed using optimization technique. Control based on the robot modeling, neural network methods, or intuitive approaches are presented. The unilaterality of contact is dealt with using on-line adaptation of the desired motion.
More details
Language
English
Place of publication
London
United Kingdom
Target group
Professional and scholarly
Product notice
sewn/stitched
Cloth over boards
Dimensions
Height: 240 mm
Width: 161 mm
Thickness: 23 mm
Weight
674 gr
ISBN-13
978-1-84821-076-9 (9781848210769)
Copyright in bibliographic data and cover images is held by Nielsen Book Services Limited or by the publishers or by their respective licensors: all rights reserved.
Schweitzer Classification
Other editions
Additional editions
Christine Chevallereau | Guy Bessonnet | Gabriel Abba
Bipedal Robots
Modeling, Design and Walking Synthesis
E-Book
03/2013
Wiley-ISTE
€170.99
Available for download
Christine Chevallereau | Guy Bessonnet | Gabriel Abba
Bipedal Robots
Modeling, Design and Walking Synthesis
E-Book
01/2010
Wiley-ISTE
€170.99
Available for download
Persons
Christine Chevallereau is Director of Research at the National Center for Scientific Research (CNRS) and is a researcher at the Institute of Research in Communication and Cybernetics, Nantes, France.
Guy Bessonnet is a Professor at the University of Poitiers and is a researcher at the Laboratory of Solid Mechanics at Poitiers, France.
Gabriel Abba is Professor of Automatic Control and Robotics at the National Engineer School of Metz and is a researcher at the Laboratory of Industrial Engineering and Mechanical Production, Metz, France.
Yannick Aoustin is an Associate Professor at the University of Nantes and is a researcher at the Institute of Research in Communication and Cybernetics, Nantes, France.
Guy Bessonnet is a Professor at the University of Poitiers and is a researcher at the Laboratory of Solid Mechanics at Poitiers, France.
Gabriel Abba is Professor of Automatic Control and Robotics at the National Engineer School of Metz and is a researcher at the Laboratory of Industrial Engineering and Mechanical Production, Metz, France.
Yannick Aoustin is an Associate Professor at the University of Nantes and is a researcher at the Institute of Research in Communication and Cybernetics, Nantes, France.
