Aberration-corrected Analytical Electron Microscopy
Will be published approx. on 23. September 2011
Book
Hardback
296 pages
978-0-470-51851-9 (ISBN)
Description
The book is concerned with the theory, background, and practical use of transmission electron microscopes with lens correctors that can correct the effects of spherical aberration. The book also covers a comparison with aberration correction in the TEM and applications of analytical aberration corrected STEM in materials science and biology. This book is essential for microscopists involved in nanoscale and materials microanalysis especially those using scanning transmission electron microscopy, and related analytical techniques such as electron diffraction x-ray spectrometry (EDXS) and electron energy loss spectroscopy (EELS).
Reviews / Votes
"This book is essential for microscopists involved in nanoscale and materials microanalysis especially those using scanning transmission electron microscopy, and related analytical techniques such as electron diffraction x-ray spectrometry (EDXS) and electron energy loss spectroscopy (EELS)." (Imaging & Microscopy, 1 March 2012)More details
Product info
gebunden
Series
Edition
1. Auflage
Language
English
Place of publication
New York
United States
Target group
Professional and scholarly
Product notice
sewn/stitched
Paper over boards
Dimensions
Height: 235 mm
Width: 157 mm
Thickness: 21 mm
Weight
598 gr
ISBN-13
978-0-470-51851-9 (9780470518519)
Schweitzer Classification
Other editions
Additional editions
E-Book
08/2011
Wiley
€58.99
Available for download
E-Book
07/2011
Wiley
€58.99
Available for download
Person
Professor R.M.D. (Rik) Brydson is based in the School of Process, Environmental and Materials Engineering at the University of Leeds, UK. He is a committee member for the European Microscopy Society as well as the Electron Microscopy and Analysis Group (Institute of Physics).
