Bogatin's Practical Guide to Transmission Line Design and Characterization for Signal Integrity Applications
Published on 31. May 2020
Book
Hardback
603 pages
978-1-63081-851-7 (ISBN)
Description
This multimedia eBook establishes a solid foundation in the essential principles of how signals interact with transmission lines, how the physical design of interconnects affects transmission line properties, and how to interpret single-ended and differential time domain reflection (TDR) measurements to extract important figures of merits and avoid common mistakes. This book presents an intuitive understanding of transmission lines.
Instructional videos are provided in every chapter that cover important aspects of the interconnect design and characterization process. This video eBook helps establish foundations for designing and characterizing the electrical properties of interconnects to explain in a simplified way how signals propagate and interact with interconnects and how the physical design of transmission structures will impact performance.
Never be intimidated by impedance or differential pairs again.
Instructional videos are provided in every chapter that cover important aspects of the interconnect design and characterization process. This video eBook helps establish foundations for designing and characterizing the electrical properties of interconnects to explain in a simplified way how signals propagate and interact with interconnects and how the physical design of transmission structures will impact performance.
Never be intimidated by impedance or differential pairs again.
More details
Edition
Unabridged edition
Language
English
Place of publication
Norwood
United States
Target group
Professional and scholarly
Edition type
Unabridged edition
Product notice
sewn/stitched
Cloth over boards
Dimensions
Height: 238 mm
Width: 160 mm
Thickness: 38 mm
Weight
927 gr
ISBN-13
978-1-63081-851-7 (9781630818517)
Copyright in bibliographic data and cover images is held by Nielsen Book Services Limited or by the publishers or by their respective licensors: all rights reserved.
Schweitzer Classification
Content
What are transmission lines and why should we care; Single-ended lossless and differential lossy transmission lines; Calculating characteristic impedance; Reflections when the instantaneous impedance changes; The TDR; Practical TDR Measurements; Exploring geometry and impedance: 1st order effects; Second order factors; Dielectric Materials and Dk; Practical design issues; The capacitance and inductance in a transmission line; Input impedance of a transmission line; Simple point to point transmission line circuits; What every scope user needs to know about transmission lines; Terminating transmission line circuits; Appendixes.
