Electronic CAD Frameworks
Published on 30. June 1992
Book
Hardback
XVII, 195 pages
978-0-7923-9252-1 (ISBN)
Description
When it comes to frameworks, the familiar story of the elephant and the six blind philosophers seems to apply. As each philoso pher encountered a separate part of the elephant, each pronounced his considered, but flawed judgement. One blind philosopher felt a leg and thought it a tree. Another felt the tail and thought he held a rope. Another felt the elephant's flank and thought he stood before a wall. We're supposed to learn about snap judgements from this alle gory, but its author might well have been describing design automation frameworks. For in the reality of today's product development requirements, a framework must be many things to many people. xiv CAD Frameworks: Integration Technology for CAD As the authors of this book note, framework design is an optimi zation problem. Somehow, it has to be both a superior rope for one and a tremendous tree for another. Somehow it needs to provide a standard environment for exploiting the full potential of computer-aided engineering tools. And, somehow, it has to make real such abstractions as interoperability and interchangeability. For years, we've talked about a framework as something that provides application-oriented services, just as an operating system provides system-level support. And for years, that simple statement has hid the tremendous complexity of actually providing those services.
More details
Series
Edition
1992 ed.
Language
English
Place of publication
New York
United States
Target group
Professional and scholarly
Research
Illustrations
XVII, 195 p.
Dimensions
Height: 241 mm
Width: 160 mm
Thickness: 17 mm
Weight
497 gr
ISBN-13
978-0-7923-9252-1 (9780792392521)
DOI
10.1007/978-1-4615-3558-4
Schweitzer Classification
Other editions
Additional editions
Timothy J. Barnes | David Harrison | A. Richard Newton
Electronic CAD Frameworks
Book
10/2012
Springer
€106.99
Shipment within 7-9 days
Content
1: Introdution.- 1.1 The Nature of a CAD Framework.- 1.2 The Evolution of CAD Frameworks.- 1.3 CAD Frameworks and Openness.- 1.4 The Rise of Commercial CAD Frameworks.- 1.5 The Impact of Object-Oriented Techniques.- 1.6 The Standardization of CAD Frameworks.- 1.7 Organization of the Book.- 2: Major Components of an Engineering Framework.- 2.1 Overview.- 2.2 Operating System Services.- 2.3 Tool Integration and Encapsulation.- 2.4 Design Management.- 3: Data Representation.- 3.1 Introduction.- 3.2 Databases and Data Structures.- 3.3 Approaches to CAD Databases.- 3.4 Representational Issues.- 3.5 The Nature of Engineering Design Information.- 3.6 Hierarchy.- 4: Data Management.- 4.1 Introduction.- 4.2 Conventional Database Approaches.- 4.3 Physical Versus Logical Data Management.- 4.4 Managing the History of a Design.- 4.5 Managing Multiple Users of the Data.- 4.6 Concurrency Control.- 4.7 Compatibility with Change.- 5: Tool Management.- 5.1 Introduction.- 5.2 Tool Characterization.- 5.3 Tool Control.- 5.4 Other Tool Management Functions.- 6: Design Flow Management.- 6.1 Introduction.- 6.2 Benefits.- 6.3 DFM Dependencies.- 6.4 Existing Approaches.- 6.5 Describing the Design Flow.- 6.6 The Design Flow Engine.- 6.7 Standardization and Design Flow Management.- 7: User Interfaces.- 7.1 Introduction.- 7.2 History of Design Automation User Interface Systems.- 7.3 Modern Framework User Interfaces.- 7.4 Future Directions for CAD User Interfaces.- 8: Extension Languages.- 8.1 Introduction.- 8.2 Commercial Extension Languages in CAD.- 8.3 Extension Languages Prototypes.- 8.4 Extension Languages Requirements.- 8.5 Design Issues for Extension Languages.- 8.6 General Applications of Extension Languages.- 8.7 Language-Based Design.- 8.8 Benefits of an Extension Language.- 8.9 Future Directions.- 9: Implementing a CAD Framework.- 9.1 Introduction.- 9.2 The CODEM Approach.- 9.3 Commercial Frameworks.- 10: The CAD Framework Initiative.- 10.1 Introduction.- 10.2 The Origins of CFI.- 10.3 Goals and Deliverables.- 10.4 The CFI Organization.- 10.5 Tangible and Intangible Benefits.- 10.6 Technical Activities.- 10.7 CFI in the Future.- 11: Summary.- 11.1 Acknowledgments.- References.
